PCB Piezotronics ICP EX639A91 Installation And Operating Manual page 19

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
RELATED DRAWING
NO MODIFICATIONS PERMITTED
WITHOUT THE APPROVAL OF
THE AUTHORIZED PERSON
B
A
4
3
Y
.95 [24.1]
.48 [12.1]
.48 [12.1]
.95 [24.1]
X
Z
.720 [18.29]
.045 [1.14]
3
MOUNTING BOLT
(SUPPLIED PER SPECIFICATION)
M12x1 - 6g
4 PIN CONNECTOR
.36 [9.1]
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.03
XXX ±.010
ANGLES  2 DEGREES
FILLETS AND RADII
.003 - .005
2
REV
B
X - AXIS
Y - AXIS
2 1
4
3
Z - AXIS
COMMON
GROUND
DRAWN CHECKED
DIMENSIONS IN MILLIMETERS
KRM 1/31/18 KRM 1/31/18
[ IN BRACKETS ]
TITLE
DECIMALS X ± 0.8
XX ± 0.25
OUTLINE DRAWING
ANGLES  2 DEGREES
CASE ISOLATED
TRIAXIAL ACCELEROMETER
FILLETS AND RADII
0.07 - 0.13
2
1
REVISIONS
DESCRIPTION DIN
FIXED ORIENTATION OF KEYWAY 47821
B
A
ENGINEER
JJD 1/31/18
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
64204
IDENT. NO.
52681
SCALE: 2X SHEET 1 OF 1
1
