Pioneer MIR-101 Operating Manual

MULTI-ROOM SYSTEM REMOTE CONTROL EMITTER
OPERATING GUIDE
MIR-101
PIONEER'
The future of sound and vision.
Thank you for buying this Pioneer product.
Please read through these operating instructions so you will
know how to operate your unit properly.
After you have finished reading the instructions, keep the
manual in a safe place for future reference.
SUPPLIED ACCESSORIES
® Stereo mini-plug remote cord (10 m)
® Screw for wail mounting ..
® Operating guide
FEATURE
This unit can be used with any Pioneer model equipped with
a Multi-Room Remote input terminal, This unit can be used
with any Pioneer model equipped with a Multi-Room Remote
input terminal. Using this unit in combination with the optional
MR-100 (REMOTE CONTROL SENSOR UNIT) and a
programmable remote contro! unit, you can control audio
components located in your main room from another room
{your "sub-room'').
It is possible to cantrol not only Pioneer components. but also
components from other manufacturers. (Use the remote
control unit that came with the product, or use the Pioneer
programmabie remote control unit after it has memorized the
commands).
CASE 1:
When using a Pioneer product equipped with a Multi-Room
Remote INPUT jack and products from other manufacturers.
CASE 2:
When using a Pioneer product not equipped with a Muiti-
Room Remote INPUT jack. In this case, the MR-100 system
power indicator remains red.
SPECIFICATIONS
Light Emission System ......... Infrared LED
input Jack (Stereo mini) 3.52.. we I
Output Jack (Stereo mini) 2.52 . ast
Dimensions ..........00.00...5 90 (W) x 165 (D) x 30 {H) mm
3-9/16 (W) x 6-1/2 (DB) 1-3/16 (H) in
VV SIGE ics sats auideston reuivenadiy carb so aiinandipeneaess 220 g (7.7 oz)
