Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the PARTS LIST and/or HARDWARE LIST shown below.
Please read the instructions thoroughly before assembly.
1.We recommend that you assemble this product with the assistance of another person; this will make the
assembly easier, and will help eliminate damage to the product or injury to persons during assembly.
2.Please do not tighten screws or bolts until the assembly is completed.
3. To level the chairs or table, before tightening all the screws, the chairs or table must be placed on a
flat surface and then tighten the screws.
4. Please put all parts on a non-abrasive floor before assembly and follow the assembly steps to assemble
your newly purchased product correctly and efficiently.
PARTS LIST
NO.
COMPONENT
A
TABLE TOP
B
LEGS
C
PLATE
D
FEET
Created date: 08/09/2023
Assembly Instructions
SKETCH
QTY
1PC
4PCS
1PC
4PCS
MADE IN VIETNAM
ITEM NO. D4212-11
CITYSCAPE ROUND DINING TABLE
(1 PC/CTN)
NO.
COMPONENT
FLAT WASHER
1
5/16" DIA.
SPRING
WASHER
2
5/16" DIA.
SHORT BOLT
3
5/16" x 2 5/32"
LONG BOLT
4
5/16" x 5 1/2"
ALLEN
WRENCH
5
( 4mm )"
HARDWARE LIST
SKETCH
QTY
12 PCS
12 PCS
8 PCS
4 PCS
1 PC
PAGE: 1 OF 3
