V-TAC VT-12023 Instruction Manual

INSTRUCTION MANUAL
TECHNICAL DATA
MODEL
VT-12023
SKU
6387, 6399
POWER
2x18W (Tubes)
1850Lmx2
LUMENS
(Tubes Lumen)
BEAM ANGLE
120°
CRI
>80
PF
≥0.7
AC: 220-240V,
INPUT VOLTAGE
50Hz
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installing and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
WARNING
1. Please make sure to turn off the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by
the manufacturer or his service agent or a similar qualified person in order to avoid a hazard.
4. Terminal block not included. To be connected with Waterproof Cable Hose
5. For indoor use and outdoor use.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
LED WATERPROOF FITTING
WITH V-TAC LED TUBES
VT-15022
6388, 6400
2x24W (Tubes)
2100Lmx2
(Tubes Lumen)
120°
>80
≥0.7
AC: 220-240V,
50Hz
DRIVER MA
140mA
(Input Current)
CLIP NUMBER
10
OPERATIONAL
-20°C to +40°C
TEMPERATURE
LIFE SPAN
20,000 Hours
ON/OFF CYCLE
10,000 Times
MATERIAL
PC+ABS
DIMENSION
1276x96x58 mm
157mA
12
-20°C to +40°C
20,000 Hours
10,000 Times
PC+ABS
1576x96x58mm
