V-TAC VT-11-R Installation Instruction

Led rechargeable light

Advertisement

Quick Links

INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read
these instructions carefully before starting the installing and keep this manual handy for future
reference. If you have any another query, please contact our dealer or local vendor from whom
you have purchased the product. They are trained and ready to serve you at the best.
The warranty is valid for 2 years from the date of purchase. The warranty does not apply to
damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the
product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24
Hours a day would void the warranty. This product is warranted for manufacturing defects only.
2
WARRANTY
INSTALLATION INSTRUCTION
LED RECHARGEABLE LIGHT
*
SPECIFICATIONS
Model
Wa�s
Lumens
BeamAngle
PF
CRI
LED Chip Type
IP Ra�ng
Unit Color
On/Off Cycles
Opera�on Temperature
Input Power
Dimension
VT-11-R
10
700
100
>0.9
>80
SMD
IP44
Green+Black
>15000
-20°C to +45°C
AC:100-240V
175x125mm

Advertisement

loading
Need help?

Need help?

Do you have a question about the VT-11-R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for V-TAC VT-11-R

  • Page 1 175x125mm INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installing and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.
  • Page 2 Safety instructions for batteries and chargers Batteries 1. Never attempt to open for any reason. 2. Do not store in locations where the temperature may exceed 40 °C. 3. Charge only at ambient temperatures between 4 °C and 40 °C. 4.
  • Page 3 Major Components 1. Work light head 2. LED lamp assembly 3. Portable bracket 4. Protective cover 5. USB socket 6. Micro socket 7. LED indicator 8. ON/OFF switch with mode function Fig. 1 Fig. 2 Assembly Instruction ADJUSTMENT THE STAND The LED work light’s portable bracket (3) is adjustable (Max.
  • Page 4 OPERATION CHARGING THE WORK LIGHT 1. Open the protective cover (4) and push the micro plug (a) into micro socket (6). 2. Plug the adapter into a suitable mains outlet. Do not use an extension cord. 3. When the battery is loaded, three LED indicators (7) all illumine (Red light, yellow light and green light light up in sequence).
