Guide to SATA Hard Disks
Installation and RAID Configuration
1.
Guide to SATA Hard Disks Installation ............................ 2
1.1
2.
Guide to RAID Configurations ......................................... 3
2.1
Introduction of RAID ............................................... 3
2.2
RAID Configuration Precautions ............................ 5
2.3
64-bit With RAID Functions .................................... 6
2.4
Setting the BIOS RAID Items .................................. 7
2.5
Configuring the Intel RAID BIOS ............................. 7
2.6
Deleting RAID Volume .......................................... 11
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H67M-ITX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK H67M-ITX

Summary of Contents for ASROCK H67M-ITX

  • Page 1: Table Of Contents

    Guide to SATA Hard Disks Installation and RAID Configuration Guide to SATA Hard Disks Installation ......2 Serial ATA (SATA) Hard Disks Installation ....2 Guide to RAID Configurations ......... 3 Introduction of RAID ..........3 RAID Configuration Precautions ......5 ®...

  • Page 2: Guide To Sata Hard Disks Installation

    You may install SATA hard disks on this motherboard for internal storage devices. For SATA installation guide, please refer to Serial ATA (SATA) Hard Disks Installation of “User Manual” in the support CD. This section will guide you how to create RAID on SATA ports.

  • Page 3: Guide To Raid Configurations

    2.1 Introduction of RAID This motherboard adopts Intel H67 chipset that integrates RAID controller supporting RAID 0 / RAID 1/ Intel Rapid Storage / RAID 10 / RAID 5 function with four independent Serial ATA (SATA) channels. This section will introduce the basic knowledge of RAID, and the guide to configure RAID 0 / RAID 1/ Intel Rapid Storage / RAID 10 / RAID 5 settings.
  • Page 4 RAID 0 and RAID 1 set using only two identical hard disk drives. The Intel Rapid Storage technology creates two partitions on each hard disk drive to create a virtual RAID 0 and RAID 1 sets. This technology also allows you to change the hard disk drive partition size without losing any data.

  • Page 5: Raid Configuration Precautions

    WARNING!! Please backup your data first before you create RAID functions. In the process you create RAID, the system will ask if you want to “Clear Disk Data” or not. It is recommended to select “Yes”, and then your future...

  • Page 6: Installing Windows

    .. \ RAID Installation Guide and the document in the support CD, “Guide to Intel Rapid Storage”, which is located in the folder at the following path: .. \ Intel Rapid Storage Information ®...

  • Page 7: Setting The Bios Raid Items

    2.4 Setting the BIOS RAID Items After installing the hard disk drives, please set the necessary RAID items in the BIOS before setting your RAID configuration. Boot your system, and press <F2> key to enter BIOS setup utility. Highlight Advanced and press <Enter>, then the main interface of BIOS setup utility will appear.
  • Page 8 1-16 letters for your RAID volume then press <Enter>. Volume0 Use the up or down arrow keys to select your desired RAID Level. You may select RAID0 (Stripe), RAID1 (Mirror), RAID 5, RAID 10, or Rapid Storage for your RAID level. Press <Enter>, and then you can...
  • Page 9 Volume0 If you selected RAID 0 (Stripe), use the up or down arrow keys to select the stripe size for your RAID 0 array then press <Enter>.The available values range from 8 KB to 128 KB. The default selection is 128 KB.
  • Page 10 Volume0 Press <Enter> under the Create Volume item. The utility prompts a confirmation message as below. Volume0 Press <Y> to complete the setup of RAID. After the completion, you will see the detailed information about the RAID that you set up.

  • Page 11: Deleting Raid Volume

    Please note that you are only allowed to create one RAID partition at a time under BIOS RAID environment. If you want to create extra RAID partition, please use the RAID utility under Windows environment to configure RAID functions after you install OS.
