FEATURES - FRONT PANEL
2
SRC 1 & SRC 2: Determines which set of Source inputs will feed
1.
the Speaker and Sub outputs. Only one of these switches can be
selected at a given time.
MONO: Sums the left and right channels to mono for the A & B
2.
Speaker outputs. This switch does not affect the Headphone or
Aux outputs.
MUTE: Cuts all signal to the Speaker and Sub outputs. This switch
3.
does not affect the Headphone or Aux outputs.
DIM: Reduces the volume by -15dB through the Speaker and Sub
4.
outputs. This switch does not affect the Headphone or Aux outputs.
A & B: Selects which set of Speaker outputs is active. Only one of
5.
these buttons can be selected at a given time.
SUB: Activates the mono Sub output when selected. The Sub
6.
output is a full bandwidth output with no frequency rolloff.
LEVEL: Sets the overall output level of the Speaker and Sub
7.
outputs. This control does not affect the Headphone or Aux outputs.
Radial Engineering Ltd.
1
3 4 5
2
7
6
Nuance Select™
