3. Identifying the Parts

3.1 Soundbar

7 8
Remote Control Sensor
1
Receive signal from the remote control.
Display Window
2
Show the current status.
Wall bracket screws
3
(ON/OFF) button
4
Switch the soundbar between ON and
Standby mode.
/ (SOURCE) button
5
Select the play function.
Press and hold to activate the pairing
function in Bluetooth mode or disconnect
the existing paired Bluetooth device.
+ / － (volume) buttons
6
Increase/decrease the volume level.
USB Socket
7
Insert the USB device to play music.
AUX Socket
8
Connect to an external audio device.
4
9 10 11
4 5
3
12 13
OPTICAL Socket
9
Use to connect to the OPTICAL OUT socket
on an external device.
COAXIAL Socket
10
Use to connect to the COAXIAL OUT socket
on an external device.
HDMI OUT (TV eARC/ARC) Socket
11
The port for connecting a TV. The port
supports the eARC/ARC HDMI feature, which
allows the soundbar to play audio that
originates on the connected TV.
HDMI IN (1/2) Sockets
12
Two HDMI ports for connecting HDMI source
devices, such as a DVD player, Blu-ray Disc™
player, or gaming console. Note that only
one HDMI input is usable at a time.
AC~ Socket
13
Use to connect to power cable.
