No part of this installation guide may be reproduced, transcribed, transmitted, or trans-

lated in any language, in any form or by any means, except duplication of documen-

tation by the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this guide may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identifica-

tion or explanation and to the owners' benefit, without intent to infringe.

Disclaimer:

Specifications and information contained in this guide are furnished for informational

use only and subject to change without notice, and should not be constructed as a

commitment by ASRock. ASRock assumes no responsibility for any errors or omissions

that may appear in this guide.

With respect to the contents of this guide, ASRock does not provide warranty of any kind,

either expressed or implied, including but not limited to the implied warranties or

conditions of merchantability or fitness for a particular purpose. In no event shall

ASRock, its directors, officers, employees, or agents be liable for any indirect, special,

incidental, or consequential damages (including damages for loss of profits, loss of

business, loss of data, interruption of business and the like), even if ASRock has been

advised of the possibility of such damages arising from any defect or error in the guide

or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in

California, USA, please follow the related regulations in advance.

"Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate"

ASRock Website: http://www.asrock.com

ASRock G41M-GS3 / G41M-S3 Motherboard

Published October 2009

1 1 1 1 1

Table of Contents

Summary of Contents for ASROCK G41-G3

Page 1 ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this guide. With respect to the contents of this guide, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose.
Page 2: Motherboard Layout
USB 2.0 Header (USB4_5, Blue) North Bridge Controller System Panel Header (PANEL1, Orange) CPU Fan Connector (CPU_FAN1) BIOS SPI Chip 2 x 240-pin DDR3 DIMM Slots Chassis Fan Connector (CHA_FAN1) (Dual Channel: DDR3_A1, DDR3_B1; Blue) Floppy Connector (FLOPPY1) ATX Power Connector (ATXPWR1)
Page 3 100Mbps connection Green 1Gbps connection LAN Port * To enable Multi-Streaming function, you need to connect a front panel audio cable to the front panel audio header. Please refer to below steps for the software setting of Multi-Streaming. ® For Windows After restarting your computer, you will find “Mixer”...
Page 4: Package Contents
This Quick Installation Guide contains introduction of the motherboard and step-by-step installation guide. More detailed information of the motherboard can be found in the user manual presented in the Support CD. Because the motherboard specifications and the BIOS software might be updated, the content of this manual will be subject to change without notice.
Page 5: Specifications
Specifications Specifications Specifications Specifications Specifications Platform - Micro ATX Form Factor: 9.6-in x 7.6-in, 24.4 cm x 19.3 cm ® - LGA 775 for Intel Core 2 Extreme / Core 2 Quad / Core ® ® ® 2 Duo / Pentium...
Page 6 Connector - 4 x SATAII 3.0 Gb/s connectors (No Support for RAID and “Hot Plug” functions) (see CAUTION 8) - 1 x ATA100 IDE connector (supports 2 x IDE devices) - 1 x Floppy connector - 1 x Print port header...
Page 7 Before installing SATAII hard disk to SATAII connector, please read the “SATAII Hard Disk Setup Guide” on page 24 of “User Manual” in the support CD to adjust your SATAII hard disk drive to SATAII mode. You can also connect SATA hard disk to SATAII connector directly.
Page 8 USB flash drive or hard drive must use FAT32/16/12 file system. 13. The software name itself – OC DNA literally tells you what it is capable of. OC DNA, an exclusive utility developed by ASRock, provides a conve- nient way for the user to record the OC settings and share with others.
Page 9: Pre-Installation Precautions
Before you insert the 775-LAND CPU into the socket, please check if the CPU surface is unclean or if there is any bent pin on the socket. Do not force to insert the CPU into the socket if above situation is found.
Page 10 775-LAND CPU For proper inserting, please ensure to match the two orientation key notches of the CPU with the two alignment keys of the socket. Step 2-3. Carefully place the CPU into the socket by using a purely vertical motion.
Page 11: Installation Of Cpu Fan And Heatsink
1. It is recommended to use the cap tab to handle and avoid kicking off the PnP cap. 2. This cap must be placed if returning the motherboard for after service. Step 4. Close the socket: Step 4-1. Rotate the load plate onto the IHS.
Page 12: Installation Of Memory Modules (Dimm)
Unlock a DIMM slot by pressing the retaining clips outward. Step 2. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
Page 13: Installing An Expansion Card
2.4 Expansion Slots (PCI and PCI Express Slots) 2.4 Expansion Slots (PCI and PCI Express Slots) There are 2 PCI slots and 2 PCI Express slots on this motherboard. PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI interface. PCIE slots: PCIE1 (PCIE x1 slot) is used for PCI Express cards with x1 lane width cards, such as Gigabit LAN card, SATA2 card, etc.
Page 14: Jumpers Setup
2-pin jumper (see p.2 No. 8) Note: CLRCMOS1 allows you to clear the data in CMOS. The data in CMOS includes system setup information such as system password, date, time, and system setup parameters. To clear and reset the system parameters to default setup, please turn off the computer and unplug the power cord from the power supply.
Page 15 When you mount a FSB800 or FSB1066 CPU, and try to overclock to FSB1333 (by BIOS setting) you may face the problem, that DRAM frequency will be overclocked very high. Please use jumper to force NB to be strapped at higher frequency, so the DRAM can work at lower frequency.
Page 16: Onboard Headers And Connectors
FDD connector (33-pin FLOPPY1) (see p.2 No. 20) the red-striped side to Pin1 Note: Make sure the red-striped side of the cable is plugged into Pin1 side of the connector. Primary IDE connector (Blue) (39-pin IDE1, see p.2 No. 7)
Page 17 HDA to function correctly. Please follow the instruction in our manual and chassis manual to install your system. 2. If you use AC’97 audio panel, please install it to the front panel audio header as below: A.
Page 18 Though this motherboard provides 4-Pin CPU fan (Quiet Fan) support, the 3-Pin CPU fan still can work successfully even without the fan speed control function. If you plan to connect the 3-Pin CPU fan to the CPU fan connector on this motherboard, please connect it to Pin 1-3.
Page 19 (see p.2 No. 6) Though this motherboard provides 24-pin ATX power connector, it can still work if you adopt a traditional 20-pin ATX power supply. To use the 20-pin ATX power supply, please plug your power supply along with Pin 1 and Pin 13.
Page 20: Installation
STEP 2: Connect the SATA power cable to the SATA / SATAII hard disk. STEP 3: Connect one end of the SATA data cable to the motherboard’s SATAII connector. STEP 4: Connect the other end of the SATA data cable to the SATA / SATAII hard disk. Driver Installation Guide...
Page 21: Bios Information
ROM drive. It will display the Main Menu automatically if “AUTORUN” is enabled in your computer. If the Main Menu does not appear automatically, locate and double- click on the file “ASSETUP.EXE” from the BIN folder in the Support CD to display the menus.
Page 22 1. Einführung 1. Einführung 1. Einführung Wir danken Ihnen für den Kauf des ASRock G41M-GS3 / G41M-S3 Motherboard, ein zuverlässiges Produkt, welches unter den ständigen, strengen Qualitätskontrollen von ASRock gefertigt wurde. Es bietet Ihnen exzellente Leistung und robustes Design, gemäß der Verpflichtung von ASRock zu Qualität und Halbarkeit.
Page 23: Spezifikationen
Spezifikationen Spezifikationen Spezifikationen Spezifikationen Spezifikationen Plattform - Micro ATX-Formfaktor: 24.4 cm x 19.3 cm; 9.6 Zoll x 7.6 Zoll ® - LGA 775 für Intel Core 2 Extreme / Core 2 Quad / Core 2 Duo / Pentium ® Dual Core / Celeron ®...
Page 24 - 1 x VGA Port - 4 x Standard-USB 2.0-Anschlüsse - 1 x RJ-45 LAN Port mit LED (ACT/LINK LED und SPEED LED) - Audioanschlüsse: Line In / Line Out / Mikrofon Anschlüsse - 4 x SATAII-Anschlüsse, unterstützt bis 3.0 Gb/s Datenübertragungsrate (Unterstützt keine “RAID”- und “Hot-...
Page 25 Beachten Sie bitte, dass Overclocking, einschließlich der Einstellung im BIOS, Anwenden der Untied Overclocking-Technologie oder Verwenden von Overclocking-Werkzeugen von Dritten, mit einem gewissen Risiko behaftet ist. Overclocking kann sich nachteilig auf die Stabilität Ihres Systems auswirken oder sogar Komponenten und Geräte Ihres Systems beschädigen.
Page 26 * Wenn Sie einen DDR3 1333 Speichermodul adoptieren auf dieser Hauptplatine adoptieren, müssen Sie die Steckbrücke regulieren. Bitte beziehen Sie sich auf Seite 28 und 29 für korrekte Steckbrücke Einstellungen. Durch Betriebssystem-Einschränkungen kann die tatsächliche ® Speichergröße weniger als 4 GB betragen, da unter Windows 7 / Vista™...
Page 27 13. Allein der Name – OC DNA* – beschreibt es wörtlich, was die Software zu leisten vermag. OC DNA ist ein von ASRock exklusiv entwickeltes Dienstprogramm, das Nutzern eine bequeme Möglichkeit bietet, Übertaktungseinstellungen aufzuzeichnen und sie Anderen mitzuteilen. Es hilft Ihnen, Ihre Übertaktungsaufzeichnung im Betriebssystem zu speichern und vereinfacht den komplizierten Aufzeichnungsvorgang von Übertaktungseinstellungen.
Page 28: Einstellung Der Jumper
+5VSB (Standby) zu setzen (siehe S.2 - No. 1) und die PS/2 oder USB- Weckfunktionen zu aktivieren. Hinweis: Um +5VSB nutzen zu können, muss das Netzteil auf dieser Leitung 2A oder mehr leisten können. CMOS löschen (CLRCMOS1, 2-Pin jumper) 2-Pin jumper (siehe S.2 - No.
Page 29 Wenn Sie die CPU zur Nutzung von FSB1066 mit diesem Motherboard übertakten möchten, müssen Sie Steckbrückeneinstellungen ändern. Bitte überbrücken Sie die Pins 2 und 3 der Steckbrücke FSB1, die Pins 4 und 5 der Steckbrücke FSB2 und die Pins 4 und 5 der Steckbrücke FSB3. Andernfalls arbeitet die CPU eventuell nicht richtig mit Ihrem Motherboard.
Page 30 (33-Pin FLOPPY1) die rotgestreifte Seite auf Stift 1 (siehe S.2 - No. 20) Hinweis: Achten Sie darauf, dass die rotgestreifte Seite des Kabel mit der Stift 1- Seite des Anschlusses verbunden wird. Primärer IDE-Anschluss (Blauer) (39-pin IDE1, siehe S.2 - No. 7)
Page 31 Geräte), wobei jedoch die Bildschirmverdrahtung am Gehäuse HDA unterstützen muss, um richtig zu funktionieren. Beachten Sie bei der Installation im System die Anweisungen in unserem Handbuch und im Gehäusehandbuch. 2. Wenn Sie die AC’97-Audioleiste verwenden, installieren Sie diese wie nachstehend beschrieben an der Front-Audioanschlussleiste: A.
Page 32 F. Rufen Sie das Windows-System auf. Klicken Sie auf das Symbol in der Taskleiste unten rechts, um den Realtek HD Audio-Manager aufzurufen. ® Für Windows XP / XP 64-Bit Betriebssystem: Klicken Sie auf “Audio-E/A”, wählen Sie die “Anschlusseinstellungen” , wählen Sie “Erkennung der Frontleistenbuchse deaktivieren”...
Page 33 Obwohl dieses Motherboard einen 24-pol. ATX-Stromanschluss bietet, kann es auch mit einem modifizierten traditionellen 20-pol. ATX-Netzteil verwendet werden. Um ein 20-pol. ATX-Netzteil zu verwenden, stecken Sie den Stecker mit Pin 1 und Pin 13 ein. Installation eines 20-pol. ATX-Netzteils Anschluss für...
Page 34 Erscheint der Wilkommensbildschirm nicht, so “doppelklicken” Sie bitte auf das File ASSETUP.EXE im BIN-Verzeichnis der Support-CD, um die Menüs aufzurufen. Das Setup-Programm soll es Ihnen so leicht wie möglich machen. Es ist menügesteuert, d.h. Sie können in den verschiedenen Untermenüs Ihre Auswahl treffen und die Programme werden dann automatisch installiert.
Page 35 1.1 Contenu du paquet Carte mère ASRock G41M-GS3 / G41M-S3 (Facteur de forme Micro ATX: 9.6 pouces x 7.6 pouces, 24.4 cm x 19.3 cm) Guide d’installation rapide ASRock G41M-GS3 / G41M-S3 CD de soutien ASRock G41M-GS3 / G41M-S3 Deux câbles d’alimentation de série ATA (SATA) HDD (en option)
Page 36 - FSB1333/1066/800/533 MHz (voir ATTENTION 1) - Prise en charge de la technologie Hyper-Threading (voir ATTENTION 2) - Prend en charge la technologie Untied Overclocking (voir ATTENTION 3) - Prise en charge de la technologie EM64T par le CPU ® Chipsets - Northbridge: Intel ®...
Page 37 - 1 x port série: COM 1 - 1 x port VGA - 4 x ports USB 2.0 par défaut - 1 x port LAN RJ-45 avec LED (ACT/LED CLIGNOTANTE et LED VITESSE) - Jack audio: entrée ligne / sortie ligne / microphone...
Page 38 - FCC, CE - Prêt pour EuP (alimentation Prêt pour EuP requise) (voir ATTENTION 16) * Pour de plus amples informations sur les produits, s’il vous plaît visitez notre site web: http://www.asrock.com ATTENTION Il est important que vous réalisiez qu’il y a un certain risque à effectuer l’overclocking, y compris ajuster les réglages du BIOS, appliquer la technologie Untied Overclocking, ou...
Page 39 Avant d’installer le disque dur SATAII au connecteur SATAII, veuillez lire le Guide « Installation du disque dur SATAII » à la page 24 du « Manuel de l’utilisateur » qui se trouve sur le CD de support pour régler votre lecteur de disque dur SATAII au mode SATAII.
Page 40 Pour améliorer la dissipation de la chaleur, n’oubliez pas de mettre de la pâte thermique entre le CPU le dissipateur lors de l’installation du PC.
Page 41 (voir p.2 No. 1) (standby) et permettre aux périphériques PS/2 ou USB de réveiller le système. Note: Pour sélectionner +5VSB, il faut obligatoirement 2 Amp et un courant standby supérieur fourni par l’alimentation. Effacer la CMOS (CLRCMOS1, le cavalier à 2 broches le cavalier à...
Page 42 Si vous voulez overclocker le CPU que vous adoptez vers un FSB1066 sur cette carte mère, vous devez régler les cavaliers. Veuillez court-circuiter pin2, pin3 pour le cavalier FSB1, pin4, pin5 pour le cavalier FSB2 et pin4, pin5 pour le cavalier FSB3. Sinon, le CPU pourrait ne pas fonctionner correctement sur cette carte mère.
Page 43 (FLOPPY1 br. 33) (voir p.2 No. 20) le côté avec fil rouge côté Broche1 Note: Assurez-vous que le côté avec fil rouge du câble est bien branché sur le côté Broche1 du connecteur. Connecteur IDE primaire (Bleu) (IDE1 br. 39, voir p.2 No. 7)
Page 44 1. L’audio à haute définition (HDA) prend en charge la détection de fiche, mais le fil de panneau sur le châssis doit prendre en charge le HDA pour fonctionner correctement. Veuillez suivre les instructions dans notre manuel et le manuel de châssis afin installer votre système.
Page 45 XP / XP 64-bit OS: Cliquer sur « E/S audio», sélectionner « Paramètres du connecteur » , choisir « Désactiver la détection de la prise du panneau de commande » et sauvegarder les changements en cliquant sur « OK ».
Page 46 (Ventilateur silencieux) ventilateur de CPU à 4 broches , le ventilateur de CPU à 3 broches peut bien fonctionner même sans la fonction de commande de vitesse du ventilateur. Si vous prévoyez de connecter le ventilateur de CPU à 3 broches au connecteur du ventilateur de CPU sur cette carte mère, veuillez le connecter...
Page 47: Informations Sur Le Cd De Support
BIOS; sinon, le POST continue ses tests de routine. Si vous désirez entrer dans le BIOS après le POST, veuillez redémarrer le système en pressant <Ctl> + <Alt> + <Suppr>, ou en pressant le bouton de reset sur le boîtier du ées système.
Page 48: Contenuto Della Confezione
1. Introduzione Grazie per aver scelto una scheda madre ASRock G41M-GS3 / G41M-S3, una scheda madre affidabile prodotta secondo i severi criteri di qualità ASRock. Le prestazioni eccellenti e il design robusto si conformano all’impegno di ASRock nella ricerca della qualità e della resistenza.
Page 49 1.2 Specifiche Specifiche Specifiche Specifiche Specifiche Piattaforma - Micro ATX Form Factor: 9.6-in x 7.6-in, 24.4 cm x 19.3 cm Processore - LGA 775 per Intel ® Core 2 Extreme / Core 2 Quad / Core ® ® ® Duo / Pentium...
Page 50 - 4 x porte USB 2.0 già integrate - 1 x porte LAN RJ-45 con LED (LED azione/collegamento e LED velocità) - Audio Jack: Line In / Line Out / Microfono Connettori - 4 x connettori SATAII 3.0Go/s (Non supporta le funzioni “RAID” e “Collegamento a caldo”) (vedi ATTENZIONE 8)
Page 51 * Per ulteriori informazioni, prego visitare il nostro sito internet: http://www.asrock.com AVVISO Si prega di prendere atto che la procedura di overclocking implica dei rischi, come anche la regolazione delle impostazioni del BIOS, l’applicazione della tecnologia Untied Overclocking Technology, oppure l’uso di strumenti di overclocking forniti da terzi. L’overclocking può...
Page 52 (dischi floppy) o altre complicate utilità Flash. Si prega di notare che l’unità Flash USB o il disco rigido devono usare il File System FAT32/16/ 13. Il nome stesso del software – OC DNA – dice di cosa è capace. OC DNA, una utilità esclusiva sviluppata da ASRock, fornisce un modo comodo per registrare le impostazioni OC e condividerle con gli altri.
Page 53 Intel l’alimentatore predisposto EuP deve soddisfare lo standard secondo cui l’efficienza energetica in standby di 5 v è più alta del 50% con un consumo di corrente di 100 mA. Per la scelta di un’alimentatore predisposto EuP consigliamo di verificare ulteriori dettagli con il produttore.
Page 54 Nota: CLRCMOS1 consente di pulire i dati nella CMOS. I dati nella CMOS includono informazioni del setup del sistema, come per esempio la password di sistema, la data, l’ora, e i parametri del setup di sistema. Per pulire I parametri di sistema e resettare ai parametri di default, spegnere il computer e scollegare l’alimentatore, poi collegare il jumper sul CLRCMOS1 per 5 secondi.
Page 55 (jumper). Mettere in corto i piedini 2, 3 per il ponticello FSB1, i piedini 4, 5 per il ponticello FSB2 ed i piedini 4, 5 per il ponticello FSB3. In caso contrario la CPU potrebbe non funzionare correttamente su questa scheda madre.
Page 56 (33-pin FLOPPY1) (vedi p.2 Nr. 20) Lato del Pin1 con la striscia rossa Nota: Assicurarsi che il lato del cavo con la striscia rossa sia inserito nel lato Pin1 del connettore. Connettore IDE primario (Blu) (39-pin IDE1, vedi p.2 Nr. 7)
Page 57 1. La caratteristica HDA (High Definition Audio) supporta il rilevamento dei connettori, però il pannello dei cavi sul telaio deve supportare la funzione HDA (High Definition Audio) per far sì che questa operi in modo corretto. Attenersi alle istruzioni del nostro manuale e del manuale del telaio per installare il sistema.
Page 58 F. Entrare nel sistema di Windows. Fare clic sull’icona situata nell’angolo inferiore destro della barra delle applicazioni per entrare su Realtek HD Audio Manager. Per Windows ® XP / XP 64-bit OS: Fare clic su “Audio I/O”, selezionare “Impostazioni connettore”...
Page 59 Sebbene la presente scheda madre disponga di un supporto per ventola CPU a 4 piedini (ventola silenziosa), la ventola CPU a 3 piedini è in grado di funzionare anche senza la funzione di controllo della velocità della ventola. Se si intende collegare la ventola CPU a 3 piedini al connettore della ventola CPU su questa scheda madre, collegarla ai piedini 1-3.
Page 60 BIOS; altrimenti, POST continua con i suoi test di routine. Per entrare il BIOS Setup dopo il POST, riavvia il sistema premendo <Ctl> + <Alt> + <Delete>, o premi il tasto di reset sullo chassis del sistema. Per informazioni più dettagliate circa il Setup del BIOS, fare riferimento al Manuale dell’Utente (PDF file) contenuto nel cd di...
Page 61: Contenido De La Caja
ASRock. Esta Guía rápida de instalación contiene una introducción a la placa base y una guía de instalación paso a paso. Puede encontrar una información más detallada sobre la placa base en el manual de usuario incluido en el CD de soporte.
Page 62 1.2 Especificación Especificación Especificación Especificación Especificación Plataforma - Factor forma Micro ATX: 24,4 cm x 19,3 cm, 9,6” x 7,6” ® Procesador - LGA 775 para Intel Core 2 Extreme / Core 2 Quad / Core ® ® ® 2 Duo / Pentium Doble Núcleo / Celeron...
Page 63 - 1 x Puerto VGA - 4 x puertos USB 2.0 predeterminados - 1 x Puerto LAN RJ-45 con LED (LED de ACCIÓN/ENLACE y LED de VELOCIDAD) - Audio Jack: Line In / Line Out / Micrófono Conectores - 4 x conexiones SATAII, admiten una velocidad de transferencia de datos de hasta 3,0Gb/s (No soporta las funciones “RAID”...
Page 64 ADVERTENCIA Tenga en cuenta que hay un cierto riesgo implícito en las operaciones de aumento de la velocidad del reloj, incluido el ajuste del BIOS, aplicando la tecnología de aumento de velocidad liberada o utilizando las herramientas de aumento de velocidad de otros fabricantes.
Page 65 Antes de instalar un disco duro SATAII en el conector SATAII, consulte la sección “Guía de instalación de discos duros SATAII” en la página 24 del “Manual de usuario” que se incluye en el CD de soporte para configurar su disco duro SATAII en modo SATAII. También puede conectar un disco duro SATA directamente al conector SATAII.
Page 66 USB o disco duro utilizado debe disponer del sistema de archivos FAT32/16/12. 13. El nombre del propio software, OC DNA, indica con claridad aquello de lo que es capaz. OC DNA, una exclusiva utilidad desarrollada por ASRock, representa para el usuario una forma cómoda de grabar su configuración...
Page 67 Si adopta la siguiente configuración DRAM / CPU en esta placa base, necesitará ajustar los puentes. Por favor, siga las instrucciones indicadas a continuación para configurar los puentes. De otra forma, puede que la CPU y el módulo de memoria no funcionen adecuadamente en esta placa base.
Page 68 Por favor, cortocircuite el pin2 y el pin3 para el puente FSB1, el pin 4 y el pin5 para el puente FSB2 y el pin4 y el pin5 para el puente FSB3. Si no lo hace así, puede que la CPU no funcione adecuadamente en esta placa base.
Page 69 (vea p.2, N. 20) la banda roja debe quedar en el mismo lado que el contacto 1 Atención: Asegúrese que la banda roja del cable queda situado en el mismo lado que el contacto 1 de la conexión. IDE conector primario (Azul) (39-pin IDE1, vea p.2, N.
Page 70 2. Si utiliza el panel de sonido AC’97, instálelo en la cabecera de sonido del panel frontal de la siguiente manera: A. Conecte Mic_IN (MIC) a MIC2_L.
Page 71 F. Entre en el sistema Windows. Haga clic en el icono de la barra de tareas situada en la parte inferior derecha para entrar en el Administrador de audio HD Realtek. ® Para Windows XP / XP 64-bit OS: Haga clic en “E/S de audio”, seleccione “Configuración de conectores”...
Page 72 Si pretende enchufar el ventilador de procesador de 3 contactos en el conector del ventilador de procesador de esta placa base, conéctelo al contacto 1-3. Contacto 1-3 conectado Instalación del ventilador de 3 contactos...
Page 73 Para iniciar la instalación, ponga el CD en el lector de CD y se desplegará el Menú Principal automáticamente si «AUTORUN» está habilitado en su computadora. Si el Menú...
Page 74 Gratos por comprar nossa placa–mãe G41M-S3, um produto confiável feito com ASRock um estrito controle de qualidade consistente. Com um excelente desempenho, essa placa é dotada de um projeto robusto que atende a ASRock de compromisso com a qualidade e durabilidade.
Page 75 1.2 Especificações 1.2 Especificações 1.2 Especificações 1.2 Especificações 1.2 Especificações Plataforma - Formato Micro ATX: 9,6 pol. x 7,6 pol., 24,4 cm x 19,3 cm ® - Socket Intel Dual Core Core 2 Extreme / Core 2 Quad / ®...
Page 76 - 4 x portas USB 2.0 padrão - 1 x porta LAN RJ-45 com LED (LED ACT/LIG e LED VELOCIDADE) - Áudio Jack: saída / entrada de linha / microfone + porta de jogos Conectores - 4 x conectores SATAII, suporte a taxa de transferência de dados de até...
Page 77 AVISO Tenha em atenção que a operação de overclocking envolve alguns riscos, nomeadamente no que diz respeito ao ajuste das definições do BIOS, à aplicação da tecnologia Untied Overclocking ou à utilização de ferramentas de overclocking de terceiros. O overclocking pode afectar a estabilidade do seu sistema ou até...
Page 78 94 e 95. Devido às limitações do sistema operativo, o tamanho real da memória pode ser inferior a 4 GB uma vez que uma parte desta está reservada ® para utilização pelo sistema operativo no âmbito do Windows Vista / 7.
Page 79 Depois, os seus amigos podem carregar o perfil OC no seu próprio sistema para obter as mesmas definições OC que você tem! Por favor, tenha em conta que o perfil OC só pode ser partilhado e trabalhado na mesma placa-mãe.
Page 80 (veja a folha 2, No. 1) para PS/2 ou eventos de wake up na USB. Nota: Para escolher +5VSB, é preciso uma corrente de stand by de 2 A ou mais. Restaurar CMOS (CLRCMOS1, jumper de 2 pinos) jumper de 2 pinos (veja a folha 2, No.
Page 81 Faça a conexão do pino 2, pino 3 para o jumper de FSB1, pino 4, pino 5 para o jumper de FSB2 o pino 4, pino 5 para o jumper de FSB3. Caso contrário, o CPU pode não funcionar devidamente nesta placa-mãe.
Page 82 Faça a conexão do pino 2, pino 3 para o jumper de FSB1, pino 3, pino 4 para o jumper de FSB2 o pino 4, pino 5 para o jumper de FSB3. Caso contrário, o CPU pode não funcionar devidamente nesta placa-mãe.
Page 83 (FLOPPY 1, 33 pinos) (veja a folha 2, No. 20) o lado com listras vermelhas para o Pino 1 Nota: Certifique-se de que o lado com listras vermelhas no cabo seja conectado ao lado Pino 1 do conector. Conector primário (Azul) (IDE1 de 39 pinos, veja a folha 2, No.
Page 84 Siga s instruções que aparecem no manual e no manual do chassis para instalar o sistema. 2. Se utilizar o painel de áudio AC’97, instale-o no cabeçalho de áudio do painel frontal, como a figura abaixo mostra: A. Ligue o Mic_IN (MIC) ao MIC2_L.
Page 85 XP / XP 64-bit OS: Queira seleccionar “Front Mic” (Microfone Frontal) como dispositivo de gravação predefinido. Se quer ouvir a sua voz através do microfone frontal, queira desmarcar o ícone “Mute” (Sem som) em “Front Mic” (Microfone Frontal) da parte “Playback” (Reprodução).
Page 86 (Ventoinha silenciosa), uma ventoinha de 3 pinos para CPU poderá funcionar mesmo sem a função de controlo de velocidade da ventoinha. Se pretender ligar uma ventoinha de 3 pinos para CPU ao conector de ventoinha do CPU nesta placa-mãe, por favor, ligue-a aos pinos 1-3.
Page 87 Se desejar acessar o Utilitário de Configuração do BIOS depois do POST, reinicie o sistema pressionando <Ctl> + <Alt> + <Del>, ou pressionando o botão de reinício no chassi do sistema. Para as informações detalhadas sobre o Utilitário de Configuração do BIOS, consulte o Manual do Usuário (arquivo PDF) no CD de suporte.
Page 88 1 0 1 1 0 1 1 0 1 1 0 1 1 0 1 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 89 ® ® ® ® ® ® ® ® 1 0 2 1 0 2 1 0 2 1 0 2 1 0 2 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 90 ® 1 0 3 1 0 3 1 0 3 1 0 3 1 0 3 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 91 “ ” ® ® ® “ ” “ ” 1 0 4 1 0 4 1 0 4 1 0 4 1 0 4 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 92 ® ® 1 0 5 1 0 5 1 0 5 1 0 5 1 0 5 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 93 “ ” “ ” “ ” “ ” 1 0 6 1 0 6 1 0 6 1 0 6 1 0 6 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 94 1 0 7 1 0 7 1 0 7 1 0 7 1 0 7 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 95 1 0 8 1 0 8 1 0 8 1 0 8 1 0 8 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 96 ® 1 0 9 1 0 9 1 0 9 1 0 9 1 0 9 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 97 ® ® ® “ ” “ ” “ ” “ ” ® “ ” “ ” 4 3 2 1 1 1 0 1 1 0 1 1 0 1 1 0 1 1 0 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 98 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 99 “ ” “ ” 1 1 2 1 1 2 1 1 2 1 1 2 1 1 2 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 100 1 1 3 1 1 3 1 1 3 1 1 3 1 1 3 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 101 ® ® ® ® ® ® ® ® 1 1 4 1 1 4 1 1 4 1 1 4 1 1 4 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 102 1 1 5 1 1 5 1 1 5 1 1 5 1 1 5 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 103 ® ® “ ” 1 1 6 1 1 6 1 1 6 1 1 6 1 1 6 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 104 ® ® ® ® ® ® ® – 1 1 7 1 1 7 1 1 7 1 1 7 1 1 7 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 105 1 1 8 1 1 8 1 1 8 1 1 8 1 1 8 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 106 1 1 9 1 1 9 1 1 9 1 1 9 1 1 9 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 107 1 2 0 1 2 0 1 2 0 1 2 0 1 2 0 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 108 1 2 1 1 2 1 1 2 1 1 2 1 1 2 1 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 109 1 2 2 1 2 2 1 2 2 1 2 2 1 2 2 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 110 ® ® ® ® ® 4 3 2 1 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 111 1 2 4 1 2 4 1 2 4 1 2 4 1 2 4 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 112 ® ® 1 2 5 1 2 5 1 2 5 1 2 5 1 2 5 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 113 1 2 6 1 2 6 1 2 6 1 2 6 1 2 6 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 114 ® ® ® ® ® ® ® ® 1 2 7 1 2 7 1 2 7 1 2 7 1 2 7 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 115 ® ® 1 2 8 1 2 8 1 2 8 1 2 8 1 2 8 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 116 ® ® ® ® 1 2 9 1 2 9 1 2 9 1 2 9 1 2 9 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 117 ® ® ® 1 3 0 1 3 0 1 3 0 1 3 0 1 3 0 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 118 1 3 1 1 3 1 1 3 1 1 3 1 1 3 1 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 119 1 3 2 1 3 2 1 3 2 1 3 2 1 3 2 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 120 1 3 3 1 3 3 1 3 3 1 3 3 1 3 3 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 121 1 3 4 1 3 4 1 3 4 1 3 4 1 3 4 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 122 ® ® ® ® 4 3 2 1 1 3 5 1 3 5 1 3 5 1 3 5 1 3 5 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 123 1 3 6 1 3 6 1 3 6 1 3 6 1 3 6 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 124 ® ® 1 3 7 1 3 7 1 3 7 1 3 7 1 3 7 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 125 1 3 8 1 3 8 1 3 8 1 3 8 1 3 8 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 126 1 3 9 1 3 9 1 3 9 1 3 9 1 3 9 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 127 ® ® ® ® ® ® ® ® 1 4 0 1 4 0 1 4 0 1 4 0 1 4 0 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 128 1 4 1 1 4 1 1 4 1 1 4 1 1 4 1 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 129 ® ® ® ® ® ® 1 4 2 1 4 2 1 4 2 1 4 2 1 4 2 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 130 ® ® ® 1 4 3 1 4 3 1 4 3 1 4 3 1 4 3 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 131 1 4 4 1 4 4 1 4 4 1 4 4 1 4 4 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 132 1 4 5 1 4 5 1 4 5 1 4 5 1 4 5 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 133 1 4 6 1 4 6 1 4 6 1 4 6 1 4 6 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 134 ® 1 4 7 1 4 7 1 4 7 1 4 7 1 4 7 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 135 ® ® ® ® 4 3 2 1 1 4 8 1 4 8 1 4 8 1 4 8 1 4 8 ASRock G41M-GS3 / G41M-S3 Motherboard...
Page 136 ® ® ® 1 4 9 1 4 9 1 4 9 1 4 9 1 4 9 ASRock G41M-GS3 / G41M-S3 Motherboard...
