ASROCK G41MH-GE User Manual
  1. Manuals
  2. Brands
  3. ASROCK Manuals
  4. Motherboard
  5. G41MH-GE
  6. User manual
ASROCK G41MH-GE User Manual

ASROCK G41MH-GE User Manual

Hide thumbs Also See for G41MH-GE:
Table of Contents

Advertisement

Quick Links

Download this manual
Copyright Notice:
Copyright Notice:
Copyright Notice:
Copyright Notice:
Copyright Notice:
No part of this installation guide may be reproduced, transcribed, transmitted, or trans-
lated in any language, in any form or by any means, except duplication of documen-
tation by the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this guide may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identifica-
tion or explanation and to the owners' benefit, without intent to infringe.
Disclaimer:
Disclaimer:
Disclaimer:
Disclaimer:
Disclaimer:
Specifications and information contained in this guide are furnished for informational
use only and subject to change without notice, and should not be constructed as a
commitment by ASRock. ASRock assumes no responsibility for any errors or omissions
that may appear in this guide.
With respect to the contents of this guide, ASRock does not provide warranty of any kind,
either expressed or implied, including but not limited to the implied warranties or
conditions of merchantability or fitness for a particular purpose. In no event shall
ASRock, its directors, officers, employees, or agents be liable for any indirect, special,
incidental, or consequential damages (including damages for loss of profits, loss of
business, loss of data, interruption of business and the like), even if ASRock has been
advised of the possibility of such damages arising from any defect or error in the guide
or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic
substance controlled in Perchlorate Best Management Practices (BMP) regulations
passed by the California Legislature. When you discard the Lithium battery in
California, USA, please follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate"
ASRock Website: http://www.asrock.com
Copyright©2009 ASRock INC. All rights reserved.
ASRock G41MH-GE Motherboard
Published September 2009
1 1 1 1 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G41MH-GE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK G41MH-GE

Summary of Contents for ASROCK G41MH-GE

  • Page 1 ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this guide. With respect to the contents of this guide, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose.

  • Page 2: Motherboard Layout

    CPU Fan Connector (CPU_FAN1) System Panel Header (PANEL1, Orange) 775-Pin CPU Socket Print Port Header (LPT1, Purple) 2 x 240-pin DDR2 DIMM Slots Chassis Speaker Header (Dual Channel A: DDRII_1, DDRII_3; Yellow) (SPEAKER 1, Purple) 2 x 240-pin DDR2 DIMM Slots Serial Port Connector (COM1) (Dual Channel B: DDRII_2, DDRII_4;...
  • Page 3 Line In (Light Blue) PS/2 Keyboard Port (Purple) ** 8 Front Speaker (Lime) * There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications. LAN Port LED Indications ACT/LINK...
  • Page 4 To enable Multi-Streaming function, you need to connect a front panel audio cable to the front panel audio header. After restarting your computer, you will find “VIA HD Audio Deck” tool on your system. Please follow below instructions according to the OS you install.

  • Page 5: Package Contents

    This Quick Installation Guide contains introduction of the motherboard and step-by-step installation guide. More detailed information of the motherboard can be found in the user manual presented in the Support CD. Because the motherboard specifications and the BIOS software might be updated, the content of this manual will be subject to change without notice.

  • Page 6: Specifications

    Specifications Specifications Specifications Specifications Specifications Platform - Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm - LGA 775 for Intel ® Core 2 Extreme / Core 2 Quad / Core ® ® ® 2 Duo / Pentium...
  • Page 7 - 1 x Optical SPDIF Out Port - 4 x Ready-to-Use USB 2.0 Ports - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jack: Side Speaker/Rear Speaker/Central/Bass/ Line in/Front Speaker/Microphone (see CAUTION 8) Connector - 4 x SATAII 3.0 Gb/s connectors (No Support for RAID and...
  • Page 8 Overclocking may affect your system stability, or even cause damage to the components and devices of your system. It should be done at your own risk and expense. We are not responsible for possible damage caused by overclocking.
  • Page 9 USB flash drive or hard drive must use FAT32/16/12 file system. 14. The software name itself – OC DNA literally tells you what it is capable of. OC DNA, an exclusive utility developed by ASRock, provides a conve- nient way for the user to record the OC settings and share with others.

  • Page 10: Minimum Hardware Requirement For Full Hd 1080P Blu-Ray (Bd) / Hd-Dvd Playback Support

    17. EuP, stands for Energy Using Product, was a provision regulated by European Union to define the power consumption for the completed system. According to EuP, the total AC power of the completed system shall be under 1.00W in off mode condition. To meet EuP standard, an EuP ready motherboard and an EuP ready power supply are required.

  • Page 11: Pre-Installation Precautions

    Before you insert the 775-LAND CPU into the socket, please check if the CPU surface is unclean or if there is any bent pin on the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 12 775-LAND CPU For proper inserting, please ensure to match the two orientation key notches of the CPU with the two alignment keys of the socket. Step 2-3. Carefully place the CPU into the socket by using a purely vertical motion.

  • Page 13: Installation Of Cpu Fan And Heatsink

    1. It is recommended to use the cap tab to handle and avoid kicking off the PnP cap. 2. This cap must be placed if returning the motherboard for after service. Step 4. Close the socket: Step 4-1. Rotate the load plate onto the IHS.

  • Page 14: Installation Of Memory Modules (Dimm)

    (the same brand, speed, size and chip- type) DDR2 DIMM pair in the slots of the same color. In other words, you have to install identical DDR2 DIMM pair in Dual Channel A (DDRII_1 and DDRII_3;...

  • Page 15: Installing A Dimm

    Unlock a DIMM slot by pressing the retaining clips outward. Step 2. Align a DIMM on the slot such that the notch on the DIMM matches the break on the slot. The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

  • Page 16: Installing An Expansion Card

    2.4 Expansion Slots (PCI and PCI Express Slots) 2.4 Expansion Slots (PCI and PCI Express Slots) There are 2 PCI slots and 2 PCI Express slots on this motherboard. PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI interface. PCIE slots: PCIE1 (PCIE x1 slot) is used for PCI Express cards with x1 lane width cards, such as Gigabit LAN card, SATA2 card, etc.

  • Page 17: Multi Monitor Feature

    VGA card to this motherboard. This motherboard also provides independent display controllers for DVI-D, D-Sub and HDMI to support multi VGA output so that DVI-D, D-sub and HDMI can drive same or different display contents.
  • Page 18 F. Set the “Screen Resolution” and “Color Quality” as appropriate for the second monitor. Click “Apply” or “OK” to apply these new values. G. Repeat steps C through E for the diaplay icon identified by the number one, two and three.
  • Page 19 - such as a computer, DVD player or set-top box - and the digital display, or receiver - such as a monitor, television or projector. In other words, HDCP specification is designed to protect the integrity of content as it is being transmitted.

  • Page 20: Jumpers Setup

    2-pin jumper (see p.2 No. 16) Note: CLRCMOS1 allows you to clear the data in CMOS. The data in CMOS includes system setup information such as system password, date, time, and system setup parameters. To clear and reset the system parameters to default setup, please turn off the computer and unplug the power cord from the power supply.

  • Page 21: Onboard Headers And Connectors

    FDD connector (33-pin FLOPPY1) (see p.2 No. 23) the red-striped side to Pin1 Note: Make sure the red-striped side of the cable is plugged into Pin1 side of the connector. Primary IDE connector (Blue) (39-pin IDE1, see p.2 No. 8)
  • Page 22 (see p.2 No. 25) control of audio devices. 1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly. Please follow the instruction in our manual and chassis manual to install your system.
  • Page 23 Though this motherboard provides 4-Pin CPU fan (Quiet Fan) support, the 3-Pin CPU fan still can work successfully even without the fan speed control function. If you plan to connect the 3-Pin CPU fan to the CPU fan connector on this motherboard, please connect it to Pin 1-3.
  • Page 24 (see p.2 No. 7) Though this motherboard provides 24-pin ATX power connector, it can still work if you adopt a traditional 20-pin ATX power supply. To use the 20-pin ATX power supply, please plug your power supply along with Pin 1 and Pin 13.

  • Page 25: Installation

    STEP 3: Connect one end of the SATA data cable to the motherboard’s SATAII tion connector. STEP 4: Connect the other end of the SATA data cable to the SATA / SATAII hard disk. Driver Installation Guide Driver Installation Guide...

  • Page 26: Bios Information

    ROM drive. It will display the Main Menu automatically if “AUTORUN” is enabled in your computer. If the Main Menu does not appear automatically, locate and double- click on the file “ASSETUP.EXE” from the BIN folder in the Support CD to display the menus.
  • Page 27 Wir danken Ihnen für den Kauf des ASRock G41MH-GE Motherboard, ein zuverlässiges Produkt, welches unter den ständigen, strengen Qualitätskontrollen von ASRock gefertigt wurde. Es bietet Ihnen exzellente Leistung und robustes Design, gemäß der Verpflichtung von ASRock zu Qualität und Halbarkeit.

  • Page 28: Spezifikationen

    Spezifikationen Spezifikationen Spezifikationen Spezifikationen Spezifikationen Plattform - Micro ATX-Formfaktor: 24.4 cm x 24.4 cm; 9.6 Zoll x 9.6 Zoll ® - LGA 775 für Intel Core 2 Extreme / Core 2 Quad / Core 2 Duo / Pentium ® Dual Core / Celeron ®...
  • Page 29 - 1 x HDMI port - 1 x optischer SPDIF-Ausgang - 4 x Standard-USB 2.0-Anschlüsse - 1 x RJ-45 LAN Port mit LED (ACT/LINK LED und SPEED LED) - HD Audiobuchse: Lautsprecher seitlich / Lautsprecher hinten / Mitte/Bass / Audioeingang/ Lautsprecher vorne / Mikrofon (siehe VORSICHT 8) Anschlüsse...
  • Page 30 Beachten Sie bitte, dass Overclocking, einschließlich der Einstellung im BIOS, Anwenden der Untied Overclocking-Technologie oder Verwenden von Overclocking-Werkzeugen von Dritten, mit einem gewissen Risiko behaftet ist. Overclocking kann sich nachteilig auf die Stabilität Ihres Systems auswirken oder sogar Komponenten und Geräte Ihres Systems beschädigen.
  • Page 31 Information. 1080p Blu-ray (BD)/HD-DVD Playback Unterstützung auf dieser Hauptplatine fordert die passende Hardwarekonfiguration. Bitte verweisen Sie auf Seite 10 für minimal Hardware Anforderung und die überschritten 1080p Blu-ray (BD)/HD-DVD Filme in unserem Laborversuch. Der Mikrofoneingang dieses Motherboards unterstützt Stereo- und Mono- Modi.
  • Page 32 USB-Flash-Laufwerk oder die Festplatte das Dateisystem FAT32/16/12 benutzen muss. 14. Allein der Name – OC DNA* – beschreibt es wörtlich, was die Software zu leisten vermag. OC DNA ist ein von ASRock exklusiv entwickeltes Dienstprogramm, das Nutzern eine bequeme Möglichkeit bietet, Übertaktungseinstellungen aufzuzeichnen und sie Anderen mitzuteilen.

  • Page 33: Einstellung Der Jumper

    +5VSB (Standby) zu setzen (siehe S.2 - No. 1) und die PS/2 oder USB- Weckfunktionen zu aktivieren. Hinweis: Um +5VSB nutzen zu können, muss das Netzteil auf dieser Leitung 2A oder mehr leisten können. CMOS löschen (CLRCMOS1, 2-Pin jumper) 2-Pin jumper (siehe S.2 - No.
  • Page 34 (33-Pin FLOPPY1) die rotgestreifte Seite auf Stift 1 (siehe S.2 - No. 23) Hinweis: Achten Sie darauf, dass die rotgestreifte Seite des Kabel mit der Stift 1- Seite des Anschlusses verbunden wird. Primärer IDE-Anschluss (Blauer) (39-pin IDE1, siehe S.2 - No. 8)
  • Page 35 Interne Audio-Anschlüsse Diese ermöglichen Ihnen Stereo-Signalquellen, wie z. B. (4-Pin CD1) CD-ROM, DVD-ROM, TV-Tuner (CD1: siehe S.2 - No. 24) oder MPEG-Karten mit Ihrem System zu verbinden. Anschluss für Audio auf Dieses Interface zu einem der Gehäusevorderseite Audio-Panel auf der Vorderseite Ihres Gehäuses, ermöglicht...
  • Page 36 Geräte), wobei jedoch die Bildschirmverdrahtung am Gehäuse HDA unterstützen muss, um richtig zu funktionieren. Beachten Sie bei der Installation im System die Anweisungen in unserem Handbuch und im Gehäusehandbuch. 2. Wenn Sie die AC’97-Audioleiste verwenden, installieren Sie diese wie nachstehend beschrieben an der Front-Audioanschlussleiste: A.
  • Page 37 Obwohl dieses Motherboard einen 24-pol. ATX-Stromanschluss bietet, kann es auch mit einem modifizierten traditionellen 20-pol. ATX-Netzteil verwendet werden. Um ein 20-pol. ATX-Netzteil zu verwenden, stecken Sie den Stecker mit Pin 1 und Pin 13 ein. Installation eines 20-pol. ATX-Netzteils Anschluss für...
  • Page 38 Erscheint der Wilkommensbildschirm nicht, so “doppelklicken” Sie bitte auf das File ASSETUP.EXE im BIN-Verzeichnis der Support-CD, um die Menüs aufzurufen. Das Setup-Programm soll es Ihnen so leicht wie möglich machen. Es ist menügesteuert, d.h. Sie können in den verschiedenen Untermenüs Ihre Auswahl treffen und die Programme werden dann automatisch installiert.

  • Page 39: Contenu Du Paquet

    1.1 Contenu du paquet 1.1 Contenu du paquet Carte mère ASRock G41MH-GE (Facteur de forme Micro ATX: 9.6 pouces x 9.6 pouces, 24.4 cm x 24.4 cm) Guide d’installation rapide ASRock G41MH-GE CD de soutien ASRock G41MH-GE Un câble ruban IDE Ultra ATA 66/100 80 conducteurs Un câbles de données de série ATA (SATA) (en option)
  • Page 40 - FSB1333/1066/800/533 MHz - Prise en charge de la technologie Hyper-Threading (voir ATTENTION 1) - Prend en charge la technologie Untied Overclocking (voir ATTENTION 2) - Prise en charge de la technologie EM64T par le CPU ® Chipsets - Northbridge: Intel ®...
  • Page 41 - 1 x port HDMI - 1 x Port de sortie optique SPDIF - 4 x ports USB 2.0 par défaut - 1 x port LAN RJ-45 avec LED (ACT/LED CLIGNOTANTE et LED VITESSE) - Prise HD Audio: Haut-parleur latéral / Haut-parleur arrière / Central /Basses / Entrée Ligne / Haut-parleur frontal /...
  • Page 42 - FCC, CE, WHQL - Prêt pour EuP (alimentation Prêt pour EuP requise) (voir ATTENTION 17) * Pour de plus amples informations sur les produits, s’il vous plaît visitez notre site web: http://www.asrock.com ATTENTION Il est important que vous réalisiez qu’il y a un certain risque à effectuer l’overclocking, y compris ajuster les réglages du BIOS, appliquer la technologie Untied Overclocking, ou...
  • Page 43 Avant d’installer le disque dur SATAII au connecteur SATAII, veuillez lire le Guide « Installation du disque dur SATAII » à la page 29 du « Manuel de l’utilisateur » qui se trouve sur le CD de support pour régler votre lecteur de disque dur SATAII au mode SATAII.
  • Page 44 Pour améliorer la dissipation de la chaleur, n’oubliez pas de mettre de la pâte thermique entre le CPU le dissipateur lors de l’installation du PC.
  • Page 45 (voir p.2 No. 1) (standby) et permettre aux périphériques PS/2 ou USB de réveiller le système. Note: Pour sélectionner +5VSB, il faut obligatoirement 2 Amp et un courant standby supérieur fourni par l’alimentation. Effacer la CMOS (CLRCMOS1, le cavalier à 2 broches le cavalier à...
  • Page 46 (FLOPPY1 br. 33) (voir p.2 No. 23) le côté avec fil rouge côté Broche1 Note: Assurez-vous que le côté avec fil rouge du câble est bien branché sur le côté Broche1 du connecteur. Connecteur IDE primaire (Bleu) (IDE1 br. 39, voir p.2 No. 8)
  • Page 47 En-tête USB 2.0 A côté des quatre ports USB 2.0 par défaut sur le panneau (USB6_7 br.9) E/S, il y a deux embases USB (voir p.2 No. 15) 2.0 sur cette carte mère. Chaque embase USB 2.0 peut (USB4_5 br.9) prendre en charge 2 ports USB (voir p.2 No.
  • Page 48 1. L’audio à haute définition (HDA) prend en charge la détection de fiche, mais le fil de panneau sur le châssis doit prendre en charge le HDA pour fonctionner correctement. Veuillez suivre les instructions dans notre manuel et le manuel de châssis afin installer votre système.
  • Page 49 (Ventilateur silencieux) ventilateur de CPU à 4 broches , le ventilateur de CPU à 3 broches peut bien fonctionner même sans la fonction de commande de vitesse du ventilateur. Si vous prévoyez de connecter le ventilateur de CPU à 3 broches au connecteur du ventilateur de CPU sur cette carte mère, veuillez le connecter...

  • Page 50: Informations Sur Le Cd De Support

    BIOS après le POST, veuillez redémarrer le système en pressant <Ctl> + <Alt> + <Suppr>, ou en pressant le bouton de reset sur le boîtier du système. Vous pouvez également redémarrer en éteignant le système et en le rallumant.

  • Page 51: Contenuto Della Confezione

    Grazie per aver scelto una scheda madre ASRock G41MH-GE, una scheda madre affidabile prodotta secondo i severi criteri di qualità ASRock. Le prestazioni eccellenti e il design robusto si conformano all’impegno di ASRock nella ricerca della qualità e della resistenza.
  • Page 52 1.2 Specifiche Specifiche Specifiche Specifiche Specifiche Piattaforma - Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm Processore - LGA 775 per Intel ® Core 2 Extreme / Core 2 Quad / Core ® ® ® Duo / Pentium...
  • Page 53 - 1 x Porta HDMI - 1 x Porta ottica SPDIF Out - 4 x porte USB 2.0 già integrate - 1 x porta LAN RJ-45 con LED (LED azione/collegamento e LED velocità) - Connettore HD Audio: cassa laterale / cassa posteriore / cassa...
  • Page 54 * Per ulteriori informazioni, prego visitare il nostro sito internet: http://www.asrock.com AVVISO Si prega di prendere atto che la procedura di overclocking implica dei rischi, come anche la regolazione delle impostazioni del BIOS, l’applicazione della tecnologia Untied Overclocking Technology, oppure l’uso di strumenti di overclocking forniti da terzi. L’overclocking può...
  • Page 55 Il supporto per riproduzione 1080p Blu-ray (BD) / HD-DVD sulla scheda madre richiede una corretta configurazione hardware. Prego fare riferimento alla pagina 10 per i requisiti minimi hardware e per il test 1080p Blu-ray (BD) / HD-DVD del nostro laboratorio.
  • Page 56 Flash USB o il disco rigido devono usare il File System FAT32/16/ 14. Il nome stesso del software – OC DNA – dice di cosa è capace. OC DNA, una utilità esclusiva sviluppata da ASRock, fornisce un modo comodo per registrare le impostazioni OC e condividerle con gli altri. Aiuta...
  • Page 57 Nota: CLRCMOS1 consente di pulire i dati nella CMOS. I dati nella CMOS includono informazioni del setup del sistema, come per esempio la password di sistema, la data, l’ora, e i parametri del setup di sistema. Per pulire I parametri di sistema e resettare ai parametri di default, spegnere il computer e scollegare l’alimentatore, poi collegare il jumper sul CLRCMOS1 per 5 secondi.
  • Page 58 (33-pin FLOPPY1) (vedi p.2 Nr. 23) Lato del Pin1 con la striscia rossa Nota: Assicurarsi che il lato del cavo con la striscia rossa sia inserito nel lato Pin1 del connettore. Connettore IDE primario (Blu) (39-pin IDE1, vedi p.2 Nr. 8)
  • Page 59 Collettore USB 2.0 Oltre alle quattro porte USB 2.0 predefinite nel pannello I/O, la (9-pin USB6_7) scheda madre dispone di due (vedi p.2 No. 15) intestazioni USB 2.0. Ciascuna intestazione USB 2.0 supporta due porte USB 2.0. (9-pin USB4_5) (vedi p.2 No. 17)
  • Page 60 1. La caratteristica HDA (High Definition Audio) supporta il rilevamento dei connettori, però il pannello dei cavi sul telaio deve supportare la funzione HDA (High Definition Audio) per far sì che questa operi in modo corretto. Attenersi alle istruzioni del nostro manuale e del manuale del telaio per installare il sistema.
  • Page 61 Sebbene la presente scheda madre disponga di un supporto per ventola CPU a 4 piedini (ventola silenziosa), la ventola CPU a 3 piedini è in grado di funzionare anche senza la funzione di controllo della velocità della ventola. Se si intende collegare la ventola CPU a 3 piedini al connettore della ventola CPU su questa scheda madre, collegarla ai piedini 1-3.
  • Page 62 BIOS; altrimenti, POST continua con i suoi test di routine. Per entrare il BIOS Setup dopo il POST, riavvia il sistema premendo <Ctl> + <Alt> + <Delete>, o premi il tasto di reset sullo chassis del sistema. Per informazioni più dettagliate circa il Setup del BIOS, fare riferimento al Manuale dell’Utente (PDF file) contenuto nel cd di...

  • Page 63: Contenido De La Caja

    ASRock. Esta Guía rápida de instalación contiene una introducción a la placa base y una guía de instalación paso a paso. Puede encontrar una información más detallada sobre la placa base en el manual de usuario incluido en el CD de soporte.
  • Page 64 1.2 Especificación Especificación Especificación Especificación Especificación Plataforma - Factor forma Micro ATX: 24,4 cm x 24,4 cm, 9,6” x 9,6” ® Procesador - LGA 775 para Intel Core 2 Extreme / Core 2 Quad / Core ® ® ® 2 Duo / Pentium Doble Núcleo / Celeron...
  • Page 65 - 1 x puerto de salida óptica SPDIF - 4 x puertos USB 2.0 predeterminados - 1 x Puerto LAN RJ-45 con LED (LED de ACCIÓN/ENLACE y LED de VELOCIDAD) - Conexión de audio: Altavoz lateral / Altavoz trasero / Central/Bajos / Entrada de línea / Altavoz frontal / Micrófono...
  • Page 66 ADVERTENCIA Tenga en cuenta que hay un cierto riesgo implícito en las operaciones de aumento de la velocidad del reloj, incluido el ajuste del BIOS, aplicando la tecnología de aumento de velocidad liberada o utilizando las herramientas de aumento de velocidad de otros fabricantes.
  • Page 67 Web site de Intel para la información más última. El apoyo de la reproducción de Blu-rayo de 1080p (BD) / HD-DVD en esta placa base requiere la configuración de hardware apropiada. Por favor refieren a la página 10 para el requisito mínimo de hardware y las películas de Blu-rayo de 1080p (BD) / HD-DVD pasado en nuestra prueba del laboratorio.
  • Page 68 ASRock Instant Flash. Ejecute esta herramienta y guarde el archivo correspondiente al sistema BIOS nuevo en su unidad flash USB, unidad de disco flexible o disco duro para poder actualizar el BIOS con sólo pulsar un par de botones, sin necesidad de preparar un disco flexible adicional ni utilizar complicadas utilidades de programación.
  • Page 69 3 para habilitar +5VSB (vea p.2, N. 1) (standby) para PS/2 o USB wake up events. Atención: Para elegir +5VSB, se necesita corriente mas que 2 Amp proveida por la fuente de electricidad. Limpiar CMOS (CLRCMOS1, jumper de 2 pins) jumper de 2 pins (vea p.2, N.
  • Page 70 (vea p.2, N. 23) la banda roja debe quedar en el mismo lado que el contacto 1 Atención: Asegúrese que la banda roja del cable queda situado en el mismo lado que el contacto 1 de la conexión. IDE conector primario (Azul) (39-pin IDE1, vea p.2, N.
  • Page 71 Cabezal USB 2.0 Además de cuatro puertos USB 2.0 predeterminados en el (9-pin USB6_7) panel de E/S, hay dos bases (ver p.2, No. 15) de conexiones USB 2.0 en esta placa base. Cada una de estas bases de conexiones (9-pin USB4_5) admite dos puertos USB 2.0.
  • Page 72 2. Si utiliza el panel de sonido AC’97, instálelo en la cabecera de sonido del panel frontal de la siguiente manera: A. Conecte Mic_IN (MIC) a MIC2_L.
  • Page 73 Si pretende enchufar el ventilador de procesador de 3 contactos en el conector del ventilador de procesador de esta placa base, conéctelo al contacto 1-3. Contacto 1-3 conectado Instalación del ventilador de 3 contactos...
  • Page 74 Para iniciar la instalación, ponga el CD en el lector de CD y se desplegará el Menú Principal automáticamente si «AUTORUN» está habilitado en su computadora. Si el Menú...
  • Page 75 Gratos por comprar nossa placa–mãe G41MH-GE, um produto confiável feito com ASRock um estrito controle de qualidade consistente. Com um excelente desempenho, essa placa é dotada de um projeto robusto que atende a ASRock de compromisso com a qualidade e durabilidade.
  • Page 76 1.2 Especificações 1.2 Especificações 1.2 Especificações 1.2 Especificações 1.2 Especificações Plataforma - Formato Micro ATX: 9,6 pol. x 9,6 pol., 24,4 cm x 24,4 cm ® - Socket Intel Dual Core Core 2 Extreme / Core 2 Quad / ®...
  • Page 77 - 1 x porta HDMI - 1 x porta óptica para saída SPDIF - 4 x portas USB 2.0 padrão - 1 x porta LAN RJ-45 com LED (LED ACT/LIG e LED VELOCIDADE) - HD Áudio Jack: Altifalante lateral / Altifalante traseiro /...
  • Page 78 AVISO Tenha em atenção que a operação de overclocking envolve alguns riscos, nomeadamente no que diz respeito ao ajuste das definições do BIOS, à aplicação da tecnologia Untied Overclocking ou à utilização de ferramentas de overclocking de terceiros. O overclocking pode afectar a estabilidade do seu sistema ou até...
  • Page 79 Em termos do microfone, esta placa-principal suporta ambos os modos estéreo e mono. Quanto à saída de áudio, esta placa-principal suporta os modos de 2, 4, 6 e 8 canais. Consulte a tabela na página 3 para uma ligação correcta.
  • Page 80 Veuillez noter que le lecteur flash USB ou le disque dur doit utiliser le système de fichiers FAT32/16/12. 14. O próprio nome do software – OC DNA diz-lhe literalmente aquilo de que é capaz. OC DNA, um utilitário exclusivo desenvolvido pela ASRock, proporciona uma forma conveniente para o utilizador gravar as definições OC e partilhar com outros.
  • Page 81 (veja a folha 2, No. 1) para PS/2 ou eventos de wake up na USB. Nota: Para escolher +5VSB, é preciso uma corrente de stand by de 2 A ou mais. Restaurar CMOS (CLRCMOS1, jumper de 2 pinos) jumper de 2 pinos (veja a folha 2, No.
  • Page 82 (FLOPPY 1, 33 pinos) (veja a folha 2, No. 23) o lado com listras vermelhas para o Pino 1 Nota: Certifique-se de que o lado com listras vermelhas no cabo seja conectado ao lado Pino 1 do conector. Conector primário (Azul) (IDE1 de 39 pinos, veja a folha 2, No.
  • Page 83 Estes conectores permitem que se receba entrada de (CD1 de 4 pinos) áudio em estéreo de fontes (CD1: veja a floha 2, No. 24) de áudio como CD-ROM, DVD-ROM, placa sintonizadora de TV ou placa MPEG. Conector Áudio do painel Esta é...
  • Page 84 Siga s instruções que aparecem no manual e no manual do chassis para instalar o sistema. 2. Se utilizar o painel de áudio AC’97, instale-o no cabeçalho de áudio do painel frontal, como a figura abaixo mostra: A. Ligue o Mic_IN (MIC) ao MIC2_L.
  • Page 85 (Ventoinha silenciosa), uma ventoinha de 3 pinos para CPU poderá funcionar mesmo sem a função de controlo de velocidade da ventoinha. Se pretender ligar uma ventoinha de 3 pinos para CPU ao conector de ventoinha do CPU nesta placa-mãe, por favor, ligue-a aos pinos 1-3.
  • Page 86 Se desejar acessar o Utilitário de Configuração do BIOS depois do POST, reinicie o sistema pressionando <Ctl> + <Alt> + <Del>, ou pressionando o botão de reinício no chassi do sistema. Para as informações detalhadas sobre o Utilitário de Configuração do BIOS, consulte o Manual do Usuário (arquivo PDF) no CD de suporte.
  • Page 87 ASRock G41MH-GE Motherboard...
  • Page 88 ® ® ® ® ® ® ® ® ® 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 ASRock G41MH-GE Motherboard...
  • Page 89 1 0 1 1 0 1 1 0 1 1 0 1 1 0 1 ASRock G41MH-GE Motherboard...
  • Page 90 ® “ ” ® ® ® ® ® 1 0 2 1 0 2 1 0 2 1 0 2 1 0 2 ASRock G41MH-GE Motherboard...
  • Page 91 “ ” “ ” ® ® 1 0 3 1 0 3 1 0 3 1 0 3 1 0 3 ASRock G41MH-GE Motherboard...
  • Page 92 1 0 4 1 0 4 1 0 4 1 0 4 1 0 4 ASRock G41MH-GE Motherboard...
  • Page 93 “ ” “ ” “ ” “ ” 1 0 5 1 0 5 1 0 5 1 0 5 1 0 5 ASRock G41MH-GE Motherboard...
  • Page 94 SATAII_1 SATAII_3 SATAII_2 SATAII_4 1 0 6 1 0 6 1 0 6 1 0 6 1 0 6 ASRock G41MH-GE Motherboard...
  • Page 95 1 0 7 1 0 7 1 0 7 1 0 7 1 0 7 ASRock G41MH-GE Motherboard...
  • Page 96 1 0 8 1 0 8 1 0 8 1 0 8 1 0 8 ASRock G41MH-GE Motherboard...
  • Page 97 1 0 9 1 0 9 1 0 9 1 0 9 1 0 9 ASRock G41MH-GE Motherboard...
  • Page 98 “ ” “ ” 1 1 0 1 1 0 1 1 0 1 1 0 1 1 0 ASRock G41MH-GE Motherboard...
  • Page 99 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 ASRock G41MH-GE Motherboard...
  • Page 100 ® ® ® ® ® ® ® ® ® 1 1 2 1 1 2 1 1 2 1 1 2 1 1 2 ASRock G41MH-GE Motherboard...
  • Page 101 1 1 3 1 1 3 1 1 3 1 1 3 1 1 3 ASRock G41MH-GE Motherboard...
  • Page 102 ® ® ® “ ” 1 1 4 1 1 4 1 1 4 1 1 4 1 1 4 ASRock G41MH-GE Motherboard...
  • Page 103 ® ® ® ® ® ® ® ® ® 1 1 5 1 1 5 1 1 5 1 1 5 1 1 5 ASRock G41MH-GE Motherboard...
  • Page 104 – 1 1 6 1 1 6 1 1 6 1 1 6 1 1 6 ASRock G41MH-GE Motherboard...
  • Page 105 1 1 7 1 1 7 1 1 7 1 1 7 1 1 7 ASRock G41MH-GE Motherboard...
  • Page 106 SATAII_1 SATAII_3 SATAII_2 SATAII_4 1 1 8 1 1 8 1 1 8 1 1 8 1 1 8 ASRock G41MH-GE Motherboard...
  • Page 107 1 1 9 1 1 9 1 1 9 1 1 9 1 1 9 ASRock G41MH-GE Motherboard...
  • Page 108 1 2 0 1 2 0 1 2 0 1 2 0 1 2 0 ASRock G41MH-GE Motherboard...
  • Page 109 1 2 1 1 2 1 1 2 1 1 2 1 1 2 1 ASRock G41MH-GE Motherboard...
  • Page 110 ® ® 1 2 2 1 2 2 1 2 2 1 2 2 1 2 2 ASRock G41MH-GE Motherboard...
  • Page 111 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 ASRock G41MH-GE Motherboard...
  • Page 112 ® ® ® ® ® ® ® ® ® 1 2 4 1 2 4 1 2 4 1 2 4 1 2 4 ASRock G41MH-GE Motherboard...
  • Page 113 1 2 5 1 2 5 1 2 5 1 2 5 1 2 5 ASRock G41MH-GE Motherboard...
  • Page 114 ® ® ® ® ® ® ® 1 2 6 1 2 6 1 2 6 1 2 6 1 2 6 ASRock G41MH-GE Motherboard...
  • Page 115 ® ® ® ® 1 2 7 1 2 7 1 2 7 1 2 7 1 2 7 ASRock G41MH-GE Motherboard...
  • Page 116 1 2 8 1 2 8 1 2 8 1 2 8 1 2 8 ASRock G41MH-GE Motherboard...
  • Page 117 SATAII_1 SATAII_3 SATAII_2 SATAII_4 1 2 9 1 2 9 1 2 9 1 2 9 1 2 9 ASRock G41MH-GE Motherboard...
  • Page 118 1 3 0 1 3 0 1 3 0 1 3 0 1 3 0 ASRock G41MH-GE Motherboard...
  • Page 119 1 3 1 1 3 1 1 3 1 1 3 1 1 3 1 ASRock G41MH-GE Motherboard...
  • Page 120 ® ® 1 3 2 1 3 2 1 3 2 1 3 2 1 3 2 ASRock G41MH-GE Motherboard...
  • Page 121 1 3 3 1 3 3 1 3 3 1 3 3 1 3 3 ASRock G41MH-GE Motherboard...
  • Page 122 1 3 4 1 3 4 1 3 4 1 3 4 1 3 4 ASRock G41MH-GE Motherboard...
  • Page 123 ® ® ® ® ® ® ® ® ® 1 3 5 1 3 5 1 3 5 1 3 5 1 3 5 ASRock G41MH-GE Motherboard...
  • Page 124 1 3 6 1 3 6 1 3 6 1 3 6 1 3 6 ASRock G41MH-GE Motherboard...
  • Page 125 ® ® ® ® ® ® ® 1 3 7 1 3 7 1 3 7 1 3 7 1 3 7 ASRock G41MH-GE Motherboard...
  • Page 126 ® ® ® ® 1 3 8 1 3 8 1 3 8 1 3 8 1 3 8 ASRock G41MH-GE Motherboard...
  • Page 127 1 3 9 1 3 9 1 3 9 1 3 9 1 3 9 ASRock G41MH-GE Motherboard...
  • Page 128 SATAII_1 SATAII_3 SATAII_2 SATAII_4 1 4 0 1 4 0 1 4 0 1 4 0 1 4 0 ASRock G41MH-GE Motherboard...
  • Page 129 1 4 1 1 4 1 1 4 1 1 4 1 1 4 1 ASRock G41MH-GE Motherboard...
  • Page 130 1 4 2 1 4 2 1 4 2 1 4 2 1 4 2 ASRock G41MH-GE Motherboard...
  • Page 131 ® ® ® 1 4 3 1 4 3 1 4 3 1 4 3 1 4 3 ASRock G41MH-GE Motherboard...

Table of Contents
