1.3 Motherboard Layout

1.3 Motherboard Layout 1.3 Motherboard Layout
1.3 Motherboard Layout 1.3 Motherboard Layout
1 2
1
PS2
PS2_USB_PWR1
Mouse
USB 2.0
T: USB2
B: USB3
USB 2.0
Top:
T: USB0
RJ-45
B: USB1
29
28
27
4Mb
26
BIOS
PCI
LAN
25
AUDIO
CODEC
24
JR1 JL1
CD1
AUDIO1
23 22
1 PS2_USB_PWR1 Jumper
2 ATX 12V Connector (ATX12V1)
3 775-Pin CPU Socket
4 North Bridge Controller
5 2 x 184-pin DDR DIMM Slots
(Dual Channel A: DDR1, DDR3; Blue)
6 2 x 184-pin DDR DIMM Slots
(Dual Channel B: DDR2, DDR4; Black)
7 Secondary IDE Connector (IDE2, Black)
8 Primary IDE Connector (IDE1, Blue)
9 FSB Select Jumper (FSB1)
10 South Bridge Controller
11 Primary Serial ATA Connector (SATA1)
12 Secondary Serial ATA Connector (SATA2)
13 Clear CMOS Jumper (CLRCMOS0)
14 Chassis Fan Connector (CHA_FAN1)
3 4
22.9cm (9.0 in)
Intel
865PE/865G
Chipset
AGP 8X
1.5V_AGP1
1
FSB1
PCI 1
7.1CH
PCI 2
ConRoe865PE
`
RoHS
PCI 3
CMOS
Battery
PCI 4
1 1
USB67
PCI 5 USB45
1
GAME1
IR1
FLOPPY1
21 20 19 18 17
15 System Panel Header (PANEL1)
16 Chassis Speaker Header (SPEAKER 1)
17 USB 2.0 Header (USB67, Blue)
18 Infrared Module Header (IR1)
19 USB 2.0 Header (USB45, Blue)
20 Floppy Connector (FLOPPY1)
21 Game Connector (GAME1)
22 Internal Audio Connector: CD1 (Black)
23 Front Panel Audio Header (AUDIO1)
24 JR1 / JL1 Jumpers
25 PCI Slots (PCI1- 5)
26 BIOS FWH Chip
27 AGP Slot (1.5V_AGP1)
28 ATX Power Connector (ATXPWR1)
29 CPU Fan Connector (CPU_FAN1)
5 6
7
8
9
Intel
ICH5
10
11
SATA
12
CLRCMOS0 13
SATA2
SATA1
USB2.0
14
PANEL 1
PLED PWRBTN
1 1
HDLED RESET
SPEAKER1
16 15
