SIDE COMFORT
assembly instructions 06/ 2021
combinations:
A
POUF + BACK
connectors:
bayonet connector
required:
A
ASSEMBLY POUF + BACK
Lift the BACK and slide in the bayonet connector
coming from above into its counterpart in the POUF.
It is recommended that the assembly is carried out
by two persons.
ZEITRAUM GmbH · Äußere Münchner Str.2 · D-82515 Wolfratshausen · Tel +49 (0)8171 - 418130 · Fax +49 (0)8171 - 418141 · info@zeitraum-moebel.de · www.zeitraum-moebel.de
B
POUF + BACKREST
/BACKREST ANGLE
M8 threaded screw + socket
- allen keys
- open-end wrench
C
BACKREST + BACKREST
suspension fitting
D
POUF + POUF
scissor-type connector
(fork + hook)
