Oriental motor 2TK3GN-AW2J Operating Manual

O P E R AT I N G M A N U A L
Torque Motors
Introduction
„ Before using the motor
Only qualified personnel of electrical and mechanical engineering should work
with the product.
Use the product correctly after thoroughly reading the section "Safety
precautions." In addition, be sure to observe the contents described in warning,
caution, and note in this manual.
The product described in this manual has been designed and manufactured to be
incorporated in general industrial equipment. Do not use for any other purpose.
Oriental Motor Co., Ltd. is not responsible for any damage caused through failure
to observe this warning.
If you have purchased a TMP-1, also refer to the operating manual for TMP-1.
Safety precautions
The precautions described below are intended to prevent danger or injury to the
user and other personnel through safe, correct use of the product. Use the product
only after carefully reading and fully understanding these instructions.
Handling the product without observing the
WARNING
instructions that accompany a "WARNING" symbol
may result in serious injury or death.
Handling the product without observing the
CAUTION
instructions that accompany a "CAUTION" symbol
may result in injury or property damage.
The items under this heading contain important
Note Note
handling instructions that the user should observe to
ensure safe use of the product.
• Do not use the product in explosive or corrosive environments, in the
presence of flammable gases, locations subjected to splashing water, or near
combustibles. Doing so may result in fire, electric shock or injury.
• Assign qualified personnel the task of installing, wiring, operating/controlling,
inspecting and troubleshooting the product. Failure to do so may result in fire,
electric shock or injury.
• Do not transport, install the product, perform connections or inspections when
the power is on. Always turn the power off before carrying out these operations.
Failure to do so may result in electric shock.
• Turn off the power in the event the overheat protection device (thermal
protector) is triggered. Failure to do so may result in injury or damage to
equipment, since the motor will start abruptly when the overheat protection
device (thermal protector) is automatically reset.
• The motor is Class I equipment. When installing the motor, be sure to ground it.
Failure to do so may result in electric shock.
• Install the motor in an enclosure in order to prevent electric shock or injury.
• Keep the input-power voltage within the specification to avoid fire and electric
shock.
• Connect the cables securely according to the wiring diagram in order to prevent
fire and electric shock.
• Do not forcibly bend, pull or pinch the lead wires. Doing so may result in fire
and electric shock.
• Be sure to insulate the connection terminal of the capacitor. Failure to do so
may result in electric shock.
• Turn off the power in the event of a power failure, or the motor will suddenly
start when the power is restored and may cause injury or damage to equipment.
• Do not touch the connection terminal of the capacitor immediately after the
power is turned off (for a period of 30 seconds). The residual voltage may cause
electric shock.
• Do not disassemble or modify the motor. This may cause electric shock or
injury.
HM-9208-8
WARNING
Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety
precautions.
• Please read it thoroughly to ensure safe operation.
• Always keep the manual where it is readily available.
• Do not use the motor beyond its specifications, or electric shock, injury or
damage to equipment may result.
• Do not touch the motor during operation or immediately after stopping. The
surface is hot and may cause a skin burn(s).
• Do not hold the motor output shaft or motor lead wires. This may cause injury.
• Keep the area around the motor free of combustible materials in order to
prevent fire or a skin burn(s).
• To prevent the risk of damage to equipment, leave nothing around the motor
that would obstruct ventilation.
• To prevent bodily injury, do not touch the rotating parts (output shaft) of the
motor during operation.
• Immediately when trouble has occurred, stop running and turn off the power.
Failure to do so may result in fire, electric shock or injury.
• The motor surface temperature may exceed 70 °C (158 °F)
even under normal operating conditions. If the operator is
allowed to approach a running motor, attach a warning label as
shown in the figure in a conspicuous position. Failure to do so
may result in skin burn(s).
CAUTION
Warning label
1
