Summary of Contents for Tradinco Metis
- Page 1 User manual Metis Version: 1.0.0 Date: 08-05-2024 TRADINCO INSTRUMENTS OFFERS THE BEST SOLUTION FOR EVERY TEST, MEASURING AND CALIBRATION CHALLENGE IN THE INDUSTRY. LONG-TERM COOPERATION CALIBRATION SPECIALISTS CUSTOMER-ORIENTED BROAD PORTFOLIO...
-
Page 2: Table Of Contents
4.7 AutoCal+ communication ..................23 5 Specifications .................... 24 5.1 P-module ........................25 5.2 VI-module ......................... 25 5.3 LEM-module ......................26 Tradinco Instruments | Radonstraat 250 | 2718 TB | Zoetermeer | The Netherlands +31 792033130 | sales@tradinco.com | www.tradinco.com... -
Page 3: General Information
Implementation of modifications to the product that are not supplied or implemented by TRADINCO INSTRUMENTS. TRADINCO INSTRUMENTS and its vendors will not be liable for any indirect, special, incidental or consequential damages irrespective of whether TRADINCO INSTRUMENTS or the vendor has advance notice of the possibility of such damages. -
Page 4: Introduction
Power over Ethernet (POE) capabilities, connecting and managing your measurement modules is a breeze. Whether you're just starting out or looking to expand your current system, Metis has you covered. Try it out today and experience the precision and convenience of Metis for yourself. -
Page 5: Product Overview
Product overview Main module Every Metis system is built up with a Main module and one or multiple measurement units. Measurement modules 2.2.1 P-module There is a series of pressure measurement modules available for the Metis product family. All available measurement ranges can be found in the specifications section. - Page 6 +30VDC and a current range of -24mA to +24mA. The +wire can be connected to the Vin connector. The -wire can be connected to the mA in connector. Tradinco Instruments | Radonstraat 250 | 2718 TB | Zoetermeer | The Netherlands +31 792033130 | sales@tradinco.com | www.tradinco.com...
- Page 7 The power- can be connected to the Com connector. The Signal- can be connected to the mA in connector for current measurement. Tradinco Instruments | Radonstraat 250 | 2718 TB | Zoetermeer | The Netherlands +31 792033130 | sales@tradinco.com | www.tradinco.com...
-
Page 8: Lem-Module
If a LEM-module is connected to Metis, all 3 parameters will be shown in the main screen in the left bottom corner. They can be selected to view a trend over the past period. -
Page 9: Interfaces
Removing power without shutdown procedure may damage your product. Ethernet private The private ethernet port is used to connect Metis measurement modules. It is a separate network connection that is isolated from the public interface. The private ethernet port must be connected to the POE switch in order to power the measurement modules, as the port itself does not have POE capabilities. -
Page 10: Ethernet Public
Ethernet public The Metis main module can be connected to a company network or directly to a dedicated computer. Doing so will enable you to connect Metis to AutoCal+ to perform automatic calibrations. network settings need to be set before the interface can be used. Futhermore communication via port 2001 is required for communication between Metis en AutoCal+. -
Page 11: Usb Front
Every Metis main module has a built-in POE switch that allows you to connect up to 7 Metis measurement modules. All the ports on the switch are the same, so it doesn't matter which one you use. If you have an additional POE switch installed, you can connect it to the first POE switch using a network cable. -
Page 12: Hdmi
HDMI A HDMI port is available at the back of the device. It can be used to connect an external monitor. The content of the Metis main screen will be duplicated on the external monitor. To use HDMI for mirrored output, you will need the following: 1. -
Page 13: Operational Instructions
Measurement screen explained Tradinco Instruments | Radonstraat 250 | 2718 TB | Zoetermeer | The Netherlands +31 792033130 | sales@tradinco.com | www.tradinco.com... -
Page 14: Modules
The modules menu button brings you to an overview of all connected modules. 4.2.1 Connecting modules Connecting measurement modules to Metis is as simple as connecting an Ethernet cable to the built-in switch and waiting for it to be automatically found. Once found, a popup up will appear. -
Page 15: Module Settings
3 module connected to Metis 4.2.2 Module settings The module settings can be viewed via 3 ways. 1. When the module is connected and recognized by the Metis main module through the identification popup 2. By clicking on the module in the module overview 3. -
Page 16: Sequences
Loop supply Enable/disable of the loop sypply Sequences Metis offers the functionality tot create test or calibration sequences. These are pre- configured sequences that can repeatedly be executed. This allows procedures to be consistently ran which improves quality. The sequences menu can be entered using the sequence button on the home screen. - Page 17 Sensor A sensor measures the output value of device under test. A connected sensor module can be selected. This can for example be a pressure input from a Metis P-module. Manual Manual input of values is available for both actuator and sensor. Check the manual box for manual operation.
-
Page 18: Logs
The log can be viewed by pressing on in the overview window. Tradinco Instruments | Radonstraat 250 | 2718 TB | Zoetermeer | The Netherlands +31 792033130 | sales@tradinco.com | www.tradinco.com... - Page 19 Note that exporting is only available to thumb drives. A thumb drive is available when the thumb drive icon is shown in the bottom menu bar. Tradinco Instruments | Radonstraat 250 | 2718 TB | Zoetermeer | The Netherlands +31 792033130 | sales@tradinco.com | www.tradinco.com...
-
Page 20: Settings
Metis can automatically synchronise date and time with a timeserver. This is possible when Metis is connected to the factory network using the public ethernet port. Access to an NTP time server is required. Metis uses a default pool of time servers and configuration of local time servers is not possible. -
Page 21: Custom Units
4.5.3 Custom units Metis features a long list of standard units which covers most needs. A custom unit can be used in case your unit is not listed as standard. Custom units can be used to visualize real time values from a module but can also be used when running sequences. -
Page 22: Network
4.5.4 Network The public ethernet interface can be used to connec to the factory network or single computer. Network settings need to be configured for Metis to communicate over the ethernet. There are 2 options available. 1. Setting up network settings via DHCP: DHCP allows Metis to automatically obtain an IP address and other network settings, such as the subnet mask, default gateway, and DNS servers, from a DHCP server. -
Page 23: Autocal+ Communication
When logged in to AutoCal+ a popup will appear in the bottom right corner when a Metis device is found or when a new module is connected to Metis. Simply click the button in the popup to start the process of adding your Metis device. -
Page 24: Specifications
Compiance EMC directive EN 61326-1 emission (group 1, class A) and immunity Low voltage directive EN 61010-1 Low voltage installations NEN-3140 Tradinco Instruments | Radonstraat 250 | 2718 TB | Zoetermeer | The Netherlands +31 792033130 | sales@tradinco.com | www.tradinco.com... -
Page 25: P-Module
Width 91.4mm | 18TE Height 133.3mm | 3HE Depth 235mm Weight Approx. 0.8 kg Measurement Voltage measurement -30 ÷ 30 VDC Tradinco Instruments | Radonstraat 250 | 2718 TB | Zoetermeer | The Netherlands +31 792033130 | sales@tradinco.com | www.tradinco.com... -
Page 26: Lem-Module
Environmental conditions Operating ambient temperature 0 ÷ 40 °C Operating ambient humidity 0 ÷ 95 %RH non condensing Tradinco Instruments | Radonstraat 250 | 2718 TB | Zoetermeer | The Netherlands +31 792033130 | sales@tradinco.com | www.tradinco.com...
