indicator light
1
2 touch screen
Knob switch
3
4
5
control panel
Photoelectric
6
Feeding belt
7
8 Weighing belt
9
10
2.2

Mechanical installation

Place the weighing scale at the installation place and remove the sensor protection
device;Adjust the levelness of the weighing scale, and the inclination shall not exceed 0.5
degree;Fix the footing of the weighing scale, the stainless steel footing contacts the ground
smoothly, and lock the screws of the footing to ensure the stability of the weighing scale.
Adjust the distance between the check weighing platform and the front and rear end
conveying mechanism is 9 ~ 11mm, and the check weighing platform shall not be in
contact with other equipment.If the front and back end conveying mechanism is not equal
to the height, it is necessary to add the oblique conveying mechanism on one side, and add
the horizontal conveying mechanism connection on the side of the oblique mechanism (to
leave a gap) to check the weight scale platform, to ensure that the check weight scale
platform level and the height of the front and back end conveying mechanism.
The electric control box can be arbitrarily installed on the left and right sides of the
weighing scale to facilitate the operation of the production process.
More intuitive display of the weight inspection
results, allowing the status of the results to be
seen from a distance.
View display data and set product parameters
Turn on/off the power supply of the weighing
scale for inspection
Emergency Pressing this button in an emergency situation
stop button can immediately stop the motor from running
Electric Control the weight inspection process and
connect external devices
Judge the weight table of the object up and
sensor down
Transport the measured object into the weighing
platform
Weighing platform for the measured object
protection Reduce interference from external environment
cover symmetry accuracy.
Prevent sliding and vibration of the weighing
Peduncle
scale, and adjust the level of the weighing table.
