1. Summary
CW-3K standard weighing scale is a high speed, high precision and small range
industrial automatic weighing scale developed by our company to meet the changing
technological update.
The full touch screen makes the CW-3K weighing scale easy to operate, external
expansion of IO input and output and external serial port communication to achieve multi-
point control, monitoring and remote control of the product.
1.1

Product Features

Product parameters：
Model number
Power Supply
Weighing range
Accuracy of weight inspection
Weight checking speed
Size of object to be measured
Conveyor belt speed
Belt size
Center distance of drum shaft
Countertop height
Operating temperature
Maximum humidity
Ultimate load
Note;Scale stands are strictly prohibited from being used over the range.
AC220V± 10%, 50/60Hz, 1200W
Length: 100~320mm Width: 50~3400mm Height:
750 (± 50mm) (customizable)
90% R.H non-dew forming
The instantaneous ultimate load shall not exceed 10kg
1
CW-3K
0.3 to 3kg
± 0.5~1.5 g
150 pieces/min
50~300mm
10 to 90 m/min
400mm*300mm
400mm
0 to 40º C
