Electrical Interface - General Measure CW-3K User Manual

Serial
number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
2.4

Electrical interface

Photoelectric sensor (already wired at factory) :
E24V: photoelectric sensor DC24V+.
E0V: photoelectric sensor DC24V-.
E1: Signal input of photoelectric sensor for loading of weighing scale.
E2: Check the output photoelectric sensor signal input of the weight balance.
Alarm light (has been connected when leaving the factory) :
L24V: Alarm light DC24V+, maximum output power 2VA.
L1: Buzzer.
Touch screen communication jack
External custom outlet OUT1-OUT4
External custom output relay K1-K8
Detect the photoelectric sensor wiring terminals
Alarm light wiring terminals
Custom input ports 1-6 externally
Sensor terminal
External RS-485 communication jack
External TCP/IP communication network port
Inverter communication jack
External USB data interface
24V power terminal
Reset key
Communication status indicator
Output relay status indicator light
