1/100-second chronograph

Advertisement

Quick Links

7T82
お客様相談窓口 〔全国フリーダイヤル〕 0120-612-911
東 京
101
-
0044  東京都千代田区鍛冶町
大 阪

550
-
0013
 大阪市西区新町
1-4-24

BSB7T82-A0607
http://www.seiko-watch.co.jp/
(下記の最寄地に着信いたします)
http://www.seiko-watch.co.jp/
お客様相談室
2-1-10

大阪 四ツ橋新町ビルディング
8階
I N S T R U C T I O N S
1/100-SECOND
1/100秒   ク ロノ グラフ
この度は弊社製品をお買い上げいただき、
誠にありがとうございました。
ご使用の前にこの説明書をよくお読みの上
正しく ご愛用くださいますよう、 お願い申し上げます。
なお、 この説明書はお手元に保管し必要に応じてご覧ください。
※  お買い求めの際の金属バン ドの調整は
お買い上げ店・弊社お客様相談窓口
(裏表紙に記載) にて承っており ますが、
その他のお店では有料も し く はお取扱
いいただけない場合があり ます。
G-4
※ 保証期間内でも電池交換は
  有料とな り ます。

お買い上げの時計には検査用のモニター
電池が入っています。所定の年数よりも
早めに電池が切れるこ とがあ り ます。

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Seiko G-4

  • Page 1 7T82 BSB7T82-A0607 http://www.seiko-watch.co.jp/ I N S T R U C T I O N S お客様相談窓口 〔全国フリーダイヤル〕 0120-612-911 (下記の最寄地に着信いたします)   1/100-SECOND http://www.seiko-watch.co.jp/ お客様相談室  1/100秒   ク ロノ グラフ  東 京  〒 0044  東京都千代田区鍛冶町  2-1-10 大 阪      〒 0013  大阪市西区新町  1-4-24 大阪 四ツ橋新町ビルディング...
  • Page 2: Table Of Contents

    取扱いを誤った場合に、 重傷を負 う などの重大な  取扱いを誤った場合に、 軽傷を負 う危険性や物質的  警告  注意  結果になる危険性が想定さ れるこ と を示します。   損害を こ う むるこ とが想定さ れるこ と を示します。   以下の場所での携帯 ・ 保管は避けてください  時計から電池を取り出さないでください  注  意  ○  揮発性の薬品が発散している と ころ (除光液などの化粧品 ・ 防虫剤 ・ シンナーなど)   警  告  ○  5℃〜35℃か...
  • Page 3: 各部の名称

    特長  各部の名称  ストップウオッチ1/10秒針  ストップウオッチ1/100秒針  ボタン  時 針  この時計は、 基本時計とス トップウオッチ機能を備えたアナログ時計です。   分 針  ●基本時計は、 時 ・ 分 ・ 小秒針で表示します。   小秒針  ●ス ト ッ プウオ ッチは、 専用の針 (1/100秒、 1/10秒、 秒、 分) で表示する1/100秒単位での計測 りゅうず  2 段目  が可能な40分計です。   (時刻合わせ、 針位置合わせ)   ストップ ...
  • Page 4 ●時刻の合わせかた (基本時計)    ②りゅうずを回して、 「基本時計」 の時刻を合わせます。          ①りゅうずを2段目まで引き出してください。 小秒針が止まります。 小秒針は12   時の位置に止めてください。           2段目      り ゅ う ず            このと き合わせる時刻は、 今か ら数分後の時刻に合わせるこ と をお勧め します。    ...
  • Page 5: 日付の合わせかた

    日付の合わせかた  ストップウオッチの使いかた  ・時刻合わせができてか ら、 日付を合わせて く ださい。   ○1/100秒単位40分計のス トップウオッチです。 2時間作動後、 自動的にス トップ ・1ヶ 月が31日でない=小の月 (2, 4, 6, 9, 11月) の翌月のは じめに、 日付を合わせ直すと きに行な します。   います。   ○12時位置の1/10秒針、 1/100秒針、 センターの秒針と6時位置の分針で読み ①りゅうずを 1 段目まで、 引き出してください。   取ります。     ○スプリッ ト機能があります。    ...
  • Page 6 ●通常の使用方法  ●ス トップウオッチのリセッ ト方法    ボタン   ボタン   ボタン   ・ス ト ッ プウオ ッ チ針が動いている場合、   →  →   ボタ ンA   スター ト  ス トップ  リセッ ト   ①ボタ ンAでス ト ッ プ  ●時間計測を積算で行なう場合   ②ボタ ンBで リ セ ッ ト   ...
  • Page 7: 電池交換後のお願い (システムリセット

    電池交換後のお願い (システムリセット )   製品仕様  電池交換後または、 万一異常な動きになった場合、 以下の操作を行って く ださい。 時計内部が 1. 水晶振動数 ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・   32,768Hz  2. 精度 ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・   平均月差±15秒 ...
  • Page 8: アフターサービスについて

    アフターサービスについて  修理用部品について  オーバーホール について  (分解掃除) ○  この時計の修理用部品の保有期間は通常7年間を基準と しています。   時計は精密機械です。  部品の油切れや磨耗によ り止ま り遅れが生じ るこ とがあ り ます。   その際にはオーバーホールを ご依頼く ださい。 オーバーホールの際にはパッ キンやバネ棒の   修理の際、 一部代替部品を使用させていただ く こ とがあ り ますのでご了承く ださい。   ○ 交換もご依頼く ださい。   電池交 換について  保証と修理について   電池交換はお買い上げ店 ・ 弊社お客様相談窓口にご依頼く ださい。    ○...
  • Page 9: お手入れについて

    時計の裏ぶたでも性能と型式の確認ができます   お手入れについて  防水性能  日頃からこまめにお手入れしてください     水分や汗、 汚れはこまめに柔らかい布で拭き取るよ うに心掛けて く ださい。   ○  すきま (金属バン ド、 り ゅ う ず周り、 裏ぶた周り など) の汚れは柔らかい歯ブラシが有効です。    ○ 耐磁性能  耐磁性能   海水に浸けた後は、 必ず真水でよ く洗ってか ら拭き取って く ださい。   ○    その際、 直接蛇口か ら水をかけるこ とは避け、 容器に水をためるなど してか ら洗って く ださい。    ...
  • Page 10: 耐磁性能について (磁気の影響

    警告  注意  この時 計はスキューバダイビングや飽和潜水には  水や汗、 汚れが付着したままにしておくのは避けて下さい  絶対に使用しないで下さい    防水時計でもガラスの接着面 ・ パッ キンの劣化や、   (気圧) 表示防水時計はスキューバダイ ビングや飽和潜水用 ステンレスが錆びるこ とによ り、 防水不良になる恐れがあ り ます。   の時計に必要と さ れる苛酷な環境を想定した様々な厳しい検査を 行っていません。  専用のダイバーズウオ ッ チを ご使用下さい。   入浴やサウナの際はご使用を避けてください  注意  蒸気や石けん、 温泉の成分などが防水性能の劣化を早めて しま う か らです。   ※ 万一、...
  • Page 11: バンドについて

    バンドについて   ○ 時計本体が日常生活強化防水 (10気圧防水) になっている ものでも、 アクアフ リ ーバン    バンド は直接肌に触れ、 汗 やほこりで汚れます。   ド 以外の皮革バン ドは、 入浴中や水泳、 水仕事などでのご使用はお控え く ださい。     そのため、 手入れが悪いとバン ドが早く傷んだり、   肌のかぶれ ・ そで口の汚れなどの    原因になります。   長 くお使いになるためには、 こまめなお手入が必要です。   ポリウレタンバンド  金...
  • Page 12 Bワンプッシュ三ツ折中留 (皮革バンド、 メタルバンド) の使い方  1 時計の着脱方法  2 バンドの長さ調整方法  1)両方のプッシュボタンを押しながら  2)バンドの剣先(先端)を定革・遊革 1)両方のプッシュボタンを押しながら  2)もう一度プッシュボタンを押し上箱    バンドを定革・遊革から抜いて、中  に入れてから、上箱の上面位置をし   バンドを定革・遊革から抜いて、中    を下に開きます。    留を開きます。  っかり押さえ留めます。    留を開きます。  プッ シュボタン  定革  プッ シュボタ ン  定革  遊革  上箱  遊革  上箱  ※メ タルバン ドの場合は、 定革がないものがご ざいます。   Cワンプッシュ三ツ折中留 (皮革バンド専用) の使い方    3)ピンをバンドのアジャスト穴から外...
  • Page 13: 使用電池・電池寿命・精度について

    ルミブライ トについて    使用電池・電池寿命・精度について  機 種は裏ぶたでご確認 いただけます。   〔お買い上げの時計がルミブライ トつきの場合〕   ( 「 お手入れについて」 をご覧ください)   ルミブライ トは、 放射能等の有害物質を全く含んでいない、 環境 ・ 人に安全な畜光 (蓄 えた光を放出する) 物質です。   使用電池  電池  精度  型式番号の前4桁  機種  平均  ( )   (例 : 7T82-0AC0)   寿命  ルミブライ トは、 太陽光や照明器具の明かりを短時間 (10分間 : 500ルクス以上) 月差 ...
  • Page 14 Thank you very much for choosing a SEIKO watch.  For proper and safe use of your SEIKO watch,   please read carefully the instructions   in this booklet before using.  Keep this manual handy for easy reference. ※Battery  replacement  is  at  cost  ※Length  adjustment  service  for  metallic  bands  is  available  at  the  retailer  from  even  within  the  guarantee  whom  the  watch  was  purchased  or  period.  SEIKO CUSTOMER SERVICE CENTER  The  battery  in  the  watch  at  the  time  of ...
  • Page 15: How To Use

    CONTENTS HOW TO USE Features  Names of the parts  Setting the time and adjusting the STOPWATCH hand position  How to set the date  How to use the stopwatch  Demonstration function of the STOPWATCH hand movement  HOW TO USE Necessary procedure after battery change  Specifications TO PRESERVE THE QUALITY OF YOUR WATCH After-sale service  Guarantee  Daily care  Water Resistance  Magnetic resistance (affect of magnetic field)   Band (maintenance procedure)    Special Clasps  Battery/Battery life/Accuracy  Lumibrite  Trouble shooting Features Names of the parts STOPWATCH 1/10-seond hands STOPWATCH 1/100-seond hands TIME/CALENDER  Hour   Hour, minute and small second hands  Minute  Hand STOPWATCH  Hand ButtonA ・40-minute measurement in 1/100-second increments  Small  Second ...
  • Page 16: Setting The Time And Adjusting The Stopwatch Hand Position

    Check the type of the crown of your watch Setting the time and adjusting the STOPWATCH hand position The crown  ●This watch is designed so that the following adjustments are made with the crown  turns. The crown of your watch  at the second click position:  is *the screw lock type.    ・  time setting  To set the watch   ・  STOPWATCH hand position adjustment  Turn the   Go to   Unscrew the crown by turning   Once the crown is pulled out to the second click, be sure to make both the above  crown   "Instructions  it counterclockwise. adjustments at the same time. The crown   clockwise. for use"  does not turn. Unscrew. STOPWATCH  second hand STOPWATCH  1/10-second hand STOPWATCH  1/100-second hand Screw up. ※This type of crown can be screwed into the watch body to avoid being pulled out   Crown Hour hand  by mistake.  ○  ...
  • Page 17: How To Set The Date

     ⑤Press button  A  for 2 seconds.   ③Reset the two STOPWATCH hands to "0" position.   The STOPWATCH minute hand turns a full circle.  Press  Button    for  2  seconds.    The    Press button   repeatedly to reset the STOPWATCH minute hand to "O" position.  STOPWATCH  1/10-  second  and  1/100- ButtonA   It moves quickly if button   is kept pressed.  second hands turns a full circle.    ButtonA ※STOPWATCH  minute  hand  turns  a  full  circle  passing  the  40-ninute  marker  Press  button    repeatedly  to  reset  the   ...
  • Page 18 <Remarks on the STOPWATCH minute hand movement>  <How to read the STOPWATCH hands>  ・When  the  minute  counting  reaches  40  minutes,  the  STOPWATCH  minute  hand  The time measured is indicated by the four  STOPWATCH 1/100-second hand  immediately  returns  and  continues  counting  from  41  minutes  onward.  The  minute  STOPWATCH hands below. STOPWATCH 1/10-second hand counting is repeated in the same manner for another rotation, up to 120 minutes, at  STOPWATCH second hand that time the stopwatch automatically stops.  ・The final position of the STOPWATCH minute hand, after completing 120 minutes  STOPWATCH minute hand of counting, is illustrated below. Reading the 1/100-second and  10 minutes 12 seconds 82 (10'12"82) 1/10-second  hands  requires  *The  display  illustrated  at  the  left  extra attention.
  • Page 19: Demonstration Function Of The Stopwatch Hand Movement

    Demonstration function of the STOPWATCH hand movement ● How to use the tachymeter ( For the models with a tachymeter scale on the dial)   ・The demonstration function allows you to view the movement of the four STOPWATCH hands.    ○The tachymeter can be used to measure the hourly average speed of a vehicle  ・Each  of  the  four  STOPWATCH  hands  demonstrates  high-speed  movements  and     and the hourly rate of operation. when the demonstration is finished, they return to the original position.    To measure the hourly average speed of a vehicle To measure the hourly rate of operation ● How to view the demonstration    START STOP START STOP 1. Reset the stopwatch.      ※Refer to "How to use the stopwatch"          section of this manual.  2. Press Button   for 2 seconds or longer. ButtonB One product ①Use  the  stopwatch  to  determine  how  ①Use ...
  • Page 20: To Preserve The Quality Of Your Watch

    TO PRESERVE THE QUALITY OF YOUR WATCH After-sale service Repair parts Notes on overhaul  The repair parts of this watch will be retained usually for 7 years.  ○ The watch is a precision device. If the parts run short of the oil or get worn out,   the watch may stop its operation or lose time. In such a case, have the watch    Some alternative parts may be used for repair if necessary. ○ overhauled. In the case of overhaul, be sure to have the gasket and push-pin   replased with new ones. Battery replacement Notes on guarantee and repair  Contact the retailer from whom the watch was purchased or SEIKO CUSTOMER   ○  SERVICE CENTER to have the battery replaced with a new one.    It is recommended to exchange the gasket at the same time to maintain the water    Contact the retailer the watch was purchased from or SEIKO CUSTOMER   ○  resistant performance.   SERVICE CENTER for repair or overhaul.   Battery replacement will be at cost even within the guarantee period.  ○  Within the guarantee period, present the certificate of guarantee to receive repair services.  ○  For a water resistant watch with 10 BAR or above, a water resistant performance   ○  Guarantee coverage is provided in the certificate of guarantee. Read carefully and retain it. ○  check is also recommended.   Please note that it may take some days to conduct the check.   If the watch runs down on a new battery, it requires an overhaul. ○...
  • Page 21: Guarantee

    The certificate of guarantee is valid only in Japan.   Procedure to claim free repair services Guarantee coverage   ○ For any defects under guarantee, submit the watch together with the attached     ○ The watch body (movement・case) and metallic band.    certificate of guarantee to the retailer from whom the watch was purchased.  In following cases, repair/adjustment services will be at cost even   Exceptions from guarantee   ○ If repair services cannot be provided by the retailer from whom the watch was   within the guarantee period or under guarantee coverage.    purchased, contact SEIKO CUSTOMER SERVICE CENTER.  In this case,     ○ Battery replacement and change of leather/urethane/cloth band     the attached certificate of guarantee is also needed.   ○ Troubles or damage caused by accidents or improper usage  Others   ○ Scratches or grime caused by use    ○ The case, dial, hands, glass and bracelet, or parts thereof may be repaired with substitutes     ○ Problems  and damage caused by acts of god, natural disasters including fire,  ...
  • Page 22: Water Resistance

    10(20) barometric pressures. WARNING  CAUTION Do not use the watch in scuba diving or   Do not leave moisture, sweat and dirt on the     saturation diving.   watch for a long time. The various tightened inspections under simulated harsh environment, which are  Be aware of a risk that a water resistant watch may lessen its water   usually required for watches designed for scuba diving or saturation diving, have  resistant performance because of deterioration of the adhesive on   not  been  conducted  on  the  water-resistant  watch  with  the  BAR  (barometric  the glass or gasket, or the development of rust on stainless steel.  pressure) display. For diving, use special watches for diving. Do not wear the watch while taking a bath or a sauna.  CAUTION Steam, soap or some components of a hot spring may accelerate the   ※ If the inner surface of the glass is clouded with condensation or water droplets appear   deterioration of water resistant performance of the watch.   inside of the watch for a long time, the water resistant performance of the watch is     deteriorated. Immediately consult the retailer from whom the watch was purchased or   Do not pour running water directly from faucet.    SEIKO CUSTMER SERVICE CENTER (listed on the back cover). Do not turn or pull out the crown when the   The water pressure of tap water from a faucet is high enough to   degrade the water resistant performance of a water resistant watch   watch is wet.  for everyday life. Water may get inside of the watch.
  • Page 23: Band (Maintenance Procedure

    Magnetic resistance Examples of common magnetic products that may affect watches (affect of magnetic field)   Affected by nearby magnetism,   a quartz watch may temporarily gain or lose time or stop operating. Cellular phone    Magnetic health belt  (speaker) ※This defective condition caused by magnetism will be corrected soon after the watch is    removed from the magnetic source. Reset the time once again before using the watch. Magnetic necklace   (with magnet buckle)  Indication on the case back Condition of use AC-powered shaver   Magnetic health mat  Keep the watch more than 10 cm away from   No indication Portable radio  Magnetic health pillow  magnetic products. (speaker)  Magnetic cooking device Keep the watch more than 5 cm away from   magnetic products.  (JIS level-1 standard) The reason why analogue   It is because the built-in motor of the watch, which harnesses   Keep the watch more than 1 cm away from   quartz watch is affected   magnetic power and external strong magnetism, affect each other   to stop the motor or suppresses the turn of the motor. magnetic products.  by magnetism. (JIS level-2 standard) Band  (maintenance procedure) The band touches the skin directly and becomes dirty with sweat or dust.   Polyurethane band Therefore, lack of care may accelerate deterioration of the band or cause skin irritation  ...
  • Page 24: Special Clasps

    A Type Special Clasps There are 3 type of special clasps as described below;  3) Take the pin out of the adjustment hole, adjust the  1) Lift up the clasp to release the buckle. size  of  the  strap  by  sliding  it  back  and  forth,  and  If the clasp of the watch you purchased is one of them,   then  put  the  pin  back  into  the  appropriate  please refer to the indications. adjustment hole. Fixed loop A type B type Adjustment hole Moveable loop 2) Open the flap. 4) Close the flap. C type Flap Flap B Type 1 How to wear or take off the watch ...
  • Page 25: Battery/Battery Life/Accuracy

    C Type 3)Pull the pin out of a adjustment hole  4)Fasten  the  buckle  with  pressing  the  1)Press  the  button  on  the  buckle,  and  2)To  adjust  :  Pull  the  pins  out  of  the  of the band.  Slide the band to adjust  push buttons. lift to open the clasp. adjustment  holes  on  the  band.  Slide  its  length  and  find  an  appropriate  the  band  to  the  appropriate  length.  hole.  Place the pin into the hole.
  • Page 26: Troubleshooting

      Troubleshooting Solutions Trouble Possible causes The watch stops operating The battery has run down.  Have  the  battery  replaced  with  a  new  one  immediately  by  the  retailer  from  whom  the  watch  was  purchased. The  small  second  hand  moves  at  two  The battery nears its end. second intervals Return  the  watch  to  a  normal  temperature  so  that  it  works  accurately  as  usual,  and  then  reset  the  time.  The ...
