- Page 1 Cal. H023 INSTRUCTIONS INSTRUCTIONS INSTRUCCIONES BEDIENUNGSANLEITUNG ISTRUZIONI INSTRUÇÕES 用法説明 (S. 99) (P. 131) (P. 163) (195 頁)
- Page 2 You are now the proud owner of a SEIKO Duo-Display Watch Cal. H023. For best results, please read the instructions in this booklet carefully before using your SEIKO Duo-Display Watch. Please keep this manual handy for ready reference. Vous voici l’heureux propriétaire d’une montre double affichage SEIKO Cal. H023. Pour en obtenir d’excellentes performances, veuillez lire attentivement les explications suivantes avant d’utiliser la...
-
Page 3: Table Of Contents
MODE CHANGE ... TIME/CALENDAR MODE ... WORLD TIME MODE ... STOPWATCH MODE ... ALARM MODE ... NOTES ON OPERATING THE WATCH ... BATTERY LIFE INDICATOR ... BATTERY CHANGE ... TO PRESERVE THE QUALITY OF YOUR WATCH ... SPECIFICATIONS ... CONTENTS Page... -
Page 4: Features
SEIKO DUO-DISPLAY QUARTZ FEATURES TIME/CALENDAR Fully automatic calendar Daylight saving time display WORLD TIME Time & date of 28 cities (on page Time transfer function ALARM World time alarm function Cal. H023 STOPWATCH Measures up to 100 hours in 1/... -
Page 5: Buttons & Display
BUTTONS & DISPLAY There are four buttons as indicated in the illustration below. [TIME/CALENDAR mode] Hour hand Mode indicator City name scrolls from right to left in TIME/CALENDAR SETTING display and WORLD TIME and ALARM modes. Scroll window Second hand Minute hand... -
Page 6: Mode Change
MODE CHANGE Press repeatedly to select mode. The mode name scrolls from right to left in the scroll window. Mode indicator TIME TIME/ CALENDAR mode When the hourly time signal/confirmation sound for button operation is switched on, a beep sounds with each press of Button A. As a reference aide, the beep sounds in a different tone when the mode changes over to the TIME/CALENDAR mode. -
Page 7: Time/Calendar Mode
Hour for 12-hour display only If the watch is left untouched for 2 minutes when Day & Date Display is selected, the digital time and city name disappear and only the day and date are shown. To show the digital time and city name, press any one of the four buttons. -
Page 8: Time/Calendar Setting
TIME/CALENDAR SETTING Set the digital time first before setting the analogue time, as the second hand is governed by the digital time. Once the time and calendar of your area are set in the TIME/CALENDAR mode, the time and calendar of the other 28 cities covered in the WORLD TIME mode will be automatically set. - Page 9 Digital time/calendar setting Analogue time setting Press to select an item(flashing) to be adjusted.With each press of the but- ton, a flashing item changes over in the following order (See *1 on page 22) Second City 12-/24-hour display Year Month Press to adjust the selected item.
- Page 10 Press to show “HOUR–SET”. Press repeatedly to set Hour and (See *3 on page 22) Press for the display selection. Press to select the desired display. * [Day & Date Display] or [Time & Calendar Display] can be alternatively selected. Press to return to TIME/CALENDAR mode.
-
Page 11: Engagement/Disengagement Of Hourly Time Signal
ENGAGEMENT/DISENGAGEMENT OF HOURLY TIME SIGNAL AND TURNING ON/OFF OF CONFIRMATION SOUND FOR BUTTON OPERATION HOW TO SET THE DAYLIGHT SAVING TIME (SUMMER TIME) If the daylight saving time is in effect, press Button D for 2 to 3 seconds to display the daylight saving time. -
Page 12: World Time Mode
WORLD TIME MODE Digital display Analogue display : Hour and Minute hands --- time of your area (Home Time) Press to show WORLD TIME mode. Selected city (Ex.: Paris) 9Mode indicato Date of the selected city “AM”/“PM” indicator for 12-hour display only Daylight saving time indicator : City name,time, date and day of the week of the city selected from the 28 cities in different time zones throughout the world that are... - Page 13 City name City hand Time of the selected city Daylight saving time indicator Press to set City (Second) hand to point at the name of the city on the bezel whose time/calendar you wish to know. * The name of the selected city scrolls from right to left in the scroll window,and then the first 4 letters of the city name remain displayed.
- Page 14 TIME TRANSFER FUNCTION The time displayed in the TIME/CALENDAR mode can easily be replaced with the time of the city selected in the WORLD TIME mode. Press to set City (Second) hand to point at the desired city. ▼ Press for 2 seconds to transfer the time of the city selected in WORLD TIME mode to TIME/CALENDAR mode.
-
Page 15: Time Differences
* The cities marked with “*” use daylight saving time (summer time). See *7 on page 22 * If you live in a time zone not covered in the list above, not all the functions are avairable. In such cases, please consult the nearest SEIKO Service Center as listed in the SEIKO Worldwide Guarantee and Instructions. -
Page 16: Stopwatch Mode
STOPWATCH MODE Stopwatch measures up to 100 hours in 1/1000-second increments. (See *8 on page 23) Press to show STOPWATCH mode. While the stopwatch is counting, the Second hand indicates the elapsed time in 1-second increments and the graphic display scrolls from left to right in the scroll window. - Page 17 STOPWATCH OPERATION Before using the stopwatch, reset the digital counter to read “00:00'00"000” by pressing Button D. 1 Standard measurement START 2 Accumulated elapsed time measurement START STOP * Stop and restart of stopwatch can be repeated as many times as required by pressing Button C. STOP RESET ○...
- Page 18 3 Lap time measurement LAP 1 START * Timing and release of lap times can be repeated as many times as required by pressing Button D. * When Button C is pressed at the end of timing, the final lap time is displayed. "Lap time"...
-
Page 19: Alarm Mode
ALARM MODE World time alarm : The alarm can be set to ring on the basis of the time (standard time or daylight saving time) of a desired city without any time difference adjustment. Press to show ALARM mode. Selected city (Ex.: London) “AM”/“PM”... - Page 20 ALARM TIME SETTING City name Press for 2 to 3 seconds to show ALARM SETTING display. * The name of the city previously selected scrolls in the scroll window while the other digital display windows become blank. Press to select the city for which you wish to set the alarm.
- Page 21 ALARM ENGAGEMENT/DISENGAGEMENT Press to show ALARM mode. ▼ With each press, alarm is alternately engaged and disengaged. Alarm indicator “on” indicator “off” indicator [Alarm engaged] [Alarm disengaged] * The alarm sounds at the designated time for 20 seconds. To stop it manually, press any one of the four buttons.
-
Page 22: Notes On Operating The Watch
The hands move counterclockwise by pressing Button A and clockwise by pressing Button D.They move quickly if the respective buttons are kept pressed. If the watch is left untouched in the TIME/CALENDAR SETTING display with an item flashing, it will automatically return to the TIME/CALENDAR mode in 2 to 3 minutes. - Page 23 • When setting the hours in the 12-hour display, check that AM/PM is properly set. *10 If the watch is left untouched in the ALARM SETTING display with an item flashing, it will automatically return to the ALARM mode in 2 to 3 minutes.
- Page 24 When all indicators light If all indicators of the display light while in the TIME/CALENDAR mode, it is not a malfunction. This happens if Button C and D are pressed at the same time during time setting. In such a case,press any one of the four buttons to return to the TIME/CALENDAR mode.
-
Page 25: Battery Life Indicator
Otherwise, the watch will stop operating in 2 to 3 days. We suggest that you have the battery replaced by a SEIKO DEALER. * Even after the battery life indicator appears, time accuracy is not affected. - Page 26 NECESSARY PROCEDURES AFTER CHANGING THE BATTERY * After the battery is replaced with a new one , or in case an abnormal display (Broken numerals or letters etc.) appear, follow the procedures below to reset the IC. * All digital indicators are reset to show "GREE", "...
- Page 27 WARNING Do not remove the battery from the watch. If it is necessary to take out the battery, keep it out of the reach of children. If a child swallows it, consult a doctor immediately. Never short-circuit, tamper with or heat the battery, and never expose it to fire.
-
Page 28: To Preserve The Quality Of Your Watch
TO PRESERVE THE QUALITY OF YOUR WATCH WATER RESISTANCE Indication on case back Degree of water resistance* No indication WATER RESISTANT WATER RESISTANT 5 BAR WATER RESISTANT 10/15/20 bar 10/15/20 BAR Accidental Condition contact of use with water such as rain... - Page 29 5 bar watch, or 10/15/20 taking a bath with a water resistant bar WR 10, 15 or 20 bar watch, be sure to observe the following: * Do not operate the buttons when the watch is wet with soapy water or shampoo.
- Page 30 2 2 - 3 to 3 years. Have your watch Years checked by an AUTHORIZED SEIKO DEALER or SERVICE CENTER to ensure that the case, buttons, gasket and crystal seal remain intact. PRECAUTION REGARDING CASE BACK PROTECTIVE FILM...
- Page 31 7 years. After that it may decrease in contrast, 7 Years becoming difficult to read. Please contact your AUTHORIZED SEIKO DEALER or SERVICE CENTER if you wish to have a new panel fitted (guaranteed one year).
-
Page 32: Specifications
SPECIFICATIONS 1 Frequency of crystal oscillator ... 32,768 Hz (Hz = Hertz ... Cycles per second) 2 Loss/gain (monthly rate) ... Less than 15 seconds at normal temperature 3 Operational temperature range ... –10° C ~ +60° C (14° F ~ 140° F) Desirable temperature range of use . - Page 33 ALARM mode ... World time alarm, Alarm time (hour and minute) Digital display medium ... Nematic Liquid Crystal, FEM (Field Effect Mode) Battery ... SEIKO SR1130W, 1 piece Battery life indicator ... Battery life indicator appears in the scroll window 10 IC (Integrated Circuit) ...
