Summary of Contents for Centurion D5
- Page 1 Theft-resistant kit installation guide THEFT-RESISTANT...
-
Page 2: General Description
Centurion Systems (Pty) Ltd cannot be held liable under any circumstance for any damage, loss or action that results from your gate operator being tampered with. -
Page 3: Product Identification
2. Product Identification FIGURE 1. THUMBWHEEL GUARD AND THEFT-RESISTANT CAGE PARTS IDENTIFICATION Thumbwheel Guard Overstrap Bracket Front bar page 2... - Page 4 3. Fitting the Thumbwheel Guard 1. Use your key to open the access door 2. Ensure that the gearbox is engaged by to the manual override thumbwheel. turning the thumbwheel anti-clockwise before fitting the Thumbwheel Guard. It must not be possible to move the gate by hand.
- Page 5 It is important that the Theft-resistant Cage is properly fitted as per the instructions given and that a suitable lock is fitted. Please note that a lock is not supplied in this kit. Centurion Systems recommends using an insurance- approved padlock with a minimum throat width of 30mm. Refer to the illustration below.
- Page 6 3. Re-fasten the washers and nuts to the 4. Fit bracket on to the right hand side retaining studs to secure the brackets. retaining stud. 5. Re-fasten the washer and nut to the 6. Slide overstrap over motor cover, retaining stud to secure the bracket. making sure it engages correctly with the brackets on both sides of the operator.
- Page 7 7. Fit the front bar to the assembly by feeding both legs of the bar through the bracket and overstrap. 8. With the front bar fully engaged with the overstrap, secure the assembly by locking a good quality padlock through the aligned barrel holes on the overstrap and front bar.
- Page 8 Notes...
- Page 9 Notes...
- Page 10 YouTube.com/CenturionSystems Subscribe to the newsletter: www.CentSys.com/Subscribe Sharecall 0860-CENTURION (0860 236 887) Head Office: +27 11 699 2400 Sharecall Technical Support 0861 003 123 or +27 11 699 2481 from 07h00 to 18h00 (GMT+2) (Sharecall numbers applicable when dialed from within South Africa only) 0.07.A.0185_04062014...
