Installation

Holding bracket for plinth

The holding bracket prevents the wash-
ing machine from falling off the plinth
during operation.
Fastening with the holding bracket is
only intended for plinths made from
concrete. The plinth must be flat and
level. The surface below the plinth must
be able to withstand the physical loads.
Prior to installation, check whether the
plinth complies with the minimum di-
mensions.
Height 6 cm
:
Width: 60 cm
Depth: 65 cm
Positioning the holding bracket

Risk of injury from sharp edges.
The holding bracket has sharp edges.
You could cut yourself on the edges.
Take care when handling the holding
bracket.
Wear gloves while installing the hold-
ing bracket.
The front appliance feet must protrude
by at least 3 mm. The washing ma-
chine must already be aligned (see "In-
stallation – Aligning the washing ma-
chine")
58
 Place the holding bracket on the front
appliance feet.
 Mark the position of the front edge of
the holding bracket with a pencil.
 Remove the holding bracket from the
feet.
 Carefully move the washing machine
until you have enough space to install
the holding bracket.
