INSTALLATION INSTRUCTIONS
WINDOW STAND
FREESTANDING
VERSION
WINDOW STAND
LANDSCAPE
WINDOW STAND
PORTRAIT
WINDOW STAND
PORTRAIT
BOLT DOWN
VERSION
WINDOW STAND
LANDSCAPE
WINDOW STAND
PORTRAIT
WINDOW STAND
PORTRAIT
OMB srl │ Via Risorgimento, 25 │ 38070 STENICO (TN) │ ITALY
Tel. +39 0465 771036 │ omb@ombitaly.it │www.ombitaly.it
PRODUCT
COLOR MIN VESA MAX VESA
CODE
09232
Black
200X200
600X400
09233
Black
200X200
09237
Black
200X200
PRODUCT
COLOR MIN VESA MAX VESA
CODE
09230
Black
200X200
600X400
09231
Black
200X200
09236
Black
200X200
REL 2022 – document code 04563
FREESTANDING VERSION
SCREEN
SCREEN SIZE
ORIENTATION
Landscape
32 - 65
400x400
Portrait
32 - 65
400x600
Portrait
32 - 65
BOLT DOWN VERSION
SCREEN
SCREEN SIZE
ORIENTATION
Landscape
32 - 65
400x400
Portrait
32 - 65
400x600
Portrait
32 - 65
WEIGHT
inch
CAPACITY
Kg/Lbs
50kg - 110lbs
50kg - 110lbs
50kg - 110lbs
WEIGHT
inch
CAPACITY
Kg/Lbs
50kg - 110lbs
50kg - 110lbs
50kg - 110lbs

Advertisement

loading
Need help?

Need help?

Do you have a question about the 09230 and is the answer not in the manual?

Questions and answers

Related Manuals for OMB 09230

Summary of Contents for OMB 09230

  • Page 1 PORTRAIT WINDOW STAND 09236 Black 200X200 400x600 Portrait 32 - 65 50kg - 110lbs PORTRAIT REL 2022 – document code 04563 OMB srl │ Via Risorgimento, 25 │ 38070 STENICO (TN) │ ITALY Tel. +39 0465 771036 │ omb@ombitaly.it │www.ombitaly.it...
  • Page 2 OMB o ad eventuale combinazione di prodotti OMB non idonei a quella installazione. 1 Prima dell'uso controllare che tutti i dadi e bulloni siano fissati saldamente.
  • Page 3 ASSEMBLY PROCESS Fix the FREESTANDING (N) or BOLT DOWN BASE (M) to the main pole (L) using 4 screws M8x30 (B). To fix the BOLT DOWN version to the floor, consult an expert technician. Floor fixing screws are not supplied. Fix the SCREEN VESA SUPPORT (O) to the main pole using 4x washers (C) and 4x screws (D)
  • Page 4 ASSEMBLY PROCESS Insert the 2x SNAP HOOK (E) in the MONITOR HOLDER BARS (P) as indicated in the picture. Fix the 2x MONITOR HOLDER BARS (P) to your screen using one of following screw set: (G), (H) or (I) Hook the monitor to VESA SUPPORT (O) while pressing lightly to engage the SNAP HOOK CLIP (E)
