ENGLISH
INSTALLATION INSTRUCTIONS
TROLLEY E500 MAXI
CAPACITY
Max Screen Size: up to 100" (254 cm)
Max weight capacity: 150 Kg (lbs 330)
Min VESA: 200x200
Max VESA: 800x600
REL 2024 – document code 04719
OMB srl│ via Risorgimento 25│ 38070 Stenico (TN)
Tel. +39.0464.771036│ info@ombitaly.it│www.ombitaly.it
1
Advertisement
Table of Contents
Related Manuals for OMB TROLLEY E500 MAXI
Summary of Contents for OMB TROLLEY E500 MAXI
- Page 1 TROLLEY E500 MAXI CAPACITY Max Screen Size: up to 100” (254 cm) Max weight capacity: 150 Kg (lbs 330) Min VESA: 200x200 Max VESA: 800x600 REL 2024 – document code 04719 OMB srl│ via Risorgimento 25│ 38070 Stenico (TN) Tel. +39.0464.771036│ info@ombitaly.it│www.ombitaly.it...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS Before using the TROLLEY E500 MAXI, please read the following information regarding safety so as to safeguard the integrity of the product and avoid accidents.
- Page 3 Legal person in charge for the preparation of the technical file: O.M.B. s.r.l. - via Risorgimento, 25 - 38070 Stenico (TN) DECLARATION SIGNED BY: Carlo Bailo POSITION: Legal representative DATE and SIGNATURE: 19/02/2023 Carlo Bailo OMB srl│ via Risorgimento 25│ 38070 Stenico (TN) Tel. +39.0464.771036│ info@ombitaly.it│www.ombitaly.it...
- Page 4 ASSEMBLY PROCESS TRANSPORT AND ASSEMBLY This motorized adjustable cart is supplied unassembled. Two people are required for assembly. The correct final installation is illustrated here below. Since the weight of the packed column is about 34 kg, the lifting and the transport should be done with a forklift or similar equipment, or carried by two people simultaneously.
- Page 5 ASSEMBLY PROCESS MOUNTING THE UPPER PART TO MOTORIZED COLUMN Fix the main tube (G) to the column (F) using 4 screws M10x30 (H). VESA SUPPORT INSTALLATION. Insert the VESA support (I) into the tube (G) and position it at the desired height, then fix the VESA support with the two available screws (L) ASSEMBLY THE SCREEN TO VESA SUPPORT...
- Page 6 ASSEMBLY PROCESS ELECTRICAL CONNECTIONS SYSTEM DIAGRAM Connect according to the system diagram and then power on (input AC is 110-220VAC). Up button: Press and hold the key to lift the column. Let go and stop. Down button: Press and hold the key to lower the column. Let Remote control go and stop.
