INSTALLATION MANUAL
CAPACITY:
Max Screen Size: up to 100" (2540 mm)
Max weight capacity: 120 Kg (lbs 264,5)
Min VESA 200x200
Max VESA 800x600
Showed measurements in mm
OMB srl – via Risorgimento, 25 – 38070 Stenico (TN) - Italy
TROLLEY XXL
1. Important safety instruction .............................. 2
2. List of components ........................................... 3
3. Assembly sequence .......................................... 4
16/04/2021 - v. 002
office: +39 0465 771036 – www.ombitaly.it – omb@ombitaly.it
INDEX
Advertisement
Related Manuals for OMB TROLLEY XXL
Summary of Contents for OMB TROLLEY XXL
- Page 1 2. List of components ........... 3 Max VESA 800x600 Showed measurements in mm 3. Assembly sequence .......... 4 16/04/2021 - v. 002 OMB srl – via Risorgimento, 25 – 38070 Stenico (TN) - Italy office: +39 0465 771036 – www.ombitaly.it – omb@ombitaly.it...
- Page 2 OMB o ad eventuale combinazione di prodotti OMB non idonei a quella installazione. 1 Prima dell'uso controllare che tutti i dadi e bulloni siano fissati saldamente.
- Page 3 2. List of components CAP 60x60 Code Description Q.ty Drawing 03601 BLACK RIGHT BASE 44389 WELDED SCREW BLACK 40056 00961 M5x10 WHITE DIN7985 LEFT BASE 44388 WELDED BLACK 40056 CAP 30x20 02113 BLACK CENTRAL BASE TUBE 44387 XXL BLACK SCREW 40056 02331 M8x12 WHITE...
- Page 4 3. Assembly sequence Insert the wheels and pins (04397) into the holes on left (44388) and right (44389) bases. Connect the two bases and the central base tube (44387) with 4 bolts (00813) for each side. Tighten the screws well after placing the system on a flat surface and checking that all wheels are in contact with the surface.
- Page 5 Insert the two horizontal tubes (44373) in the holes available at the required height and fix them with 2 screws each (03510). Insert the plugs into the vertical (03601) and horizontal (02113) tubes. Fix the cover (44383), the camera bracket (44385) and the laptop accessory if included (44384) with the necessary screws (03510).
- Page 6 Fix the soundbar bracket accessory if included (44386) with the necessary screws (03510). Fix the camera shelf (44455) and adjust the high with the screw (03510). After passing the cables inside the vertical tubes, close the holes with the plugs (02643). P a g .
- Page 7 Install the monitor bracket (44370) with the screw (02312) on the monitor and fix it on the horizontal tubes. P a g . 7 | 8 OMB_TrolleyXXL_InstallationManual_v001...
- Page 8 Risorgimento, 25 38070 Stenico (TN) - Italy office: +39 0465 771036 www.ombitaly.it omb@ombitaly.it P a g . 8 | 8 OMB_TrolleyXXL_InstallationManual_v001...
