INSTALLATION INSTRUCTIONS
TROLLEY E700
CAPACITY
Max Screen Size: up to 100" (254 cm)
Max weight capacity: 150 Kg (lbs 330)
Min VESA: 200x200
Max VESA: 800x600
REL 2024 – document code 04720
OMB srl│ via Risorgimento 25│ 38070 Stenico (TN)
Tel. +39.0464.771036│ info@ombitaly.it│www.ombitaly.it
1
Advertisement
Table of Contents
Related Manuals for OMB TROLLEY E700
Summary of Contents for OMB TROLLEY E700
- Page 1 TROLLEY E700 CAPACITY Max Screen Size: up to 100” (254 cm) Max weight capacity: 150 Kg (lbs 330) Min VESA: 200x200 Max VESA: 800x600 REL 2024 – document code 04720 OMB srl│ via Risorgimento 25│ 38070 Stenico (TN) Tel. +39.0464.771036│ info@ombitaly.it│www.ombitaly.it...
-
Page 2: Safety Instruction
IMPORTANT SAFETY INSTRUCTIONS Before using the TROLLEY E700, please read the following information regarding safety so as to safeguard the integrity of the product and avoid accidents. - Page 3 Legal person in charge for the preparation of the technical file: O.M.B. s.r.l. - via Risorgimento, 25 - 38070 Stenico (TN) DECLARATION SIGNED BY: Carlo Bailo POSITION: Legal representative DATE and SIGNATURE: 19/02/2023 Carlo Bailo OMB srl│ via Risorgimento 25│ 38070 Stenico (TN) Tel. +39.0464.771036│ info@ombitaly.it│www.ombitaly.it...
-
Page 4: Assembly Process
ASSEMBLY PROCESS TRANSPORT AND ASSEMBLY This motorized adjustable cart is supplied unassembled. Two people are required for assembly. The correct final installation is illustrated here below. Since the weight of the packed column is about 34 kg, the lifting and the transport should be done with a forklift or similar equipment, or carried by two people simultaneously. - Page 5 ASSEMBLY PROCESS MOUNTING THE UPPER PART TO MOTORIZED COLUMN fix the main tube with VESA support (G) to the motorized column using 4 screws M10x30 (H). ASSEMBLY THE SCREEN TO VESA SUPPORT Use 4 x slotted screws Place the brackets (A) equidistant from the center according to the screen holes, then fix them with the four specific screws (D) indicated by the screen manufacturer in the mounting instructions.
-
Page 6: Electrical Connections
ASSEMBLY PROCESS ELECTRICAL CONNECTIONS SYSTEM DIAGRAM Connect according to the system diagram and then power on (input AC is 110-220VAC). Remote Six axis control sensor Up button: Press and hold the key to lift the column. Let go and stop. Down button: Press and hold the key to lower the column.
