DS-K3G501X Series Tripod Turnstile
UD33130B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-K3G501X-R-M-DM55 and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION DS-K3G501X-R-M-DM55

Summary of Contents for HIKVISION DS-K3G501X-R-M-DM55

  • Page 1 DS-K3G501X Series Tripod Turnstile UD33130B...
  • Page 2 Any part of the Document, including text, pictures, graphics, ● etc., belongs to Hikvision. No part of this Document may be excerpted, copied, translated, or modified in whole or in part by any means without written permission. and other Hikvision's trademarks and logos are ●...
  • Page 3 DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET ●...
  • Page 4 © Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
  • Page 5 Regulatory Information EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, RE Directive 2014/53/EU,the RoHS Directive 2011/65/EU 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European...
  • Page 6 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Dangers and Cautions: Dangers: Neglecting any of the warnings may cause serious injury or death.
  • Page 7 Do not dispose of the battery into fire or a hot oven, or mechanically crush or cut the battery, which may result in an explosion. Do not leave the battery in an extremely high temperature surrounding environment, which may result in an explosion or the leakage of flammable liquid or gas.
  • Page 8 Please keep all wrappers after unpack them for future use. In ● case of any failure occurred, you need to return the device to the factory with the original wrapper. Transportation without the original wrapper may result in damage on the device and lead to additional costs.
  • Page 9 Available Models Product Name Model Tripod Turnstile DS-K3G501X viii...

  • Page 10: Table Of Contents

    Contents 1 Overview ..............1 1.1 Introduction ............1 1.2 Main Features ............1 2 System Wiring ............1 3 Installation ............... 2 3.1 Disassemble Pedestals .......... 2 3.2 Install Pedestals ............ 3 4 General Wiring ............4 4.1 Components Introduction ........4 4.2 Wiring ..............
  • Page 11 5.1 Activate via SADP ..........13 5.2 Activate Device via iVMS-4200 Client Software ................... 14 5.3 Activate via Web Browser ........15 6 Operation via Web Browser ........15 6.1 Login ..............15 6.2 Forget Password ..........16 6.3 Live View ............. 16 6.4 Person Management ...........
  • Page 12 6.6.19 Log Query ..........31 6.6.20 Certificate Management ......31 7 Client Software Configuration ......... 32 7.1 Configuration Flow of Client Software ....33 7.2 Device Management ........... 33 7.2.1 Add Device ..........33 7.2.2 Reset Device Password ......35 7.2.3 Manage Added Devices ......
  • Page 13 7.8.1 Control Door Status ........53 7.8.2 Check Real-Time Access Records ....54 A. DIP Switch ............. 56 A.1 DIP Switch Description ........57 A.2 DIP Switch Corresponded Functions ....58 B. Button Configuration Description ......59 C. Event and Alarm Type ..........63 D.

  • Page 14: Overview

    1 Overview 1.1 Introduction The tripod turnstile is designed to detect unauthorized entrance or exit. By adopting the turnstile integratedly with the access control system, person should authenticate to pass through the lane via swiping IC or ID card, scanning QR code, etc. It is widely used in attractions, stadiums, construction sites, residences, etc.

  • Page 15: Installation

    Figure 2-1 System Wiring Diagram Note High voltage: AC power input ● Low voltage: network cable (CAT5E, CAT6 or CAT6E), interconnecting data cable and interconnecting power cable. The supplied interconnecting power cable length is 3.75 m, if ● necessary, you can contact the sales person to replace it with a 5.5 m cable.

  • Page 16: Install Pedestals

    3.2 Install Pedestals Before You Start Prepare for the installation tools, check the device and the accessories, and clear the installation base. Steps Note The device should be installed on the concrete surface or other ● non-flammable surfaces. To prevent stainless steel from rusting due to dirt during ●...

  • Page 17: General Wiring

    1. Prepare for the installation tools, check the components, and prepare for the installation base. 2. Seal the bottom of the turnstile to avoid water from entering. 3. Move the pedestals to the corresponded positions. Note Make sure the installation holes on the pedestals and the base are aligned with each other.

  • Page 18: Wiring

    Figure 4-2 Serial Port 4.2 Wiring Scan the QR code to view the wiring guide video. 4.3 Wiring Electric Supply Wire electric supply with the power switch or power adapter in the pedestal. Terminal L (brown) and terminal N (Blue) are on the switch, while terminal PE should connect to a ground wire (yellow and green wire).

  • Page 19: Terminal Description

    The switching power supply can select the input voltage of 220 V or 110 V by the DIP switch, and the default setting is 220V. Please adjust the DIP switch based on the actual AC voltage to avoid damaging the equipment. Note The cable bare part should be no more than 8 mm.

  • Page 20: Main Optional Board Terminal Description

    Note RS-485A corresponds to UART 5 on web and is for QR code ● scanner connection at entrance by default; RS-485C corresponds to UART 7 on web and is for card reader connection at entrance by default. The SOC and MCU serial port are for maintenance and ●...

  • Page 21: Sub Optional Board Terminal Description

    Figure 4-4 Main Optional Board Terminal 4.4.4 Sub Optional Board Terminal Description Figure 4-5 Sub Optional Board Terminal Note RS-485B corresponds to port 6 on web and is for QR code ● scanner connection by default. RS-485D corresponds to port 4 on web and is for card reader ●...

  • Page 22: Rs-485 Wiring

    Figure 4-6 Card Reader Board 4.4.6 RS-485 Wiring The RS-485 interfaces on the access control board and sub optional board are suggested to connect with the face recognition module or the card reader. Here takes connecting with a card reader as an example. Note If there are other RS-485 devices connecting, the ID of the ●...

  • Page 23: Exit Button Wiring

    Figure 4-10 Remaining Closed 4.4.9 Exit Button Wiring The main and sub lane control board each has 1 button interface, which can be connected to exit button or face recognition device. Figure 4-11 Exit Button Wiring Note The face recognition devices are powered via 12 VDC power ●...
  • Page 24 C ANCEL: Return to the level-1 menu, or exit the configuration ● from the level-1 menu OK: Confirm the data, or enter configuration mode, or enter ● the submenu Note Configuration data is displayed by two digital tubes. ● Level-1 Menu: If the decimal point on the right is on, it ●...

  • Page 25: Initialize Device

    configuration No. setting without saving changes. Conduct no operations for 5 s to cancel configuration. 4.5.2 Initialize Device Steps 1. Hold the initialization button on the access control board for 5 Figure 4-14 Initialization Button Position 2. The device will start restoring to factory settings. 3.

  • Page 26: Activation

    Before You Start Get the SADP software from the supplied disk or the official ● website http://www.hikvision.com/en/ , and install the SADP according to the prompts. The device and the PC that runs the SADP tool should be within ●...

  • Page 27: Activate Device Via Ivms-4200 Client Software

    Status of the device becomes Active after successful activation. 5. Modify IP address of the device. 1) Select the device. 2) Change the device IP address to the same subnet as your computer by either modifying the IP address manually or checking Enable DHCP.

  • Page 28: Activate Via Web Browser

    Note Characters containing admin and nimda are not supported to be set as activation password. 7. Click OK to activate the device. 5.3 Activate via Web Browser You can activate the device via the web browser. Steps 1. Enter the device default IP address (192.0.0.64) in the address bar of the web browser, and press Enter.

  • Page 29: Forget Password

    Answer the security questions. E-mail Verification 1. Export the QR code and send it to pw_recovery@hikvision.com as attachment. 2. You will receive a verification code within 5 minutes in your reserved email. 3. Enter the verification code into the verification code field to verify your identification.
  • Page 30 Click Add to add the person's information, including the basic information, certificate, and authentication settings. Figure 6-1 Person Management Add Basic Information Click Person Management → Add to enter the Add Person page. Add the person's basic information, including the employee ID, the person's name, etc.

  • Page 31: Search Event

    Note The person data will be downloaded to your PC. ● The password you set will be required for importing the data ● file. Importing Person Data Click Importing Person Data and select the file. Click Import. Enter the encryption password to import and synchronize the person data to devices.

  • Page 32: Set Time

    6.6.2 Set Time Set the device's time zone and synchronization mode. Click Configuration → System → System Settings → Time Settings . Click Save to save the settings after the configuration. Time Zone Select the device located time zone from the drop-down list. Time Sync.

  • Page 33: View Device Arming/Disarming Information

    6.6.6 View Device Arming/Disarming Information View device arming type and arming IP address. Go to Configuration → User Management → Arming/Disarming Information . You can view the device arming/disarming information. Click Refresh to refresh the page. 6.6.7 Network Settings Set Basic Network Parameters Click Configuration →...

  • Page 34: Set Audio Parameters

    If you disable DHCP, you should manually set the IPv4 address, IPv4 subnet mask, IPv4 default gateway, preferred DNS server, and alternate DNS server. If you enable DHCP, the system will automatically allocate the IPv4 address, IPv4 subnet mask, the IPv4 default gateway preferred DNS server and alternate DNS server.

  • Page 35: Event Linkage

    6.6.9 Event Linkage Set linked actions for events. Steps 1. Click Configuration → Event → Event Detection → Linkage Settings to enter the page. Figure 6-6 Event Linkage 2. Set event source. - If you choose Linkage Type as Event Linkage, you need to select event types from the drop-down list.
  • Page 36 Figure 6-7 Set Authentication Parameters Click Save to save the settings after the configuration. Terminal Choose Entrance or Exit for settings. Terminal Type/Terminal Model Get terminal description. They are read-only. Enable Authentication Device Enable the authentication function. Authentication Select an authentication mode according to your actual needs from the drop-down list.
  • Page 37 Set the door unlocking duration. If the door is not opened for the set time, the door will be locked. Note The open duration ranges from 5 s to 60 s. Exit Button Type You can set the exit button as Remain Open or Remain Closed according to your actual needs.

  • Page 38: Turnstile

    Permission Free Mode The device only judge your credential is in the valid duration, and will not authenticate the permission. Enable Verify Credential Locally, the device will check permission but not estimate the plan template. Access Control Mode The access control mode is the device normal mode. You should authenticate your credential for accessing.
  • Page 39 Steps 1. Click Configuration → Turnstile Configuration → Keyfob to enter the page. Figure 6-9 keyfob 2. View the keyfob working status. 3. Set Working Mode as One-to-One or One-to-Many. 4. Add keyfob. 1) Click Add and the keyfob adding window will pop up. 2) Enter the Name and Serial No..
  • Page 40 Figure 6-10 People Counting 2. Enable People Counting. 3. Enable Device Offline People Counting at your actual needs. Note Passing Event Recording is reserved. 4. Select Person Statistics Type as Invalid, Passing Detection or Authentication Number. 5. Optional: Click Clear to clear all the people counting information.

  • Page 41: Card Settings

    7. Click Save. 6.6.12 Card Settings Set Card Security Click Configuration → Card Settings → Card Type to enter the settings page. Set the parameters and click Save. Enable NFC Card Reserved. Enable M1 Card Enable M1 card and authenticating by presenting M1 card is available.

  • Page 42: Customize Audio Content

    You can set fingerprint parameters for accessing. Click Configuration → Smart → Smart . Select the Card Reader as Entrance or Exit. Enable Fingerprint Recognition. Select Fingerprint Security Level. Click Save to save the settings after the configuration. 6.6.15 Customize Audio Content Customize the output audio content when authentication succeeded and failed.

  • Page 43: Upgrade And Maintenance

    Note You can click + Audio File or Audio File Management to add audio files. 5) Optional: Repeat substep 1 to 3. 6) Optional: Click to delete the configured time duration. 6. Click Save. 6.6.16 Upgrade and Maintenance Reboot device, restore device parameters, and upgrade device version.

  • Page 44: Device Debugging

    6.6.17 Device Debugging You can set device debugging parameters. Steps 1. Click Maintenance and Security → Maintenance → Device Debugging . 2. You can set the following parameters. Enable SSH To raise network security, disable SSH service. The configuration is only used to debug the device for the professionals.

  • Page 45: Client Software Configuration

    Create and Install Self-signed Certificate Steps 1. Go to Maintenance and Security → Security → Certificate Management . 2. In the Certificate Files area, select a Certificate Type from the drop-down list. 3. Click Create. 4. Input certificate information. 5. Click OK to save and install the certificate. The created certificate is displayed in the Certificate Details area.

  • Page 46: Configuration Flow Of Client Software

    7.1 Configuration Flow of Client Software Follow the flow diagram below to configure on the client software. Figure 7-1 Flow Diagram of Configuration on Client Software 7.2 Device Management The client supports managing access control devices and video intercom devices. Example You can control entrance &...
  • Page 47 The devices to add share the same port number. The default value is 80. User Name Enter the device user name. By default, the user name is admin. Password Enter the device password. Caution The password strength of the device can be automatically checked.

  • Page 48: Reset Device Password

    3. Click Add to open the Add window, and then select Batch Import as the adding mode. 4. Click Export Template and then save the pre-defined template (CSV file) on your PC. 5. Open the exported template file and enter the required information of the devices to be added on the corresponding column.

  • Page 49: Manage Added Devices

    All the online devices sharing the same subnet will be displayed in the list. 3. Select the device from the list and click on the Operation column. 4. Reset the device password. - Click Generate to pop up the QR Code window and click Download to save the QR code to your PC.

  • Page 50: Group Management

    Click to view the details of online user View Online who access the device, including user User name, user type, IP address and login time. Refresh Click to refresh and get the latest Device device information. Information 7.3 Group Management The client provides groups to manage the added resources in different groups.

  • Page 51: Person Management

    Note You can click to switch the resource display mode to thumbnail view or to list view. 6. Click Import to import the selected resources to the group. 7.4 Person Management You can add person information to the system for further operations such as access control, video intercom, time and attendance, etc.

  • Page 52: Collect Fingerprint Via Client

    person information from device, if there are no person IDs, the person IDs will be generated according to the rule. 2. Select an organization in the organization list to add the person. 3. Click Add to open the adding person window. The Person ID will be generated automatically.

  • Page 53: Import And Export Person Identify Information

    5. Select the model of the connected fingerprint recorder or the enrollment station. Note If the fingerprint recorder is DS-K1F800-F, you can click Settings to select the COM the fingerprint recorder connects to. 6. Collect the fingerprint. 1) Click Start. 2) Place and lift your fingerprint on the fingerprint recorder to collect the fingerprint.

  • Page 54: Get Person Information From Access Control Device

    You can export the added persons' information to local PC as a CSV/Excel file. Before You Start Make sure you have added persons to an organization. ● Make sure you have enabled the Export Person Information ● function to display the Export button. See for details. Steps 1.

  • Page 55: Issue Cards To Persons In Batch

    Note The getting mode varies according to different devices. The access control device supports getting the person information by employee ID. Up to 5 employee IDs can be specified each time. 6. Click Import to start importing the person information to the client.

  • Page 56: Set Card Issuing Parameters

    4. Optional: If the lost card is found, you can click to cancel the loss. After cancelling card loss, the access authorization of the person will be valid and active. 5. If the lost card is added in one access group and the access group is applied to the device already, after reporting card loss or cancelling card loss, a window will pop up to notify you to apply the changes to the device.

  • Page 57: Configure Schedule And Template

    If the card is M1 card, and if you need to enable the M1 Card Encryption function, you should enable this function and select the sector of the card to encrypt. Remote Mode: Issue Card by Card Reader Select an access control device added in the client and swipe the card on its card reader to read the card number.

  • Page 58: Add Template

    Move the cursor to the time duration and drag the time ● duration on the timeline bar to the desired position when the cursor turns to Click the time duration and directly edit the start/end time in ● the appeared dialog. M ove the cursor to the start or the end of time duration and ●...

  • Page 59: Set Access Group To Assign Access Authorization To Persons

    3) Optional: Perform the following operations to edit the time durations. Move the cursor to the time duration and drag the time ● duration on the timeline bar to the desired position when the cursor turns to C lick the time duration and directly edit the start/end time in ●...
  • Page 60 Note You should configure the template before access group settings. Refer to Configure Schedule and Template for details. 5. In the left list of the Select Person field, select person(s) to assign access authority. 6. In the left list of the Select Access Point field, select door(s), door station(s) or floor(s) for the selected persons to access.

  • Page 61: Configure Advanced Functions

    Note If you change the persons' access information or other related information, you will view the prompt Access Group to Be Applied on the right corner of the client. You can click the prompt to apply the changed data to the device.
  • Page 62 Note The displayed parameters may vary for different access ● control devices. Some of the following parameters are not listed in the Basic ● Information page, click More to edit the parameters. Enable NFC If enable the function, the device can recognize the NFC card.
  • Page 63 Note The door or floor's status duration settings will be copied to the selected door/floor(s) as well. Configure Parameters for Card Reader After adding the access control device, you can configure its card reader parameters. Before You Start Add access control device to the client. Steps 1.
  • Page 64 Steps 1. Click Access Control → Advanced Function → Device Parameter to enter access control parameter configuration page. 2. In the device list on the left, click to expand the door, select an alarm input and you can edit the alarm input's parameters on the right.

  • Page 65: Configure Device Parameters

    7.7.2 Configure Device Parameters After adding the access control device, you can set its parameters such as network parameters. Set RS-485 Parameters You can set the access control device's RS-485 parameters including the baud rate, data bit, the stop bit, parity type, flow control type, communication mode, work mode, and connection mode.

  • Page 66: Control Door Status

    event are displayed in this module. You can view the access details and person details. Note For the user with door control permission, the user can enter the Monitoring module and control the door. Or the icons used for control will not show. For setting the user permission, refer to Person Management.

  • Page 67: Check Real-Time Access Records

    All doors in the group will be unlocked (no matter closed or open). All the persons can access the doors with no credentials required. Remain All Locked All doors in the group will be closed and locked. No person can access the doors even if he/she has the authorized credentials, except the super users.
  • Page 68 2. Optional: Select an access point group from the drop-down list in the upper-right corner to show the real time access records of the selected group. 3. Optional: Check the event type and event status. The detected events of checked type and status will be displayed in the list below.

  • Page 69: Dip Switch

    A. DIP Switch...

  • Page 70: Dip Switch Description

    A.1 DIP Switch Description The DIP switch is on the access control board. No.1 and No 2 is from the low bit to the high bit. Figure A-1 DIP Switch When the switch is towards ON, it means the switch is enabled, otherwise, the switch is off.

  • Page 71: Dip Switch Corresponded Functions

    A.2 DIP Switch Corresponded Functions Note After setting the DIP switch, you should reboot the device, or the function cannot take effect. The 2-bit DIP switch corresponded functions on the access control board are as follows: DIP Switch Device Decimal Function Address Mode...

  • Page 72: Button Configuration Description

    B. Button Configuration Description Refer to the table below for device configuration via button on the main lane control board. Level-1 Configuration Level-1 Configuration Description No. and Functions 1-Normal Mode 2-Pairing Mode Note keyfob Pairing Mode By default, 1 will be displayed on the display screen.
  • Page 73 Level-1 Configuration Level-1 Configuration Description No. and Functions Note By default, 5 will be displayed on the display screen. 5-5s，6-6s，7-7s, ..., 60-60s Note Exit Duration By default, 5 will be displayed on the display screen. 1-0，2-1，3-2，4-3， Note Volume By default, 2 will be displayed on the display screen.
  • Page 74 Level-1 Configuration Level-1 Configuration Description No. and Functions Note By default, 1 will be displayed on the display screen. 1-Disable 2-Enable Note Unauthorized Passing By default, 1 will be displayed on the display screen. 1-Disable 2-Enable Exceeding Note Authentication Duration By default, 1 will be displayed on the display screen.
  • Page 75 Level-1 Configuration Level-1 Configuration Description No. and Functions Note By default, 2 will be displayed on the display screen. 1-Default 2-Enable Note Restore to Default By default, 1 will be displayed on the display screen.

  • Page 76: Event And Alarm Type

    C. Event and Alarm Type Event Alarm Type Passing Timeout None...

  • Page 77: Table Of Audio Index Related Content

    D. Table of Audio Index Related Content Index Content Authenticated. Card No. does not exist. Card No. and fingerprint mismatch. Passing timeout. No permissions. Authentication time out. Authentication failed. Expired card.

  • Page 78: Error Code Description

    E. Error Code Description The turnstile will display the error code on the seven-segment display if error occurred. Refer to the table below to find the description of each number. Error Reason Code Error Reason Code Optional Board Offline (If the board is not installed, the error code of "49"...
