- Page 1 Machine Translated by Google PELLET BURNER PELL V.2 series TECHNICAL PASSPORT INSTALLATION and OPERATION INSTRUCTIONS for AUTHORIZED INSTALLERS Version i0.4.6...
-
Page 2: Table Of Contents
Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS CONTENTS 1. EXPLANATION OF SYMBOLS AND SAFETY INSTRUCTIONS ........ 4 2. PRODUCT DESCRIPTION ..................6 3. FUEL ........................7 4. TRANSPORTING THE BURNER................. 7 5. -
Page 3: Explanation Of Symbols And Safety Instructions
Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 1. EXPLANATION OF SYMBOLS AND SAFETY INSTRUCTION BURNiT iUse only original parts 1.1. Explanation of symbols ATTENTION! Installation and adjustment of the ATTENTION! - Important recommendation or warning burner must be done only by an authorized ÿ... - Page 4 Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS General safety rules to be followed by the user: to fire or injury. Contact your local building inspector if you need prior approval to install this product. - Operate the pellet burner only with the recommended fuel, periodically checking the boiler room.
- Page 5 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 1.2.3. Minimum distance during installation and flammability of building materials Other minimum distances than those below may apply in your country. Please consult your installer. The minimum distance of the heating boiler or exhaust gas pipe from objects and walls must be no less than 200 mm.
-
Page 6: Product Description
Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS 2. PRODUCT DESCRIPTION • Built-in microprocessor control. The main control unit located in the burner manages the entire heating process. The pellet burner for water heating boilers BURNiT Pell is designed to burn only wood pellets, and its purpose is to heat heating boilers. -
Page 7: Fuel
Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 260x120x1700 mm. 3. FUEL - Dimensions of the package (wooden case) of the Pell 150 burner: 865x435x630mm When buying pellets, ask for a declaration of conformity and a certificate from an accredited laboratory and make sure that the fuel meets the requirements mentioned in the instructions. -
Page 8: Storage Of The Burner
Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS Scheme 4. Installation of a Pell v.2 burner to a 6. STORAGE OF THE BURNER combustion chamber Pell torches should be stored in dry and well-ventilated areas. 7.1. - Page 9 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL backup electric power supply - generator, with ÿIt is mandatory to ensure the appropriate power! (see item 12.3) ÿ Check that the power supply network is grounded. During lightning storms, disconnect the device ÿ...
- Page 10 Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS diagram 6. Electrical diagram of connecting the internal devices/ sensors to the controller Lera...
- Page 11 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 7.3. Possible problems and their prevention Table 4. Reason Removal Malfunction 1. Temperature 1.1. Immediately consult - in the boiler, on combination of No Yes Install at the outlet which you wrote with your installer, it was installed - 1.1. Improperly sized for the problem. the rail is low. installation and/ or for heating equipment reach normal draining Y PIC-tap, which temperature mode is included in the set.
-
Page 12: Operation Of The Burner
Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS 8. OPERATION OF THE BURNER repeatability depending on burner load. 8.1. Ignition. 8.4. Requirements for the installer regarding servicing and After starting the burner from the control unit, the main feed auger maintenance of the burner. -
Page 13: Microprocessor Control
Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 9. MICROPROCESSOR CONTROL The NPBC-V4 controller must be powered for at 9.1. Controller view. Explanation of but- least 3 minutes to operate normally nits and indicators. ÿ The NPBC-V4C-1 controller is controlled via its "Control Module", the system for maintaining the clock and using 6 buttons. - Page 14 Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS 9.2. LCD Screen. Explanation of display indication: After turning on the power, the controller displays its main screen, which looks like this: Icon bar for the condition of outlets and Internet Clock...
- Page 15 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL a timer is active and the burner is on, below the icon will be the next burner lighting procedure begins with loading the first batch of timer action and the time or day of the week when it will occur. pellets into the combustion chamber.
- Page 16 Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS installed an additional powerful fan or other mechanical cleaning combustion chamber starts feeding pellets and air for maximum power, system to and from the FC outlet. The cleaning settings are different, the flame can be choked or blown out.
- Page 17 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 9.4. Operation of the burner: 9.4.1. Circulation pumps can continue to operate despite the extinguished burner as long as the conditions for their operation are met. In this Switch on / off the burner. way, the remaining thermal energy of the water in the boiler will be used.
- Page 18 Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS 9.4.2. Changing the set temperature for heating the water in the 9.4.5. Information about the status of some current parameters. boiler. By pressing a button when the controller is in the "Pellet consumption" screen, it goes to the "Information"...
- Page 19 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL The messages you may see on this screen are given in Table 5. The fields are as follows: Messages 1 to 13 are also displayed as registered fault messages ID – Unique identifier of each modem on the bottom line of the main screen.
- Page 20 Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS Table 5. Clearing Description Message mistake 1 Backfire A backburner thermostat has tripped with a button 2 Interrupted TC boiler automatically Interrupted thermal sensor of the boiler 3 Short in TC boiler automatic Short in boiler temperature sensor 4 Frozen boiler...
- Page 21 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL values, and if they are reached, the corresponding parameter stops To see more clearly if the timers are activated and changing, despite a short beep when the change button is pressed. will control the burner and what their next action will be turn on/ After completing the necessary corrections to remember the changed...
- Page 22 Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS 10.3. Installer (service) menu. Service parameter settings. These parameters are directly related to ignition management, combustion and safety when using the burner. Access to them can be restricted with a code that can be set from the "Service Settings"...
- Page 23 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL on this menu without pressing any buttons for 5 minutes. The outputs are then turned off and output to the front screen. 10.3.2. Fuel dependent service settings. To enter these settings, you must enter the main screen for service settings on the line "Sett.
- Page 24 Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS of the maximum power you will want to get from the burner. Power P2 should be 50% of P3 and P1 should be 20% of P3. With such a setting, the controller will have the ability to smoothly modulate the power of the burner in the range of 20 to 100%, changing the power if necessary with each new cycle.
- Page 25 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL When adjusting the maximum temperature of the burner, information on adjusting the temperature of the buffer is displayed. In the service menu, in the "Basic settings" submenu , you can adjust the hysteresis of the buffer vessel.
- Page 26 Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS Range of adjustable parameters Default Menu Min Max Pell Pell Pell Pell Pell Pell Parameter The only level Display Brightness Pump Turn on 10 80 50 50 50 heating Control...
- Page 27 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL Range of adjustable parameters Default Min Max Pell Pell Pell Pell Pell Pell Menu Parameter One- Continue- seconds physicality Unravel- speed hurt Chimney vent. speed seconds 10 seconds 10 25.0 Portion seconds 0.1 Cycle...
-
Page 28: Technical Characteristics
Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS 11. TECHNICAL CHARACTERISTICS OF THE PELLET BURNER PELL v.2 11.1. Elements of a PELL pellet burner Scheme 8. Elements of a Pell v.2 burner 1. Pellet burner Pell; 6. Supply pipe; 2. - Page 29 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 11.2. Technical parameters Pell Pell Pell Pell Pell Pell Nominal power kW Min. / max. power kW 5÷25 10÷30 10÷40 15÷70 30÷90 50÷150 ~ 400 ~ 400 ~ 400 ~ 400 ~ 400 ~ 400 In the process of ignition...
-
Page 30: Recycling And Disposal
Machine Translated by Google ERATION MANUAL INSTALLATION and OPTICAL TECHNICAL PASSPORT. INSTALLATION AND OPERATION INSTRUCTIONS 12. RECYCLING AND DISPOSAL Submit the packaging material for recycling according to local regulations and requirements. contain harmful substances on health and the environment. The metallic At the end of each product's life cycle, it must be parts as well as the non-metallic ones the components... - Page 31 Machine Translated by Google TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL...
- Page 32 Machine Translated by Google tel.: +359 700 17 343 www.burnit.bg...
