- Page 1 Kit Instructions Under Counter Mounting Bracket 7199-K100 Issue B Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited...
- Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.
-
Page 3: Revision Record
Revision Record Issue Date Remarks Nov 2017 First issue May 2023 Converted to Guild template Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited. -
Page 4: Tools Needed
This kit serves as a mounting bracket for installing the printer under the counter. Tools needed Cordless hand drill Phillips screw driver Screws (4) Note Screws are not included in the kit. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited. -
Page 5: Installation Procedures
1. Prepare the installation site. Use the following dimensions. a. Mark the location of the anchor holes under the counter. b. Drill the four anchor holes. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited. - Page 6 2 turns at a time, to evenly secure the mounting bracket under the counter. 3. Connect the cables to their respective ports on the printer. For more information, refer to Connecting the Cables on page 10. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited.
- Page 7 4. Mount the printer to the mounting bracket. a. Hold the printer on both sides, positioning it to the center of the mounting bracket. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited.
- Page 8 If the printer is not properly installed, remove the printer by pulling the anti-dislodgement plunger at the back of the mounting bracket and then sliding the printer up. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited.
- Page 9 6. Connect the other end of the cables to their respective device or terminal. For more information, refer to Connecting the Cables on the next page. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited.
-
Page 10: Connecting The Cables
1. Connect the communication cable and the cash drawer cable to their respective connectors on the bottom of the printer. 2. Connect the power cable to its connector on the bottom of the printer. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited. - Page 11 Note The image shown above has a Serial Interface Module Cable Connection. For other cable routings, refer to NCR RealPOS 7199 Thermal Receipt Station Printer User Guide (BCC5-0000-5172). Confidential and proprietary information of NCR.
- Page 12 At this point, the printer receives power. If the On Line LED (green) is on, the printer is online. Otherwise, the printer is not receiving power. Ensure that the host terminal is on or that the power supply is on. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited.
-
Page 13: Routing The Cables
This type of cable routing is for USB cable connection, regardless of the type of power cable used. Note Route the cash drawer cable first before the USB cable. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited. - Page 14 This type of cable routing is for RS-232/Ethernet cable connection that uses a power cable without a ferrite bead. Note Route the cash drawer cable first before the RS-232/Ethernet cable. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited.
- Page 15 This type of cable routing is for RS-232/Ethernet cable connection that uses a power cable with a ferrite bead. Note Route the power cable first before the cash drawer cable. Confidential and proprietary information of NCR. Unauthorized use, reproduction and/or distribution is strictly prohibited.
