  • Page 1 NSS evo2 NSO evo3S MPU ENGLISH simrad-yachting.com...
  • Page 3 Warranty The warranty card is supplied as a separate document. In case of any queries, refer to the brand website of your unit or system: www.simrad-yachting.com Compliance statements Europe Navico declare under our sole responsibility that the product conforms with the requirements of: •...
  • Page 4 If you are unsure, contact your service provider to confirm rates and restrictions. Trademarks ® Navico is a registered trademark of Navico Holding AS. ® Simrad is used by license from Kongsberg. ® ™ HDMI and HDMI , the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
  • Page 5 Translated manuals Available translated versions of this manual can be found on the following website: • www.simrad-yachting.com Preface | NSO evo3S MPU Installation Manual...

  • Page 6: Table Of Contents

    Contents Introduction System overview Operating the system Parts included Connectors Card reader 10 Installation General mounting guidelines Wall mounting 12 Wiring Access to connectors Wiring guidelines Control devices Monitors Power NMEA 2000 Serial port Ethernet USB port Video in HDMI out 21 System setup First time startup Software setup sequence...

  • Page 7: Introduction

    Introduction System overview The basic system consists of the processor and one or two monitors. The system can be configured and installed in various configurations: • One processor with one monitor (A) • One processor with two independent monitors (B) •...

  • Page 8: Parts Included

    Parts included NSO evo3S Marine Processor Unit (MPU) MPU Power cable, 2 m (6.5') Micro-C power cable, 1.3 m (4.3') Micro-C drop cable, male-female plugs, 1.8 m (6') Micro-C T-connectors (x3) Micro-C terminators, 120 ohm, (male and female) NMEA 0183 serial cable, 8 wires, 2 m (6.5') Ethernet adaptor, 5 pin female to RJ45 male Installation kit: •...

  • Page 9: Connectors

    Connectors NETWORK 1 NETWORK 3 VIDEO 1 IN HDMI 1 OUT PoE 15W USB 1 NMEA2000 SERIAL 1 SERIAL 2 POWER COMBINED 45W MAX NETWORK 2 USB 2 VIDEO 2 IN HDMI 2 OUT SD CARD Network 1 and Network 2 ports (Ethernet with PoE) Network 3 (Ethernet) Video 1 IN and Video 2 IN HDMI 1 OUT and HDMI 2 OUT...

  • Page 10: Installation

    Installation General mounting guidelines Warning: Do not install the unit in a hazardous/flammable atmosphere. Ú Note: Choose a mounting location that will not expose the unit to conditions that exceed the technical specifications. Mounting location This product generates heat which must be considered when choosing the mounting location.

  • Page 11: Wall Mounting

    Electrical and radio frequency interference This unit conforms to the appropriate Electromagnetic Compatibility (EMC) regulations. To ensure that the EMC performance is not compromised, the following guidelines apply: • Separate battery used for the vessel engine. • Minimum 1 m (3 ft) between the device, the device's cables and any transmitting equipment or cables with radio signals.

  • Page 12: Wiring

    Wiring Access to connectors For easier access to connectors, remove the bottom front of the unit. Wiring guidelines Don't: • Make sharp bends in the cables. • Run cables in a way that allows water to flow down into the connectors. •...

  • Page 13: Power

    Power The power connector is used for power, power control and for external alarm output. Power connector details Unit socket (male) Purpose DC negative External alarm Power control +12/24 V DC Power connection The unit is designed to be powered by 12 or 24 V DC system. It is protected against reverse polarity, under voltage, and over voltage (for a limited duration).
  • Page 14 Purpose Color Power control wire, connected to supply power Yellow Power controlled by ignition The unit will turn on once ignition is turned on to start engines. Ú Note: Engine start batteries and house batteries should have a common ground connection.

  • Page 15: Nmea 2000

    slave units. If a unit is set to power control slave, it cannot be powered down using its own power key while a power control master unit is turned on. Pressing the power key will set the unit to standby. If all power control masters are off, power control slaves can be turned on and off using their own power key.

  • Page 16: Serial Port

    Plan and install an NMEA 2000 network An NMEA 2000 network consists of a powered backbone from which drop cables connect to NMEA 2000 devices. The backbone needs to run within 6 m (20 ft) of the locations of all products to be connected, typically in a bow to stern layout.
  • Page 17 Connector details Unit socket (male) Purpose NMEA 0183 Listener B (Rx_B) NMEA 0183 Listener A (Rx_A) NMEA 0183 Talker B (Tx_B) NMEA 0183 Talker A (Tx_A) Touch screen RS422 Talker + (Tx+) Touch screen RS422 Talker - (Tx-) Touch screen RS422 Listener - (Rx-) Touch screen RS422 Listener + (Rx+) NMEA 0183 and Touch screen control, cable details Description...

  • Page 18: Ethernet

    Units with a 5-pin yellow Ethernet connector will require an adapter cable to connect to this unit. For more details about the available adapter cables, refer to the brand website of your unit: www.simrad-yachting.com Wiring | NSO evo3S MPU Installation Manual...

  • Page 19: Usb Port

    Ethernet expansion device Connection of network devices can be made via an Ethernet expansion device. Additional expansion devices can be added to provide the required number of ports. USB port The USB port can be used to: • Connect a keyboard. •...

  • Page 20: Hdmi Out

    Video input configuration Configurations to video input are made in the video panel. Refer to the Operator Manual for more information. HDMI out The HDMI port(s) is used for connecting monitor(s). The connected monitor should support the resolution listed in the Technical specifications, or be able to scale.

  • Page 21: System Setup

    System setup First time startup When the unit is started for the first time, or after a reset, the unit displays a series of dialogs. Respond to the dialog prompts to make fundamental settings. You can perform further setup and later change settings using the system settings dialogs. Software setup sequence This setup sequence focus on the settings done during installation and setup of the system.
  • Page 22 Ú Note: Record the PIN code and store it in a safe place. When you establish password protection, the PIN code must be entered when any of the following are selected. After the correct PIN code is entered, all of them can be accessed without re-entering the PIN code.

  • Page 23: Alarms

    Use SOG as boat speed If boat speed is not available from a paddle wheel sensor, it is possible to use speed over ground from a GPS. SOG will be displayed as boat speed and used in the true wind calculations and the speed log.
  • Page 24 Adjust antenna height Set the radar scanner height relative to the water surface. The Radar uses this value to calculate the correct STC settings. Select antenna length Select the proper antenna length. Adjust range offset The radar sweep should commence at your vessel (a radar range of zero). You may need to adjust the radar range offset to achieve this.
  • Page 25 other directions. This energy is referred to as sidelobe energy and occurs in all radar systems. The returns caused by sidelobes tend to appear as arcs. Ú Note: This control should only be adjusted by experienced radar users. Target loss in harbor environments may occur if this control is not adjusted correctly.

  • Page 26: Echosounder Settings

    Reset radar to factory defaults Clears all user and installer settings applied to the selected radar source, and restores factory settings. Ú Note: Use this option with caution. Take note of current settings first, especially those set by the operator if radar has already been in active service. Echosounder settings A compatible echosounder module (or another unit which has built-in sonar) shared over the Ethernet network is required to view echosounder images on the unit.
  • Page 27 • To show the depth from the lowest point of the vessel to the bottom, set the offset equal to the vertical distance between the transducer and the lowest part of the vessel, A (negative value). • To show the depth from the water surface to the bottom, set the offset equal to the vertical distance between the transducer and the water surface, B (positive value) •...
  • Page 28 • To show the depth from the lowest point of the vessel to the bottom, set the offset equal to the vertical distance between the transducer and the lowest part of the vessel, A (negative value). • To show the depth from the water surface to the bottom, set the offset equal to the vertical distance between the transducer and the water surface, B (positive value) •...

  • Page 29: Autopilot Settings

    Restore echosounder defaults Restore echosounder settings to the factory supplied defaults. Use depth and temp data from Selects from which source the depth and temperature data is shared on the NMEA 2000 network. ForwardScan installation Available when the ForwardScan feature is connected. For setup information, refer to the Operator Manual.

  • Page 30: Fuel Settings

    • confirm that the motor can be manually moved smoothly in each direction • check for other mechanical issues • check wiring connections • repeat the rudder calibration. Hydraulic system calibration Virtual rudder feedback (VRF) calibration is used for vessels with hydraulic steering when no rudder feedback is available.
  • Page 31 Vessel setup The Vessel setup dialog must be used to select the number of engines, the number of tanks and vessel’s total fuel capacity across all tanks. Fuel remaining measurement The Fuel remaining measurement can be determined from fuel used by engine(s), or fuel level from tank sensors.

  • Page 32: Wireless Settings

    Select OK to save settings. The Fuel K-Value should now show a new value. Ú Note: To calibrate multiple engines repeat the steps above, one engine at a time. Alternatively, run all engines simultaneously, and divide the Actual amount used by the number of engines.
  • Page 33 If the unit is part of a source group, all source selection changes will affect all units belonging to the same group. Ú Note: In order to enable group selection, the unit must be set to the Simrad group. Devices with no selected group can use different sources than the rest of the network devices.
  • Page 34 Provides information on Ethernet activity. SimNet groups This function is used to control parameter settings, either globally or in groups of units. The function is used on larger vessels where several units are connected to the NMEA 2000 network. By assigning several units to the same group, a parameter update on one unit will have the same effect on the rest of the group members.
  • Page 35 the data that is required. The less sentences that are selected, the higher the output rate of the enabled sentences. Ethernet/WiFi The NMEA 0183 data stream is output and made available to tablet devices and PCs, via WiFi or Ethernet connection. The dialogue provides IP and port data typically required for configuring the application on the third party device.

  • Page 36: 3Rd Party Support

    3rd party support CZone CZone connection to NMEA 2000 When interfacing to CZone network it is recommended to use a BEP Network interface bridge to join the two network backbones together. The CZone / NMEA 2000 Network interface bridge isolates the power of the two networks, but allows data to be freely shared between both sides.

  • Page 37: Naviop

    Compatible FLIR cameras are plug and play when used in conjunction with a device acting as a DHCP host. For setup on networks not utilizing a DHCP host, refer to the website www.simrad-yachting.com, or contact technical support. 3rd party support...

  • Page 38: Dimensional Drawings

    Dimensional drawings NSO evo3S MPU Dimensional drawings | NSO evo3S MPU Installation Manual...

  • Page 39: Technical Specifications

    Technical specifications NSO evo3S MPU Electrical Supply voltage 9 - 31.2 V DC Power consumption - Max 45 W Power consumption - OFF 1 W Recommended fuse rating 3 Amp Low power standby mode Yes Protection Reverse polarity and temporary over-voltage to 36 V Alarm output current 1 Amp Processors iMX8 Quad Max (x2)

  • Page 40: Supported Data

    Supported data NMEA 2000 compliant PGN List NMEA 2000 PGN (receive) 59392 ISO Acknowledgement 59904 ISO Request 60160 ISO Transport Protocol, Data Transfer 60416 ISO Transport Protocol, Connection M. 65240 ISO Commanded Address 60928 ISO Address Claim 126208 ISO Command Group Function 126992 System Time 126996...
  • Page 41 129041 AIS aids to Navigation 129283 Cross Track Error 129284 Navigation Data 129539 GNSS DOPs 129540 AIS Class B Extended Position Report 129545 GNSS RAIM Output 129549 DGNSS Corrections 129551 GNSS Differential Correction Receiver Signal 129793 AIS UTC and Date Report 129794 AIS aids to Navigation 129798...
  • Page 42 130584 Entertainment - Bluetooth Devices 130585 Entertainment - Bluetooth Source Status NMEA 2000 PGN (transmit) 60160 ISO Transport Protocol, Data Transfer 60416 ISO Transport Protocol, Connection M. 126208 ISO Command Group Function 126992 System Time 126993 Heartbeat 126996 Product Info 127237 Heading/Track Control 127250...

  • Page 43: Nmea 0183 Supported Sentences

    NMEA 0183 supported sentences TX / RX - GPS Name Description Datum reference Global positioning system (GPS) fix data Geographic position - Loran-C Geograpic position - Latitude/longitude GNSS DOP and active satellites GNSS fix data GNSS satellites in view Course over ground and ground speed Time and date TX / RX - Navigation Name...
  • Page 44 TX / RX - Wind Name Description Wind direction and speed Wind speed and angle TX / RX - AIS / DSC Name Description Digital selective calling information Expanded digital selective calling AIS VHF data-link message AIS VHF data-link own-vessel report Ú...
