TYPE K TEMPERATURE MEASUREMENTS

CAUTION

The supplied thermocouple is rated for 482℉ (250℃) maximum.

1. Place the input shutter switch in the lower position.

2. Rotate the function switch to the TYPE K position. Press MODE

to select °F or °C.

3. Insert the temperature probe(s) into the thermocouple jacks, ob-

serving correct polarity.

4. Touch the probe tip(s) to the surface under test. Read the tem-

perature measurement on the display. Use the T1–T2 button to

select a display mode.
