SPECIFICATIONS

Service Ref.
Power supply(phase, cycle, voltage)
Max. Fuse Size
Min.Circuit Ampacity
External finish
Heat exchanger
Fan Fan(drive) × No.
Fan motor output
Fan motor
Airflow(Low-Medium2-Medium1-High)
External static pressure
Operation control & Thermostat
Noise level(Low-Medium2-Medium1-High)
Field drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply(phase, cycle, voltage)
Max. Fuse Size
Min.Circuit Ampacity
External finish
Heat exchanger
Fan Fan(drive) × No.
Fan motor output
Fan motor
Airflow(Low-Medium2-Medium1-High)
External static pressure
Operation control & Thermostat
Noise level(Low-Medium2-Medium1-High)
Field drain pipe O.D.
Dimensions
Weight
Service Ref.
Power supply(phase, cycle, voltage)
Max. Fuse Size
Min.Circuit Ampacity
External finish
Heat exchanger
Fan Fan(drive) × No.
Fan motor output
Fan motor
Airflow(Low-Medium2-Medium1-High)
External static pressure
Operation control & Thermostat
Noise level(Low-Medium2-Medium1-High)
Field drain pipe O.D.
Dimensions
Weight
TCH113
A
A
kW
F.L.A
CFM (m³/min)
Pa (mmAq)
dB
inch (mm)
W inch (mm)
D inch (mm)
H inch (mm)
lb (kg)
A
A
kW
F.L.A
CFM (m³/min)
Pa (mmAq)
dB
inch (mm)
inch (mm)
W
D inch (mm)
H inch (mm)
lb (kg)
A
A
kW
F.L.A
CFM (m³/min)
Pa (mmAq)
dB
inch (mm)
W inch (mm)
D inch (mm)
H inch (mm)
lb (kg)
7
PCA-A24KA8
1 phase, 60 Hz, 208/230 V
15
1
White Munsell 6.4Y 8.9/0.4
Plate fin coil
Sirocco fan (direct) × 3
0.095
1.25
Dry: 530-565-600-670 (15-16-17-19)
Wet: 495-530-565-635 (14-15-16-18)
0 (direct blow)
Remote controller & built-in
33-35-37-40
1-1/32 (26)
50-3/8 (1,280)
26-3/4 (680)
9-1/16 (230)
71 (32)
PCA-A30KA8
1 phase, 60 Hz, 208/230 V
15
1
White Munsell 6.4Y 8.9/0.4
Plate fin coil
Sirocco fan (direct) × 3
0.095
1.25
Dry: 565-600-635-705 (16-17-18-20)
Wet: 530-565-600-670 (15-16-17-19)
0 (direct blow)
Remote controller & built-in
35-37-39-41
1-1/32 (26)
50-3/8 (1,280)
26-3/4 (680)
9-1/16 (230)
71 (32)
PCA-A36KA8
1 phase, 60 Hz, 208/230 V
15
2
White Munsell 6.4Y 8.9/0.4
Plate fin coil
Sirocco fan (direct) × 4
0.160
1.51
Dry: 775-850-920-990 (22-24-26-28)
Wet: 705-775-850-920 (20-22-24-26)
0 (direct blow)
Remote controller & built-in
37-39-41-43
1-1/32 (26)
63 (1,600)
26-3/4 (680)
9-1/16 (230)
79 (36)
