1

REFERENCE MANUAL

OUTDOOR UNIT SERVICE MANUAL
Model Name
PUZ-A24/30NHA7
PUZ-A36/42NKA7
PUY-A24/30NHA7
PUY-A36/42NKA7
PUZ-A24/30NHA8
PUZ-A36/42NKA8
PUY-A24/30NHA8
PUY-A36/42NKA8
PUZ-HA24NHA1
PUZ-HA30/36NKA
PUZ-HA42NKA1
MXZ-3C30NA2
MXZ-4C36NA2
MXZ-5C42NA2
MXZ-3C30NAHZ2
MXZ-3C30NA3
MXZ-4C36NA3
MXZ-5C42NA3
MXZ-3C30NAHZ3
MXZ-3C30NA4
MXZ-4C36NA4
MXZ-5C42NA4
MXZ-3C30NAHZ4
Remote controller (Optional parts)
Wired remote controller
RETURN SELECT
MENU
HOLD
TCH113
Service Ref.
PUZ-A24/30NHA7
PUZ-A36/42NKA7
PUY-A24/30NHA7
PUY-A36/42NKA7
PUZ-A24/30NHA8
PUZ-A36/42NKA8
PUY-A24/30NHA8
PUY-A36/42NKA8
PUZ-HA24NHA1
PUZ-HA30/36NKA
PUZ-HA42NKA1
MXZ-3C30NA2 (-U1)
MXZ-4C36NA2 (-U1)
MXZ-5C42NA2 (-U1)
MXZ-3C30NAHZ2 (-U1)
MXZ-3C30NA3 (-U1)
MXZ-4C36NA3 (-U1)
MXZ-5C42NA3 (-U1)
MXZ-3C30NAHZ3 (-U1)
MXZ-3C30NA4-U1
MXZ-4C36NA4-U1
MXZ-5C42NA4-U1
MXZ-3C30NAHZ4-U1
ON
OFF
Service Manual No. / Parts catalog No.
Wireless remote controller
2
OCH636 / OCB636
OCH764 / OCB764
OCH750 / OCB750
OBH702 / OBB702
