Panasonic LUMIX DMC-ZS45P Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DMC-ZS45P
Model No.
DMC-ZS45PC
DMC-ZS45PR
DMC-ZS45PU
DMC-ZS45GK
DMC-ZS45GT
DMC-TZ57EB
DMC-TZ57EE
DMC-TZ57EF
DMC-TZ57EG
DMC-TZ57EP
DMC-TZ57GA
DMC-TZ57GC
DMC-TZ57GN
DMC-TZ58EG
Colour
(K)...........Black Type
(W)..........White Type (except PR/GC)
(T)...........Brown (except P/PC/PR)
© Panasonic Corporation 2015 Unauthorized copy-
ing and distribution is a violation of law.
ORDER NO. DSC1502004CE
B26
Digital Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUMIX DMC-ZS45P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic LUMIX DMC-ZS45P

Summary of Contents for Panasonic LUMIX DMC-ZS45P

  • Page 1 Model No. DMC-ZS45PC DMC-ZS45PR DMC-ZS45PU DMC-ZS45GK DMC-ZS45GT DMC-TZ57EB DMC-TZ57EE DMC-TZ57EF DMC-TZ57EG DMC-TZ57EP DMC-TZ57GA DMC-TZ57GC DMC-TZ57GN DMC-TZ58EG Colour (K)...Black Type (W)..White Type (except PR/GC) (T)...Brown (except P/PC/PR) © Panasonic Corporation 2015 Unauthorized copy- ing and distribution is a violation of law.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -----------------------------------------------3 1.1. General Guidelines ----------------------------------------3 1.2. Leakage Current Cold Check ---------------------------3 1.3. Leakage Current Hot Check (See Figure. 1)--------3 1.4. How to Discharge the E.Capacitor on Flash P.C.B. Unit ---------------------------------------------------4 2 Warning --------------------------------------------------------------5 2.1.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check 1. IMPORTANT SAFETY NOTICE (See Figure. 1) There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check.

  • Page 4: How To Discharge The E.capacitor On Flash P.c.b. Unit

    1.4. How to Discharge the E.Capacitor on Flash P.C.B. Unit CAUTION: • Be sure to discharge the E.Capacitor on Flash P.C.B. Unit before disassembling. • Be careful of the high voltage circuit on Flash P.C.B. Unit when servicing. [Discharging procedure] 1.

  • Page 5: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).
  • Page 6 NOTE: Above caution is applicable for a battery pack which is for DMC-ZS45/TZ57/TZ58 series, as well.

  • Page 7: Service Navigation

    3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2.

  • Page 8: Service Notes

    3.3. Service Notes 3.3.1. About Wi-Fi Function...
  • Page 9 3.3.2. Important Notice of Servicing This camera unit has the personal information of wireless LAN connection the customer has registered. For the protection of private information, please erase the personal information after the completion of repair by “Initial Settings”. In addition, please print out the following documents, and pass to the customer with the camera unit. Printing material [ Leaflet for customer ] [For The Customer] Before using your camera please check the Wi-Fi settings.

  • Page 10: General Description About Lead Free Solder (Pbf)

    3.4. General Description About Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin (Sn), silver (Ag) and copper (Cu), and the melting point of the lead free solder is higher approx.30°C (86°F) more than that of the normal solder.

  • Page 11: How To Define The Model Suffix (Ntsc Or Pal Model)

    3.5. How to Define the Model Suffix (NTSC or PAL Model) There are eight kinds of DMC-ZS45, DMC-TZ57 and DMC-TZ58, regardless of the colours. • a) DMC-TZ57 (Japan domestic model) • b) DMC-ZS45P/PC • c) DMC-TZ57EB/EF/EG/EP, DMC-TZ58EG • d) DMC-TZ57EE •...
  • Page 12 3.5.2. Initial Settings: 1. Copy the contents of the “CK-TZ57 Sales Area Setting Tool” to a folder in Windows 7 PC. Note: The Initial Setting Tool is available at “TSN Website”. First of all, it is necessary installing the USB driver. Refer to the procedure described in “9.4.2.

  • Page 13: Specifications

    4 Specifications The following specification is for DMC-ZS45PC. Some specifications may differ depending on model suffix.

  • Page 14: Location Of Controls And Components

    5 Location of Controls and Components The following description is for DMC-ZS45PC. Some descriptions may differ depending on model suffix.

  • Page 15: Troubleshooting Guide

    6 Troubleshooting Guide 6.1. Wi-Fi Circuit (Flash P.C.B. Unit) 6.1.1. How to Remove Wi-Fi Password Protection To prevent incorrect operation or use of the Wi-Fi function by a third party and to protect saved personal information, this unit pro- tects the Wi-Fi function with a password. It is unable to service with password locked condition.

  • Page 16: Service Fixture & Tools

    7 Service Fixture & Tools 7.1. Service Fixture and Tools The following service fixture and tools are used for checking and servicing this unit. 7.2. When Replacing the Main P.C.B. After replacing the Main P.C.B., be sure to achieve adjustment.

  • Page 17: Disassembly And Assembly Instructions

    8 Disassembly and Assembly Instructions 8.1. Disassembly Flow Chart This is a disassembling chart. When assembling, perform this chart conversely. 8.2. P.C.B. Location...

  • Page 18: Disassembly Procedure

    8.3. Disassembly Procedure Item Fig. Removal LCD Hinge Cover (Fig. D1) Screw (A) x 2 Unit Screw (B) x 2 Screw (C) x 2 (Fig. D2) Locking tab x 9 LCD Hinge Cover Unit Rear Case Unit (Fig. D3) Screw (D) x 4 Screw (E) x 1 Locking tab x 2 (Fig.
  • Page 19 8.3.1. Removal of the LCD Hinge Cover Unit (Fig. D2) (Fig. D1)
  • Page 20 8.3.2. Removal of the Rear Case Unit (Fig. D4) 8.3.3. Removal of the LCD Unit (Fig. D3) (Fig. D5)
  • Page 21 8.3.4. Removal of the Front Case Unit (Fig. D7) (Fig. D6)
  • Page 22 8.3.5. Removal of the Top Case Unit (Fig. D9) (Fig. D8)
  • Page 23 (Fig. D10) 8.3.6. Removal of the Frame Plate Unit (Fig. D12) (Fig. D11)
  • Page 24 8.3.7. Removal of the Lens Unit 8.3.8. Removal of the Flash P.C.B. Unit (Fig. D14) (Fig. D13)
  • Page 25 8.3.10. Removal of the Main P.C.B. (Fig. D15) 8.3.9. Removal of the AF P.C.B. Unit (Fig. D17) (Fig. D16)
  • Page 26 8.3.11. Removal of the Battery Door Unit (Fig. D18) (Fig. D19) NOTE: (When Installing) Make sure to confirm the following points when installing: • The screw is tightened enough. • Installing conditions are fine. (No distortion, no abnormal- space.) • No dust and/or dirt on lens surfaces. •...

  • Page 27: Lens Disassembly Procedure

    8.4. Lens Disassembly Procedure 2. Remove the Shutter FPC. 3. Remove the Lens FPC from the positioning boss. Precaution: 4. Remove the Master Flange Unit and Drive Gear. 1. Do not remove the MOS Unit when disassembling or re- assembling the lens in order to maintain it clean. When remove it, refer to item “8.6”.
  • Page 28 8.4.2. Removal of the Drive Frame Unit, 8.4.3. Removal of the Decorative Frame Decorative Frame Unit, Outside Unit, Outside Cam Frame, 1st Lens Cam Frame, 1st Lens Frame Unit, Frame Unit, 2nd Lens Frame Unit, 2nd Lens Frame Unit, 3rd Lens 3rd Lens Frame Unit, Straight Frame Unit, Straight Frame and Frame and Both Side Cam Frame...
  • Page 29 8.4.4. Removal of the Outside Cam 8.4.5. Removal of the 1st Lens Frame Frame, 1st Lens Frame Unit, 2nd Unit, 2nd Lens Frame Unit, 3rd Lens Frame Unit, 3rd Lens Frame Lens Frame Unit, Straight Frame Unit, Straight Frame and Both Side and Both Side Cam Frame Cam Frame •...
  • Page 30 8.4.7. Removal of the 2nd Lens Frame 8.4.8. Removal of the 3rd Lens Frame Unit Unit 1. Hold the Straight Frame and turn it in the arrow (1) so that • Push the 3rd Lens Frame Unit in the arrow direction from the mark (2nd Lens Frame Unit) meets the mark front of the Lens, and remove the 3rd Lens Frame Unit from...

  • Page 31: Assembly Procedure For Lens (Revised Version)

    8.5. Assembly Procedure for Lens 3. Turn the Straight Frame about 90 degrees in the arrow direction so that the mark of Straight Frame comes (Revised Version) close to the mark of Both Side Cam Frame. *As the drawing below indicates, align the Grooves of 8.5.1.
  • Page 32 2. Insert the 2nd Lens Frame Unit as the drawing below 3. While pushing the 3rd Lens Frame Unit and the 2nd Lens indicated. Frame Unit, turn the Straight Frame Unit in the arrow *Align the mark of the 2nd Lens Frame Unit with the direction to the end.(about 30 degree) one of the Straight Frame Unit, then put the each Cam *Need to confirm that the two Lens Frames move...
  • Page 33 8.5.3. Insert the 1st Lens Frame Unit and 2. Move the mark of the Both Side Cam Frame Unit closer to the mark of the Outside Cam Frame Unit, then turn the Outside Cam Frame Unit the 1st Lens Frame Unit just a bit in the arrow 1.
  • Page 34 4. Turn the Both Side Cam Frame Unit to the end in the 8.5.4. Insert the Decorative Frame Unit arrow direction while holding the Outside Cam Frame 1. Hold the Straight Key (Both Side Cam Frame), turn it in Unit. (About 118.5 degrees) the arrow direction and align with the Straight Key (Out- *Confirm that 1st Lens Frame Unit does not rotate when side Cam Frame).
  • Page 35 3. Align the mark (Decorative Frame) with the Straight 8.5.5. Insert the Drive Frame Unit Key (Both Side Cam Frame), and install the Unit of • Align the mark (Drive Frame and Outside Cam Frame), Outside Cam Frame,1st Lens Frame Unit, 2nd Lens and install the Unit of Decorative Frame Unit, Outside Cam Frame Unite, 3rd Lens Frame Unite, Straight Frame and Frame, 1st Lens Frame Unit, 2nd Lens Frame Unite, 3rd...
  • Page 36 8.5.6. Insert the Fix Frame Unit 8.5.7. Insert the Master Flange Unit 1. Install the Drive Gear to the Fix Cam Frame Unit. Note: (When Installing) Take Care not to damage the flex. 2. Align the mark (Outside Cam Frame and Drive Frame Take Care not to tuck in to the Master Flange Unit, When and Fix Cam Frame), and install the Unit of Drive Frame inserting the Shutter Flex.

  • Page 37: Removal Of The Mos Unit

    8.6. Removal of the MOS Unit 5. Join the Zoom Motor Unit to the Boss, and install to the Fix Cam Frame. When remove the MOS Unit once (the Torx screw (A) is loosened even a little), the optical tilt adjustment is required.

  • Page 38: Measurements And Adjustments

    9 Measurements and Adjustments 9.1. Introduction When servicing this unit, make sure to perform the adjustments necessary based on the part(s) replaced. NOTE: (When replacing the Lens unit, Master flange unit and MOS Unit) • When the MOS Unit is unavoidably removed for Lens unit, Master flange unit and MOS Unit replaced, an optical adjustment is necessary after parts are exchanged.

  • Page 39: Matrix Chart (Replaced Part And Adjustment Item)

    [ For RFKZ0523 Light Box ] 9.3. Matrix Chart (Replaced Part and Adjustment Item) The following matrix table shows the relation between the replaced part and the necessary adjustment. When a part is replaced, make sure to perform the necessary adjustment(s) in the order indicated. Note: (*1) •...

  • Page 40: Adjustment Procedure

    9.4. Adjustment Procedure 9.4.1. DSC_Tilt Procedure • ZS45/TZ57/TZ58 require the DSC_Tilt adjustment when repairing Lens parts. • Please use the DSC_Tilt software provided on WEB site. NOTE: The adjustment procedure is a little different from other model as below. For detail, refer to “DSC_Tilt OPERATION MANUAL” of “DSC_Tilt” software. 9.4.2.
  • Page 41 9.4.3. VR Hall/OC Calibration 9.4.4. MB/LCD Function Check (1) Preparation (1) Preparation 1. Attach the fully charged Battery to the camera. 1. Attach the fully charged Battery to the camera. 2. Turn the power off. 2. Insert Memory Card. 3. Rotate Zoom lever towards “[ T ](Tele)” and press 3.
  • Page 42 4. Checking Items are executed in turn automatically as fol- 2. Change the value of “Disable” from “000001” to “000000” lows. by Cursor buttons, then press [ MENU/SET ] button twice. • RTC: Check the Crystal RTC • Iris: Check the Iris operation •...
  • Page 43 9.4.6. WB/AGC Calibration d. Select the item “P2 B Ratio”, and change the value to “000672”. (1) Preparation “P2 B Ratio” may not be displayed. In this case, (If the calibration is done right after previous calibration, changing the value of these items are unnecessary. skip the 1 to 4 procedure.) 1.
  • Page 44 9.4.7. MeShut Calibration d. Select the item “P2 B Ratio”, and change the value to “000672”. (1) Preparation “P2 B Ratio” may not be displayed. In this case, (If the calibration is done right after previous calibration, changing the value of these items are unnecessary. skip the 1 to 5 procedure.) 1.
  • Page 45 4. When the calibration is finished, the result “OK” or “NG” is 9.4.8. Dark DP Calibration displayed. (1) Preparation (If the calibration is done right after previous calibration, skip the 1 to 5 procedure.) 1. Attach the fully charged Battery to the camera. 2.
  • Page 46 6. It is no problem if “X” mark of “Light/S.S” item is dis- 3. Select “OK”, then press [ MENU/SET ] button to start the played. calibration. This means it is necessary to execute the “Light/S.S/Pre- view” calibration. 4. When the calibration is finished, the result “OK” or “NG” is displayed.
  • Page 47 3. Select “OK”, then press [ MENU/SET ] button to start the (2) Execute the Flash WB Calibration 1. Choose “FLASH WB” by Cursor buttons, then press calibration. [ Playback ] button. 4. When the calibration is finished, the result “OK” or “NG” is 2.
  • Page 48 9.4.12. Boot Type and USB Mode setting 5. Rotate Zoom lever towards "[T](Tele)" and press [MENU/ SET] button, [Playback] button simultaneously for a few (1) Preparation seconds. (If the calibration is done right after previous calibration, (The camera is turned on by engineer mode automati- skip the 1 to 4 procedure.) cally.) 1.
  • Page 49 9.4.13. Wi-Fi Flag Check 1. Copy the contents of the “CK-TZ57 Write WiFi Flag AP” to a folder in Windows 7 PC. 2. Attach the fully charged Battery to the camera. 3. Turn the power off. 4. Rotate Zoom lever towards “[ T ](Tele)” and press [ MENU/SET ] button, [ Playback ] button simultaneously for a few seconds. (The camera is turned on by engineer mode automatically.) 5.

  • Page 50: Maintenance

    10 Maintenance 10.1. Cleaning Lens and LCD Panel Do not touch the surface of lens and LCD panel with your hand. When cleaning the lens, use air-blower to blow off the dust. When cleaning the LCD panel, dampen the lens cleaning paper with lens cleaner, and the gently wipe the its surface. Note: The Lens Cleaning Kit ;...

  • Page 51: Wiring Connection Diagram

    11 Wiring Connection Diagram 11.1. Interconnection Diagram FLASH P.C.B. UNIT FLASH UNIT LCD UNIT VLED- VLED+ AVDD NAVDD NGVDD GVDD VREF (BU) C41P C41N C51P C51N FLASH P.C.B. (FOIL SIDE) (COMPONENT SIDE) VSYNC HSYNC DCLK AF P.C.B. VDDIO (FOIL SIDE) VDD_18V C14N C14P...
