  • Page 1 OM100 Ultrasonic Homogenizer User Manual...
  • Page 2: Warranty

    1. WARRANTY Your OM100 Ultrasonic Homogenizer is warranted and backed by the manufacturer for a period of two years from the date of shipment against defects in material and work- manship under normal use as described in this instruction manual. During the warranty...
  • Page 3 • Install the OM100 Ultrasonic Homogenizer in an area free from excessive dust, dirt, explosive or corrosive fumes and protected from extremes in temperature and hu- midity. Do not place the Generator within a Fume Hood.
  • Page 4: Specifications

    3. SPECIFICATIONS Power Supply Part Number 29-060-100-120 29-060-100-220 Input Voltage 108 to 132 VAC @ 50/60 Hz 198 to 264 VAC @ 50/60 Hz Rated Current 2.4 Amps max. 1.2 Amps max. Fuse Rating 3 Amps Slow Blow 1.6 Amps Slow Blow Weight 7 lbs.
  • Page 5 Substances (ROHS) Other For indoor use only The Power Cord supplied with the OM100 Ultrasonic Homogenizer must be used. If the 220V plug is not configured to match the wall receptacle, a properly grounded universal AC socket adapter must be added.
  • Page 6: Principles Of Operation

    4. PRINCIPLES OF OPERATION The OM100 ultrasonic power supply transforms AC line power to a 20 KHz signal that drives a piezoelectric converter/transducer. This electrical signal is converted by the transducer to a mechanical vibration due to the characteristics of the internal piezo- electric crystals.
  • Page 7 The OM100 ultrasonic homogenizer was designed to deliver constant amplitude to your liquid sample, regardless of these changes in load (much like the vehicle’s cruise control described above). As a liquid is processed, the load on the probe will vary due to changes in the liquid sample (i.e., viscosity, concentration, temperature, etc.).
  • Page 8 5. DESCRIPTIONS OF COMPONENTS / FUNCTIONS OF CONTROLS 5.1. OM100 FRONT PANEL Convertor Cable Convertor Probe Power Supply Lab Stand with Clamp 5.1. OM100 REAR PANEL Power Cord Connector Cooling Fan 9 Pin Connector Convertor Cable Connector Footswitch Jack...
  • Page 9 Used to enter the amplitude selected, and view REVIEW amplitude, power, and energy START/STOP Starts or stops the OM100 ultrasonics. In the STOP mode the red indicator goes off. Switches the main power on. Switches the main power off. Used with the numeric keys to set the duration of TIMER ultrasonic application –...
  • Page 10 REAR PANEL Connects to external actuation device, and enable 9 pin D-sub connector (IO Port) power and frequency monitoring. Connects to the footswitch cable. Footswitch Connector Connects to the converter. Converter Cable Connector (Output) Connects to the electrical line cord and encases Power Supply Connector the fuse(s).
  • Page 11 5.4. CONVERTER CLAMPING Improper clamping can damage the system and void the warranty. Using a sound en- closure (part #060-12) or stand (part #060-10) will ensure a proper fit. Proper Clamping Improper Clamping...
  • Page 12: Electrical Requirements

    INSTALLING THE OM100 ULTRASONIC HOMOGENIZER The OM100 Ultrasonic Homogenizer should be installed in an area that is free from ex- cessive dust, dirt, explosive and corrosive fumes, and extremes of temperature and hu- midity.
  • Page 13 7. OPERATING INSTRUCTIONS 7.1. CAUTION • Do not operate continuously for more than 1 minute. • Do not operate the power supply unless it is connected to the converter. • Never allow liquid to spill into the converter. • Do not allow a probe to vibrate in air for more than 10 seconds. •...
  • Page 14: Operation

    7.3. OPERATION Press the ON ON key. The screen will display the power rating of the OM100 Ultrasonic Ho- mogenizer and the following control parameters. AMPLITUDE: Desired amplitude must be set in order for the OM100 Ultrasonic Homog- enizer to be operational. The other control parameters – Time and Pulse, do not have to be set for continuous operation.
  • Page 15 1. To set the processing time, press the TIMER key. The screen will display: 2. Using the numeric keys, set the processing time as required, for example: 3. Press the ENTER/REVIEW key. The screen will display: PULSER: Ultrasonics generates heat. Pulsing ultrasonics on and off helps to prevent heat build-up in temperature sensitive samples.
  • Page 16 REVIEW: The REVIEW function provides a “window” on the process by displaying various operating parameters without process interruption. Pressing the ENTER/REVIEW key repeatedly during processing will consecutively display the following information. a) Selected amplitude: e.g. Amplitude 40% b) Selected processing time and elapsed processing time: e.g.
  • Page 17: Probe Maintenance

    8. MAINTENANCE It is recommended to periodically inspect the unit, both visually and physically, to ensure optimum and safe performance. This inspection should be scheduled as a routine maintenance procedure, done with the unit power OFF and with the unit un- plugged from the AC power source.
  • Page 18 8.2. ATTACHING & DETACHING MICROTIPS 1. Disconnect probe from convertor. Use the wrench set provided with the system. 2. Clean threaded stud. Use alcohol and a cotton swab to remove any debris on the threading of the connecting stud. Allow the alcohol to dry completely. 3.
  • Page 19: Troubleshooting

    OM100 Ultrasonic Homogenizer should be returned for repair. OVERLOAD CONDITION If the OM100 Ultrasonic Homogenizer stops working, and an OVERLOAD indication is displayed on the screen, check for possible causes as outlined in the above paragraph, then press the OFF key to switch the unit off, and the ON key to switch the unit back on.
  • Page 20: Frequently Asked Questions

    10. FREQUENTLY ASKED QUESTIONS Probe size vs. Sample volume Selecting the proper size probe is a critical factor when sonicating a sample. The sample volume to be processed must correlate with the tip diameter. Each probe has a recom- mended sample volume range. This range may overlap with other probes. For example the 1/8”...
  • Page 21 The probe should be submerged approximately halfway into the liquid but there are exceptions. Before processing actual samples, it is recommended to test the probe in a vessel filled with water to observe the ultrasonic energy and the flow pattern of the liquid.
  • Page 22 935 Cobb Place Blvd. Kennesaw, GA 30144 800.776.4431 • 770.421.0058 www.omni-inc.com PN: 03-2021-100 Rev. A...
