Summary of Contents for Omni International OMNI THq
- Page 1 OMNI TH DIGITAL TISSUE HOMOGENIZER USER MANUAL REV. B 03-225...
-
Page 2: Warranty Information
WARRANTY INFORMATION This manual is a guide for the use of the Omni International TH Digital Tissue Homogenizer and accessories. Data herein has been verified and validated. It is believed adequate for the intended use of the instrument. If the instrument or procedures... - Page 3 . If you experi- ence problems with or have questions about your Omni TH , contact your authorized dealer or call Omni International at 800-776-4431 or 770-421-0058. DANGER - DO NOT allow the machine to be submerged in any liquid.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Warranty Information ..................2 Section 1 — Omni TH , Digital Tissue Homogenizer 1.1 Device Layout ..................5 1.2 Buttons / Display .................. 6 1.3 Parts and Accessories ................. 6 1.4 Powering the Device ................7 1.5 Stand Mounting the Omni TH ............ -
Page 5: Section 1 - Omni Th
SECTION 1 — Omni TH DIGITAL TISSUE HOMOGENIZER 1.1 DEVICE LAYOUT Power jack LED RPM display Run button Running LED Stop button Stop LED Speed up button Speed down Power button button Stand Arm cutout Omni Tip™ coupling... -
Page 6: Q, Digital Tissue Homogenizer
Prior to operation, please remove all parts from the shipping container and inspect for damaged or missing parts. If any parts are found to be dam- aged or missing, please contact Omni International at 1-800-776-4431. The Omni TH Digital Tissue Homogenizer Package consists of the following:... -
Page 7: Powering The Device
SECTION 1 — Omni TH DIGITAL TISSUE HOMOGENIZER 1.4 POWERING DEVICE Connect the included power supply to the Omni TH motor unit and plug the power supply unit into an appropriate outlet. STAND-MOUNTING THE OMNI TH To mount the Omni TH to a stand assembly, refer to the figure and follow these steps: 1. -
Page 8: Section 2 - Rotor-Stator Generator Probes
SECTION 2 — ROTOR-STATOR GENERATOR PROBES 2.1 INSTALLING ROTOR-STATOR GENERATOR PROBES Stainless steel and plastic Omni Tip™ rotor- stator generator probes are easily installed to the Omni TH motor by means of a quar- ter-turn bayonet mount. Simply push the generator probe into the motor housing as far as possible, turn clockwise, and release. -
Page 9: Homogenization
SECTION 2 — ROTOR-STATOR GENERATOR PROBES 2.2 HOMOGENIZATION Insert the generator probe into the Omni TH motor. The depth of the generator probe in the sample vessel can significantly affect flow pat- terns within the vessel. This also affects process- ing efficiency. -
Page 10: Section 3 - Motor Unit Maintenance
SECTION 3 — MOTOR MAINTENANCE 3.1 SPECIFICATIONS Motor Speed: 8,000 - 32,000 rpm Processing Capacity: 0.1-150 mL Height (motor only): 21.92 cm (8.63 in.) Weight (motor only): 340 g (11.99 oz.) Electrical Requirements: 115V, 60Hz or 220V, 50Hz Standards Approval/Compliance: CE Certified (220V) is equipped with a universal power supply which NOTE:... -
Page 11: Storage
SECTION 3 — MOTOR MAINTENANCE 3.5 STORAGE The unique design of the Omni TH , Tissue Homogenizer allows the hand-held unit to stand vertically on a bench-top or shelf so that it can be stored in less than six square inches of space. WARNING: Keep all housings in place and in working order. -
Page 12: Section 4 - Troubleshooting
SECTION 4 — TROUBLESHOOTING Do not attempt to service the Omni TH in a manner other than those discussed in this manual. For any issue that is unsuccessfully corrected using this guide, please contact your authorized dealer or call Omni International technical assistance at 1-800-776-4431 or 1-770-421-0058. -
Page 13: Section 5 - Service
SECTION 5 — SERVICE 5.1 ASSISTANCE Should this product ever require service, please contact Omni International at 1–800–776-4431. 5.2 DECONTAMINATION Should an instrument or component that has been used with radioac- tive or pathogenic material require factory or field service, comply with the following procedure to ensure the safety of service personnel: •... - Page 14 NOTES...
- Page 15 NOTES...
- Page 16 OMNI TH DIGITAL TISSUE HOMOGENIZER ™ Omni International, Inc. 935C Cobb Place Blvd. Kennesaw, GA 30144 800.776.4431 770.421.0058 www.omni-inc.com...
