IMPORTANT TO BE READ AND OBSERVED
Before using the appliance, read these safety
instructions. Keep them nearby for future reference.
These instructions and the appliance itself provide
important safety warnings, to be observed at all times.
The manufacturer declines any liability for failure to
observe these safety instructions, for inappropriate
use of the appliance or incorrect setting of controls.
Very young children (0-3 years) should be kept away
from the appliance. Young children (3-8 years) should
be kept away from the appliance unless continuously
supervised. Children from 8 years old and above and
persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge can
use this appliance only if they are supervised or have
been given instructions on safe use and understand
the hazards involved. Children must not play with the
appliance. Cleaning and user maintenance must not
be carried out by children without supervision.
PERMITTED USE
CAUTION: the appliance is not intended to be
operated by means of an external switching device,
such as a timer, or separate remote controlled system.
This appliance is intended to be used in household
and similar applications such as: staff kitchen areas
in shops, offices and other working environments;
farm houses; by clients in hotels, motels, bed
& breakfast and other residential environments.
The maximum number of place settings is shown
in the product sheet.
The door should not be left in the open position - risk
of tripping. The open appliance door can only support
the weight of the loaded rack when pulled out. Do not
rest objects on the door or sit or stand on it.
WARNING: Dishwasher detergents are strongly
alkaline. They can be extremely dangerous if
swallowed. Avoid contact with the skin and eyes and
keep children away from the dishwasher when the
door is open. Check that the detergent receptacle is
empty after completion of the wash cycle.
WARNING: Knives and other utensils with sharp
points must be loaded in the basket with their points
down or placed in a horizontal position - risk of cuts.
This appliance is not for professional use. Do not use the
appliance outdoors. Do not store explosive or flammable
substances (e.g. gasoline or aerosol cans) inside or near
the appliance - risk of fire. The appliance must be used
only to wash domestic dishes in accordance with the
instructions in this manual. The water in the appliance
is not potable. Use only detergent and rinse additives
designed for an automatic dishwasher. When adding salt
to the water softener, run one cycle immediately to avoid
corrosion damage to internal parts. Store the detergent,
rinse aid and salt out of reach of children. Shut off the
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
3O41 PL
o cerca il tuo prodotto tra le
SAFETY INSTRUCTIONS
migliori offerte di Lavastoviglie
water supply and unplug or disconnect the power before
servicing and maintenance. Disconnect the appliance in
the event of any malfunction.
INSTALLATION
The appliance must be handled and installed by
two or more persons - risk of injury. Use protective
gloves to unpack and install - risk of cuts. Connect
the dishwasher to the water mains using only new
hose sets. The old hose sets should not be reused.
All hoses must be securely clamped to prevent them
coming loose during operation. All local waterboard
regulations must be complied with. Water supply
pressure 0.05 - 1.0 MPa. The appliance must be
placed against the wall or built into furniture to limit
the access to its rearside. For dishwashers having
ventilation openings in the base, the openings must
not be obstructed by a carpet.
Installation, including water supply (if any) and
electrical connections, and repairs must be carried
out by a qualified technician. Do not repair or replace
any part of the appliance unless specifically stated
in the user manual. Keep children away from the
installation site. After unpacking the appliance, make
sure that it has not been damaged during transport.
In the event of problems, contact the dealer or
your nearest After-sales Service. Once installed,
packaging waste (plastic, styrofoam parts etc.) must
be stored out of reach of children - risk of suffocation.
The appliance must be disconnected from the power
supply before any installation operation - risk of
electrical shock. During installation, make sure the
appliance does not damage the power cable - risk of
fire or electrical shock. Only activate the appliance
when the installation has been completed.
If installing the dishwasher at the end of a row of units
making the side panel accessible, the hinge area
must be covered to avoid risk of injury. The inlet water
temperature depends on the dishwasher model. If the
installed inlet hose is marked „25°C Max", the maximum
allowed water temperature is 25°C. For all other models
the maximum allowed water temperature is 60°C. Do
not cut hoses and, in the case of appliances fitted with
a waterstop system, do not immerse the plastic casing
containing the inlet hose in water. If hoses are not long
enough, contact your local dealer. Make sure the inlet
and drain hoses are kink-free and are not crushed.
Before using the appliance for the first time, check the
water inlet and drain hose for leaks. Make sure that the
four feet are stable and resting on the floor, adjusting
them as required, and check that the dishwasher is
perfectly levelled using a spirit level.
ELECTRICAL WARNINGS
The rating plate is on the edge of the dishwasher
door (visible when the door is open).
1
