DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on:
www.whirlpool.eu/register
Before using the appliance carefully read Health and Safety guide.
PRODUCT DESCRIPTION
APPLIANCE
1
4
7
8
10
12
Service:
0000 000 00000
13
CONTROL PANEL
1
1. On-Off/Reset button with indicator light
2. Program selection button
3. Salt refill indicator light
4. Rinse Aid refill indicator light
5. Program number and remaining time indicator
6. Delay indicator light
7. Display
2
3 4
5
6 7 8
You can download the Safety Instructions and the Use
and Care Guide, by visiting our website
http://docs.whirlpool.eu and following the Instructions
on the back of this booklet.
2
1.Upper rack
2. Cutlery rack
3
3.Foldable flaps
4.Upper rack height adjuster
5.Upper spray arm
6.Lower rack
7.Space Zone
8.Lower spray arm
5
9.Filter Assembly
6
10.Salt reservoir
11.Detergent and Rinse Aid dispensers
9
12.Rating plate
13.Control panel
11
9
10
11
12
8. Multizone indicator light
9. Delay button
10. Multizone button
11. Turbo button with indicator light
12. Power Clean button with indicator light
13. Tablet (Tab) button with indicator light
13
EN
