- Page 1 Yealink UVC84-BYOD Meeting Kit English| 简体中文 Quick Start Guide(V1.1) www.yealink.com...
-
Page 2: Package Contents
Package Contents Package A for Large Room (UVC84-VCM34x2-MSpeaker Ⅱ ) Package B for Medium Room (UVC84-MSpeech-BYOD) 7.5m VCR20 Power Adapter UVC84 Ethernet Cable Remote Control 48V/0.7A USB Cable Cable Tie× 5 Velcro Mounting Bracket UVC84 (on the bracket) Battery×2 and Accessories Quick Start Guide UVC84 package VCM34... - Page 3 Velcro×2 Type-C to Type-A BYOD Adapter Quick Start Guide BYOD-BOX package We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may result in poor performance. Package A Connection 3.5mm Cat5e MSpeaker...
- Page 4 Package B Connection and Deployment Connction: UVC84 HDMI Cable BYOD Type-C MSpeech Power Adapter Deployment: Attach the BYOD box to the bottom or the top of the table. HDMI Cable USB 2.0 Type-C Type-C Power MSpeech...
- Page 5 包装清单 组合 A 适用于大型会议室 (UVC84-VCM34x2-MSpeaker Ⅱ ) 组合 B 适用于中型会议室 (UVC84-MSpeech-BYOD) 7.5m 电源适配器 VCR20 遥控器 UVC84 以太网线 (48V/0.7A) USB 线 7 号电池 ×2 支架配件 UVC84 魔术贴 束线带 ×5 快速入门指南 （已粘在挂架上） UVC84 套件 VCM34 VCM34 3m 网线 硅胶垫 快速入门指南 VCM34 套件 MSpeaker Ⅱ...
- Page 6 MSpeech MSpeech 硅胶垫 快速入门指南 MSpeech 套件 BYOD 盒子 1.2 米 USB Type-C 线 电源适配器 魔术贴 ×2 Type-C 转 Type-A BYOD 转换头 快速入门指南 BYOD 盒子套件 我们推荐使用由亿联提供或经亿联认可的配件， 使用未经认可的第三方配件可能会导致性能的 下降。 连接组合 A 3.5mm Cat5e MSpeaker VCM34 组 合 A 可 以 额 外 购 买 BYOD 盒 子，搭 配 BYOD 盒子使用。...
- Page 7 连接和部署组合 B 连接： UVC84 HDMI 线 BYOD Type-C MSpeech 电源适配器 部署： 将 BYOD 盒子贴在桌子顶部或底部。 HDMI 线 USB 2.0 Type-C Type-C 电源 MSpeech...
- Page 8 As one of the best providers in more than 140 countries and regions, Yealink ranks No.1 in the global market share of SIP phone shipments (Global IP Desktop Phone Growth Excellence Leadership Award Report, Frost & Sullivan, 2019).
