SERVICE MANUAL
EN
DEVILBISS PRO AIR Series :
PRO AIR 1, 2 & 3 Filter Regulator Units
IMPORTANT! DO NOT DESTROY
It is the Customer's responsibility to have all operators and service personnel read and understand
this manual.
Contact your local DeVilbiss representative for additional copies of this manual.
READ ALL INSTRUCTIONS BEFORE OPERATING THIS DEVILBISS PRODUCT.
1/8
SB-E-8-310 R1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DeVilbiss PRO AIR Series
Summary of Contents for DeVilbiss PRO AIR Series
- Page 1 IMPORTANT! DO NOT DESTROY It is the Customer's responsibility to have all operators and service personnel read and understand this manual. Contact your local DeVilbiss representative for additional copies of this manual. READ ALL INSTRUCTIONS BEFORE OPERATING THIS DEVILBISS PRODUCT. SB-E-8-310 R1.0...
-
Page 2: Functional Description
PRO AIR is a range of compact compressed air regulator and filters suitable for 1 or 2 operators. PRO AIR 2 and 3 are suitable for use with Respiratory Personal Equipment such as the Devilbiss PRO VISOR and Half Mask kits. - Page 3 Product Description/Object of Declaration: Pro Air 1, 2, 3 Suitable for use in hazardous area: Zone 1 Protection Level: II 2G IIB D c T5 Notified body details and role: This Declaration of conformity/ incorporation Finishing Brands UK Ltd, is issued under the sole responsibility of the Ringwood Road, manufacturer: Bournemouth, BH11 9LH.
- Page 4 In this part sheet, the words WARNING, CAUTION and NOTE are used to emphasise important safety information as follows: WARNING CAUTION NOTE Hazards or unsafe practices which could result in Hazards or unsafe practices which could result in Important installation, operation or maintenance severe personal injury, death or substantial minor personal injury, product or property information.
-
Page 5: Parts List
PARTS LIST REF. PART No. DESCRIPTION PROAIR-51 FILTER ELEMENT (5 m) PROAIR-52 COALESCAR FILTER ELEMENT (0.01 m) PROAIR-53 ACTIVATED CARBON FILTER ELEMENT PROAIR-62 KIT OF PROAIR-51 & 52 PROAIR-63 KIT OF PROAIR-51, 52 & 53 PROAIR-71 UPPER COVER ASSEMBLY PROAIR-72 METAL FILTER BOWL WITH DRAIN VALVE BALL VALVE 1/4"... -
Page 6: Installation
INSTALLATION Do not install the unit above electrical or any other equipment that could be damaged by discharged condensate oil. Ensure air flows through the unit in the direction of the arrows on the body. Install the unit as near as possible to the point of use. An isolation valve is fitted (8) to the inlet of the PRO AIR 2 &... -
Page 7: Maintenance
MAINTENANCE Always de-pressurise the whole unit prior to carrying out any maintenance work, ensuring no pressure is locked in the unit or items attached to it. The regulator knob should be wound fully counter clockwise to exhaust all pressure after isolating. Ensure earthing of the unit is not affected by maintenance activities, see installation on previous page. -
Page 8: Warranty Policy
