HAF-517 - 75 CFM CHARCOAL FILTER
1 (not shown)
1A
2
3
Figure 1 - HAF-517, 75 CFM Charcoal Filter
PARTS LIST
Ref No. Replacement
Part No.
1
HAF-404
1A
2
3
HAF-36
4
HAF-11
5
HAF-8
6
HAF-19
7
HAF-409
SPECIFICATIONS
Air Filter:
Air Inlet
Air Outlet
Air Flow Capacity
Maximum Inlet Pressure
Maximum Operating Pressure
Maximum Temperature
Aerosol Filter
Particulate Filter
4
Description
Filter Change Indicator
(not shown)
Body
O-Ring
Filter and O-Ring Kit
Manual Drain
Plastic Bowl
Metal Bowl Guard
Clamp Ring
1/2" NPT(F)
1/2" NPT(F)
75 CFM @ 100 PSI
150 PSIG (10.3 Bar)
150 PSIG (10.3 Bar)
150° F (65.6°C)
0.003 ppm/wt.
3.0 micron
IMPORTANT: Read and follow all INSTRUCTIONS and
SAFETY PRECAUTIONS before installing, operating
or maintaining this equipment. Keep this manual for
future reference.
Improper use can cause personal injury.
5
• This product is designed and intended for
use in industrial compressed air systems only.
Do not use for liquids or gasses other than air.
6
• Do not use where pressure or temperature
can exceed rated operating conditions (see
7
specifications).
• Regulated outlet pressure must never be
set higher than the maximum operating
pressure of the downstream air tool or
equipment. An outlet pressure gauge should
always be used.
Ind.
Parts
Req.
1
Risk of injury. Do not place unit in service
without metal bowl guard installed. Filter
1
units are sold only with metal bowl guards.
1
To minimize the danger of flying fragments
1
in the event of plastic bowl failure, guard
1
must not be removed. If the unit is in ser-
1
vice without the metal bowl guard installed,
1
manufacturer's warranties are void and the
1
manufacturer assumes no responsibility for
any resulting loss. If unit has been in service
and does not have a metal bowl guard, order
one and install before placing back in service.
Certain compressor oils, cleaning agents and
solvents may attack the plastic and rubber
components used in the construction of this
product. This product should not be used in
conjunciton with or in the vicinity of these
materials. Read and follow material labels
carefully. Please consult DeVilbiss if in doubt.
SERVICE BULLETIN
SB-6-155-B
Replaces SB-6-155-A
Risk of explosion or fire.
