Aaeon SRT-IMX8P User Manual

Gateway & expansion board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SRT-IMX8P
Gateway & Expansion Board
User's Manual 1
Ed
st

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRT-IMX8P and is the answer not in the manual?

Questions and answers

Related Manuals for Aaeon SRT-IMX8P

Summary of Contents for Aaeon SRT-IMX8P

  • Page 1 SRT-IMX8P Gateway & Expansion Board User’s Manual 1...
  • Page 2 AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
  • Page 3 Acknowledgment The following product names and trademarks are properties of their respective owners: Microsoft Windows is a registered trademark of Microsoft Corp. ⚫ Intel is a registered trademark of Intel Corporation ⚫ Arm, Cortex, and Cortex-A53 are registered trademarks of Arm Limited (or its ⚫...
  • Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity SRT-IMX8P ⚫ If any of these items are missing or damaged, please contact your distributor or sales representative immediately. Preface...
  • Page 5 (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the product page at AAEON.com for the latest version of this document. Preface...
  • Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
  • Page 7 If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device...
  • Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. Caution: There is a danger of explosion if the battery is incorrectly replaced.
  • Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 ○ ○ ○ ○ 及其电子组件 外部信号 ○ ○ ○ ○ 连接器及线材 O：表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下。...
  • Page 10 China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products AAEON Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Hexavalent Polybrominated Polybrominated Component Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &...

  • Page 11: Table Of Contents

    Table of Contents Chapter 1 - Product Specifications..................1 Specifications ......................2 Chapter 2 – Hardware Information ..................4 Dimensions ....................... 5 I/O Location ......................6 List of Connectors ....................7 2.3.1 DC Power (CN6) ................... 8 2.3.2 HDMI Port (CN11) ..................8 2.3.3 USB 3.0 Port (CN31) ..................
  • Page 12 3.2.2 To Delete a User Account................21 I/O Management ....................22 CAN-FD Pin Definition..................23 Pin Definition: RS-232/422/485 x 2 ..............25 Network Settings ....................27 3.6.1 Check the IP Setting .................. 27 3.6.2 Set the Static IP ..................28 3.6.3 Set the Dynamic IP ..................

  • Page 13: Chapter 1 - Product Specifications

    Chapter 1 Chapter 1 - Product Specifications...

  • Page 14: Specifications

    Specifications System Processor Arm® NXP i.MX8M Plus Quad-Core Cortex®-A53 1.6GHz Processor (NPU Optional) Memory Onboard DDR4L 2GB (Optional 4GB) Storage eMMC 16G (Optional 32GB) Real Time Clock RTC x 1, with 3V CR2032 Lithium battery Security TPM 2.0 Indicators Programmable LED control x 7 Cellular Mini PCIe Connector x 1 (USB signal) Wi-Fi &...
  • Page 15 Power Supply Power Requirement DC 9-36V Power Consumption 9.36W (Full Loading) MTBF (Hours) 479,374 Environmental Dimension 3.66” x 5.43” (93mm x 138mm) Weight 0.7 lb. (0.35 Kg) Mount Options — Operation Temperature -4°F ~ 158°F (-20°C ~ 70°C) Storage Temperature -40°F ~ 176°F (-40°C ~ 80°C) Operation Humidity 10% ~ 95% relative humidity, non-condensing...

  • Page 16: Chapter 2 - Hardware Information

    Chapter 2 – Hardware Information Chapter 2...

  • Page 17: Dimensions

    Dimensions Chapter 2 – Hardware Information...

  • Page 18: I/O Location

    I/O Location Bottom Chapter 2 – Hardware Information...

  • Page 19: List Of Connectors

    List of Connectors The SRT-IMX8P features several connectors which can be configured for your application. This section details those connections and their specifications. Label Function DC 9-36V Power CN11 HDMI Port CN31 USB 3.0 Port CN1/2 Giga LAN Port LED3/4...

  • Page 20: Dc Power (Cn6)

    2.3.1 DC Power (CN6) The gateway can accept DC 9-36V input though a 2-pin phoenix connector. Note: Input connector should be secured by 18-24mm AWG wire and torque value of 2kg lb.-in. 2.3.2 HDMI Port (CN11) The HDMI support port enables video output to an external display. 2.3.3 USB 3.0 Port (CN31) The USB 3.0 is a Type-A connector, and can also support USB mass storage.

  • Page 21: Giga Lan Port (Cn1/Cn2)

    2.3.4 Giga LAN Port (CN1/CN2) The standard RJ-45 LAN Jack provides connection to the Local Area Network (LAN). Function Status ON: LAN link is established. Yellow Active status OFF: LAN link is not established. Blink: Data received and transmitted. Green on: 100Mbps. Orange/Green Link Speed status Orange on: 1000Mbps.

  • Page 22: Indicators Light (Led3/Led4)

    2.3.5 Indicators Light (LED3/LED4) User can control the 7 LED via the GPIO. The control command for LED 1: Control Command Turn On m0cli -c 0 -i 1 -v 1 Turn Off m0cli -c 0 -i 1 -v 0 Note: i: LED number. Chapter 2 –...

  • Page 23: Can-Fd Port (Cn21)

    2.3.6 CAN-FD Port (CN21) Provides two phoenix CANbus ports for external device connection. Check Chapter 3 for more information. 2.3.7 Reset Button (SW2) Press the button to reboot the OS. 2.3.8 RS-232/422/485 Port (CN4/CN5) Provides two phoenix connectors for RS-232/422/485 interface. Check chapter 3 for more information.

  • Page 24: Micro Sim Slot (Cn14)

    2.3.9 Micro SIM Slot (CN14) User can insert the micro SIM card into the slot when using an LTE module via the mini card slot. 2.3.10 MicroSD Slot (CN16) User can increase the available storage by insert the microSD card. 2.3.11 Mini PCIe slot (CN12/CN13) The two slots support Wi-Fi or 4G LTE modules.

  • Page 25: Wireless Hardware Setup

    Wireless Hardware Setup SRT-IMX8P features mini PCIe slots and a Micro SIM card slot for connecting to wireless networks such as 4G LTE and WiFi. This section details how to install a SIM Card, 4G/LTE module, and WiFi module. 2.4.1...

  • Page 26: Sim Card Installation

    Item Module Installation Location Wi-Fi Install the RF cable to left conn. to support Wi-Fi WPET-236ACN(BT) signal. module (ANT0 for WLAN only, ANT1 for WLAN+BT) 4G/LTE Install the RF cable to left conn. to support 4G/LTE signal EG25-G module 2.4.2 SIM Card Installation To install a SIM Card (Micro SIM) simply insert the SIM Card into the slot as shown.

  • Page 27: Sd Card Installation

    2.4.3 SD Card Installation To install an SD Card simply insert it into the slot as shown. Ensure the card is correctly oriented. Chapter 2 – Hardware Information...

  • Page 28: Chapter 3 - Gateway Setup And Configuration

    Chapter 3 Chapter 3 – Gateway Setup and Configuration...

  • Page 29: Connecting To The System

    Connecting to the System When connecting a PC or laptop to the SRT-IMX8P , using PuTTY with Windows 10 is recommended. Users can download the software from the PuTTY website. Step 1: Download the PuTTY tools: https://www.putty.org/. Step 2: Switch jumper (SW3) to 0010. (Factory default settings).
  • Page 30 Step 4: Open Device Manager and locate Multifunction Composite Gadget. Double click on the device. A pop-up should appear, with a notice that the CDC Serial is unrecognized Step 5: Open the PuTTY application. In the configuration menu, type in the COM port and type 115200 in the Speed column.
  • Page 31 Step 6: Log into the system using the below credentials. Username: root Password: aaeon You will see a welcome message when you have successfully connected to the gateway. Chapter 3 – Gateway Setup and Configuration...

  • Page 32: User Account Management

    User Account Management This section will show you how to manage user accounts on this system. 3.2.1 To Add a User Account Command Line: $ sudo useradd USERACCOUNT E.g. (USERACCOUNT: jonny) $ sudo adduser jonny When successful, output will display as below. Chapter 3 –...

  • Page 33: To Delete A User Account

    3.2.2 To Delete a User Account Command Line: $ sudo userdel USERACCOUNT E.g. (USERACCOUNT: jonny) $ sudo userdel jonny When successful, output will display as below. Chapter 3 – Gateway Setup and Configuration...

  • Page 34: I/O Management

    I/O Management This section will show you how to operate the I/O function. Control GPIO Command: gpionum: 85 Set GPIO direction: E.g. echo 85 > /sys/class/gpio/export echo "out" > /sys/class/gpio/gpio85/direction Set GPIO ON: E.g. echo 1 > /sys/class/gpio/gpio85/value Set GPIO OFF: E.g.

  • Page 35: Can-Fd Pin Definition

    CAN-FD Pin Definition System Position Pin Definition Name Definition can0 CAN1 Definition can1 CAN2 CANBus Read/Write The two ports can be connected to each other, as below: CAN1 pin H CAN2 pin H CAN1 pin L CAN2 pin L Chapter 3 – Gateway Setup and Configuration...
  • Page 36 Command: Run CANBus script: ifconfig can0 down ip link set can0 type can loopback off ip link set can0 type can bitrate 1000000 triple-sampling on ifconfig can1 down ip link set can1 type can loopback off ip link set can1 type can bitrate 1000000 triple-sampling on ifconfig can0 up ifconfig can1 up candump can0&...

  • Page 37: Pin Definition: Rs-232/422/485 X 2

    Pin Definition: RS-232/422/485 x 2 System Position RS232 RS422 RS485 Name Definition Definition Definition DCD1 DCD1 RXD1 RXD1 RXD1 /dev/ttym COM P1 TXD1 TXD1 DTR1 (CN4) Definition Definition Definition DCD2 DCD2 RXD2 RXD2 RXD2 /dev/ttym TXD2 TXD2 COM P2 DTR2 (CN5) Check/Switch RS-232/422/485 Mode Command:...
  • Page 38 COM P2 (CN5): Mode 0 – GPIO87 Signal Inversion Mode 1 – GPIO12 Signal Inversion Switch Function Mode 0 Mode 1 GPIO87 GPIO12 Function Signal RS-232 (High/Low) Signal RS-485 (High/Low) Signal RS-485/RS- (High/Low) RS232 Mode GPIO control: echo 0 > /sys/class/gpio/gpio85/value echo 1 >...

  • Page 39: Network Settings

    Network Settings This section will show you how to check and setup the network settings. 3.6.1 Check the IP Setting Command: $ nmcli dev sh NETWORKPROFILE ->It should be: Profile Support Hardware LAN1 LAN0 Modem 4G LTE Module When successful, output will display as below. Chapter 3 –...

  • Page 40: Set The Static Ip

    3.6.2 Set the Static IP Enter edit mode. Command: $ sudo nmcli connection add con-name eth0 type ethernet ifname eth0 ip4 192.16.12.21/24 $ sudo nmcli connection up eth0 $ sudo nmcli connection add con-name eth1 type ethernet ifname eth1 ip4 192.16.12.26/24 $ sudo nmcli connection up eth1 $ sudo nmcli dev sh...

  • Page 41: Set The Dynamic Ip

    3.6.3 Set the Dynamic IP Enter edit mode: Command: $ sudo nmcli connection mod eth0 ipv4.method auto $ sudo nmcli con mod eth0 -ipv4.addresses "192.16.12.21/24" $ sudo nmcli connection up eth0 $ sudo nmcli connection mod eth1 ipv4.method auto $ sudo nmcli con mod eth1 -ipv4.addresses "192.16.12.26/24" $ sudo nmcli connection up eth1 $ sudo nmcli dev sh When successful, output will display as below.

  • Page 42: Cellular Network Settings (Optional)

    Cellular Network Settings (Optional) This section will show you how to check and setup the cellular network setting. 3.7.1 Check the Cellular Module Status Step 1: Leave Command: $ apt-get install minicom Then press ‘Y’. When successful, output will display as below. Step 2: Leave Command: $ minicom –s When successful, output will display as below.
  • Page 43 Step 3: Choose “Serial port setup”, then press “A” to settings. Step 4: Leave Command: $ /dev/ttyUSB3 Finish setting configuration, then press “Enter”, as below. Step 5: Choose “Exit” to leave the dialog. Chapter 3 – Gateway Setup and Configuration...

  • Page 44: Check Module Information In Minicom

    3.7.2 Check Module Information in Minicom Check if module is connected to the serial port: Command: $ AT Check the SIM card status: Command: $ AT+CPIN? Check module manufacturer information: Command: $ ATI Check setting APN: Command: $ AT+CGDCONT=1,"IPV4V6","internet" Check 4G signal quality: Command: $ AT+CGDCONT? $ AT+CSQ...
  • Page 45 When successful, output will display as below. Chapter 3 – Gateway Setup and Configuration...

  • Page 46: Leave Minicom

    3.7.2.1 Leave Minicom Step 1: Press “Ctrl +A”. Step 2: Press “X”. Step 3: Choose “Yes” then select “Enter” to leave Minicom. Chapter 3 – Gateway Setup and Configuration...

  • Page 47: Dial-Up Cellular Module

    3.7.3 Dial-up Cellular Module Check the cellular module status Command: $ sudo su # systemctl enable ModemManager # sudo systemctl start ModemManager # mmcli --list-modems # mmcli -m 0 Result: Cellular module will show “register” status when module is ready. Chapter 3 –...
  • Page 48 Enable the cellular module Command: # mmcli -m 0 -e Result: Dial up the cellular module Command: # nmcli –a # nmcli c add con-name test type gsm ifname ttyUSB2 apn internet Result: Check the cellular module connection: Command: #ifconfig Result: # ping 8.8.8.8 Chapter 3 –...

  • Page 49: Wi-Fi Network Settings (Optional)

    Wi-Fi Network Settings (Optional) This section will show you how to check and setup the wireless network like Wi-Fi. 3.8.1 Scan Wi-Fi Access Point Command: # depmod -a 5.10.9-1.0.0+g32513c25d8c7 # modprobe 88x2bu # nmcli radio wifi on # nmcli dev wifi list Result: 3.8.2 Connect Wi-Fi Access Point Command:...

  • Page 50: Check Wi-Fi Signal

    3.8.3 Check Wi-Fi signal Command: # ping 8.8.8.8 Result: 3.8.4 Disconnect Wi-Fi Access Point Command: # sudo nmcli con down id ‘SSID’ E.g. # sudo nmcli con down id 'ABC' SSID->Which you want to disconnect Result: Chapter 3 – Gateway Setup and Configuration...

  • Page 51: Check Wi-Fi Connection Status

    3.8.5 Check Wi-Fi Connection Status Command: # nmcli connect show –active Result: The disconnected Wi-Fi status is shown in the picture as below: # nmcli dev Result: Chapter 3 – Gateway Setup and Configuration...

  • Page 52: System Management

    System Management This section will show you how to check and setup system settings such as the OS version, RTC, etc. 3.9.1 Check OS version Command: $ cat /etc/os-release Result: Chapter 3 – Gateway Setup and Configuration...

  • Page 53: Check The Storage Status

    3.9.2 Check the Storage Status Command: $df –h Result: 3.9.3 Shutdown the System Command: $ sudo shutdown now Result: Chapter 3 – Gateway Setup and Configuration...

  • Page 54: Date And Time Settings

    3.9.4 Date and Time Settings 3.9.4.1 Check the Current Date and Time Command: $ hwclock Result: 3.9.4.2 Set a New Date and Time Command: $ date -s "YYYYMMDD hh:mm:ss"; hwclock –w E.g. $ date -s "20220803 15:30:00"; hwclock –w YYYY->Year MM->Month DD->Date hh->Hour...

  • Page 55: Install Docker

    3.10 Install Docker This section will show you how to install Docker and setup the system settings. Note: Ensure LAN cable is plugged in prior to setting up system settings. Step 1: Leave Command: # sudo apt-get update Result: Step 2: Leave Command: # sudo apt-get install apt-transport-https ca-certificates curl gnupg lsb- release Then press “Y”...
  • Page 56 Step 3: Leave Command: # curl -k -fsSL https://download.docker.com/linux/debian/gpg | sudo gpg - -dearmor -o /usr/share/keyrings/docker-archive-keyring.gpg Then press “Y” Result: Step 4: Leave Command: # echo "deb [arch=$(dpkg --print-architecture) signed- by=/usr/share/keyrings/docker-archive-keyring.gpg] https://download.docker.com/linux/debian $(lsb_release -cs) stable" | sudo tee /etc/apt/sources.list.d/docker.list > /dev/null Result: Step 5: Leave Command: # sudo apt-get update...
  • Page 57 Step 6: Leave Command: # sudo apt-get install docker-ce docker-ce-cli containerd.io Then press “Y” Step 7: Leave Command: Modify /etc/docker/daemon.json (ex: vim) "storage-driver": "overlay2" Step 8: Restart the Device and Leave Command: $ sudo docker run hello-world Result: Chapter 3 – Gateway Setup and Configuration...
