- Page 1 UP LoRA Edge IP68 IP68 Gateway System User’s Manual 3 Ed.aeu Last Updated: Feb,03,2020...
- Page 2 AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
- Page 3 Acknowledgment All other products’ name or trademarks are properties of their respective owners. Microsoft Windows is a registered trademark of Microsoft Corp. Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel Corporation Core, Atom are trademarks of Intel Corporation ...
- Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity UP LoRA Edge IP68 Wi-Fi Antenna &Bluetooth Antenna LTE antenna LoRa antenna If any of these items are missing or damaged, please contact your distributor or sales...
- Page 5 (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the AAEON.com for the latest version of this document.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
- Page 7 If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device...
- Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
- Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON System QO4-381 Rev.A0 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 × ○ ○ ○ ○ ○ 及其电子组件 外部信号 × ○ ○ ○ ○ ○ 连接器及线材 ○...
- Page 10 China RoHS Requirement (EN) Hazardous and Toxic Materials List AAEON System QO4-381 Rev.A0 Hazardous or Toxic Materials or Elements Component Name PCB and Components Wires & Connectors for Ext. Connections Chassis CPU & RAM HDD Drive LCD Module Optical Drive...
- Page 11 2. Individual components including the CPU, RAM/memory, HDD, optical drive, and PSU are optional. 3. LCD Module and Touch Control Module only applies to certain products which feature these components...
-
Page 12: Table Of Contents
Table of Contents Chapter 1 - Product Specifications ....................1 Specifications ....................... 2 Product Applications ....................3 Chapter 2 – Hardware Information ..................... 4 Dimensions ........................5 I/O Location ......................... 6 List of Connectors ...................... 8 2.3.1 Power Input Connector (Power) ..............9 2.3.2 COM (I/O-1) ..................... -
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications... -
Page 14: Specifications
Specifications System Intel® Atom™ E3940 Processor Intel® Atom™ E3940 Processor (2M Cache, CPU Frequency 1.60 GHz up to 1.80 GHz) CPU with 64 bit architecture; Quad Core • Connectivity WiFi 802.ac , Bluetooth 4.1, LoRa 868MHz, EMEA LTE Intel®... -
Page 15: Product Applications
Antenna Product Applications The AAEON AIOT IP6801 Gateway is a sophisticated and compact outdoor IoT device. To provide faster and more flexible communication for industrial outdoor applications, it supports multiple wireless communications such as Wi-Fi, Bluetooth, LoRa frequencies 868 MHz and 915 MHz, 3G and 4G LTE. The AIOT-IP6801 gateway is ideal for usage in data collection, smart aggregation and cloud service applications. -
Page 16: Chapter 2 - Hardware Information
Chapter 2 – Hardware Information Chapter 2 Chapter 1 – Product Specifications... -
Page 17: Dimensions
Dimensions Chapter 2 – Hardware Information... -
Page 18: I/O Location
I/O Location Chapter 2 – Hardware Information... - Page 19 Chapter 2 – Hardware Information...
-
Page 20: List Of Connectors
List of Connectors Please refer to the table below for all of the system’s connectors that you can configure for your application Reference Designation Functional Description POWER Power Input Connector I/O_1 USB 3.0 HDMI HDMI 1.2 Gigabit Ethernet I/O_2 Chapter 2 – Hardware Information... -
Page 21: Power Input Connector (Power)
2.3.1 Power Input Connector (Power) Signal Description 2.3.2 COM (I/O-1) Signal Description Chapter 2 – Hardware Information... -
Page 22: Usb 3.0 (Usb)
Signal Description 2.3.3 USB 3.0 (USB) Signal Description Signal Description USB3_RX+ USB2_D- USB2_D+ USB3_TX- USB3_TX+ USB3_RX- Chapter 2 – Hardware Information... -
Page 23: Hdmi 1.2 (Hdmi)
2.3.4 HDMI 1.2 (HDMI) Signal Description Signal Description DDI2_TX0_HDMI_DP+ DDI2_CLK_HDMI_DN- DDI2_TX0_HDMI_DN- HDMI_CEC_D DDI2_TX1_HDMI_DP+ DDI2_DDC_CLK DDI2_TX1_HDMI_DN- DDI2_DDC_DAT DDI2_TX2_HDMI_DP+ +5V_HDMI DDI2_TX2_HDMI_DN- DDI2_TYPE_C_HPD DDI2_CLK_HDMI_DP+ Chapter 2 – Hardware Information... -
Page 24: Gigabit Ethernet (Lan)
2.3.5 Gigabit Ethernet (LAN) Signal Description LAN1_MDI0+ LAN1_MDI0- LAN1_MDI1+ LAN1_MDI1- LAN1_MDI2+ LAN1_MDI2- LAN1_MDI3+ LAN1_MDI3- Chapter 2 – Hardware Information... -
Page 25: Com (I/O-2)
2.3.6 (I/O-2) Signal Description Chapter 2 – Hardware Information... -
Page 26: Chapter 3 - Software And System Startup
Chapter 3 Chapter 3 – Software and System Startup Chapter 2 – Hardware Information... -
Page 27: Drivers Download And Installation
Drivers Download and Installation Drivers for the AIOT-IP6801 can be downloaded from the product page on the AAEON website by following this link: https://www.aaeon.com/en/p/iot-gateway-systems-aiot-ip6801 Download the driver(s) you need and follow the steps below to install them. Step 1 – Install Chipset Drivers Open the Step 1 - Chipset folder Open the Setup.exe file in the folder... - Page 28 Step 4 – Install LAN Drivers Open the Step 4 - LAN folder and select your OS For the N3350 CPU, open the Realtek folder For the E3940 CPU, open the Intel folder Open the setup.exe file in the folder Follow the instructions Drivers will be installed automatically Step 5 –...
-
Page 29: Quick Startup Guide
Quick Startup Guide This section provides instructions to quickly setup and initialize the AIOT-IP6801. Follow the steps below to startup your gateway for the first time. Step 1: Connect the Hardware Connect the power adapter to the system (6A@5V 5.5/2.1mm DC) and plug the system in. - Page 30 Step 2: Prepare Drive Prepare the bootable drive with the OS (Windows 10 or Ubuntu). Step 3: Turn On Turn on the system power and install the OS and drivers. Chapter 3 – Drivers Installation...
