- Page 1 SRG-3352 IOT Gateway System User’s Manual 1 Last Updated: July 24, 2019...
- Page 2 AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
- Page 3 Acknowledgment The following product names and trademarks are properties of their respective owners: Microsoft Windows is a registered trademark of Microsoft Corp. Intel is a registered trademark of Intel Corporation ARM, Cortex, and Cortex-A8 are registered trademarks of Arm Limited (or its subsidiaries).
- Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity SRG-3352 If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
- Page 5 (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the product page at AAEON.com for the latest version of this document.
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
- Page 7 If any of the following situations arises, please the contact our service personnel: Damaged power cord or plug Liquid intrusion to the device iii. Exposure to moisture Device is not working as expected or in a manner as described in this manual The device is dropped or damaged Any obvious signs of damage displayed on the device...
- Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. Caution: There is a danger of explosion if the battery is incorrectly replaced.
- Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON System QO4-381 Rev.A0 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 × ○ ○ ○ ○ ○ 及其电子组件 外部信号 × ○ ○ ○ ○ ○ 连接器及线材 外壳...
- Page 10 China RoHS Requirement (EN) Hazardous and Toxic Materials List AAEON System QO4-381 Rev.A0 Hazardous or Toxic Materials or Elements Component Name PCB and Components Wires & Connectors for Ext. Connections Chassis CPU & RAM HDD Drive LCD Module Optical Drive...
-
Page 11: Table Of Contents
Table of Contents Chapter 1 - Product Specifications ..................1 Specifications ........................2 Chapter 2 – Hardware Information ..................4 Dimensions ........................5 I/O Location ........................6 List of Connectors ......................7 2.3.1 Reset Button (SW1) .................... 8 2.3.2 Power Input (CN1) ..................... 8 2.3.3 RJ45 LAN (CN6, CN7) .................. - Page 12 3.2.7 Test Watchdog ....................27 3.2.8 Assign Access Point Name (APN)............... 29 3.2.9 PPP Dialing Procedure ................... 29...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications... -
Page 14: Specifications
Specifications System ARM Cortex-A8 RISC Processor 800 MHz Onboard DDR3L-SDRAM 8GB 1600MHz System Memory 8GB eMMC onboard Storage 9~30 VDC Power Requirement DC-in Power Supply Type Power Consumption (Typical) Dimensions 143mm (W) x 100mm (D) x 44mm (H) Operating Temperature 0°C ~ 60°C 5~95% at 40°C, non-condensing Operating Humidity... - Page 15 Expansion Mini PCIe x 1 Internal Expansion USB port x 2 NB-IoT 10 pin 4pin wafer box SIM Card Socket x 1 External Expansion Micro SD Socket x 1 Chapter 1 – Product Specifications...
-
Page 16: Chapter 2 - Hardware Information
Chapter 2 – Hardware Information Chapter 2 Chapter 1 – Product Specifications... -
Page 17: Dimensions
Dimensions Chapter 2 – Hardware Information... -
Page 18: I/O Location
I/O Location Chapter 2 – Hardware Information... -
Page 19: List Of Connectors
List of Connectors The SRG-3352 features several connectors which can be configured for your application. This section details those connections and their specifications. Label Function Reset Button Power Input RJ45 LAN Connector RJ45 LAN Connector RS-485 Connector x 2 CN11... -
Page 20: Reset Button (Sw1)
2.3.1 Reset Button (SW1) Position Function SW1 0 (default) SW1 1 Reset 2.3.2 Power Input (CN1) Signal Description +12V DC Chapter 2 – Hardware Information... -
Page 21: Rj45 Lan (Cn6, Cn7)
2.3.3 RJ45 LAN (CN6, CN7) Signal Description Signal Description TD1 + TD3 - TD1 - TD4 + TD2 + TD4 - TD2 - LED yellow+ LED yellow- LED green+/ LED orange- TD3 + LED green-/ LED orange+ Chapter 2 – Hardware Information... -
Page 22: Rs-485 Connector X2 (Cn8)
2.3.4 RS-485 Connector x2 (CN8) Signal Description 2.3.5 Micro USB (CN18) Signal Description Signal Description Chapter 2 – Hardware Information... -
Page 23: Mini Card Slot (Cn21)
2.3.6 Mini Card Slot (CN21) Signal Description Signal Description Top Side Bottom Side 3.3V Reserved**** Reserved**** 1.5V CLKREQ# VCC** I/O** REFCLK- CLK** REFCLK+ RST** N/C or GND VPP** Mechanical key Reserved Reserved Reserved*** PERST# PERn0 +3.3Vaux PERp0 +1.5V Chapter 2 – Hardware Information... - Page 24 Signal Description Signal Description Top Side Bottom Side SMB_CLK PETn0 SMB_DATA PETp0 USB_D- Reserved* USB_D+ Reserved* Reserved* LED_WWAN# Reserved* LED_WLAN# Reserved* LED_WPAN# Reserved* +1.5V Reserved* Reserved* +3.3V Chapter 2 – Hardware Information...
-
Page 25: Usb 2.0 Type A (Cn22)
2.3.7 USB 2.0 Type A (CN22) Signal Description Chapter 2 – Hardware Information... -
Page 26: Micro Sim Card Socket (Cn24)
2.3.8 Micro SIM Card Socket (CN24) Signal Description Signal Description Reset Clock Reserved Reserved Chapter 2 – Hardware Information... -
Page 27: Wireless Hardware Setup (Sim Card And Mini Card)
Wireless Hardware Setup (SIM Card and Mini Card) The SRG-3352 features both a SIM Card and Mini Card slot for connecting to wireless networks such as 4G. This section details how to install a SIM Card and/or Mini Card. 2.4.1... - Page 28 Step 2: Next, remove the two screws securing the cover on the top: Instructions continue on next page. Chapter 2 – Hardware Information...
- Page 29 Step 3: Install Mini Card Insert the Mini Card (Mini PCIe) into the slot at an angle about 30 degrees. Gently press down until it is horizontal. Use a screw to secure the corner shown below. Step 4: Replace top cover and secure by fastening the top screws first, then the sides. Chapter 2 –...
-
Page 30: Sim Card Installation
2.4.2 SIM Card Installation To install a SIM Card (Micro SIM) simply insert the SIM Card into the slot on the side of the system as shown. Take care to make sure the card is oriented correctly. Chapter 2 – Hardware Information... -
Page 31: Chapter 3 - Connecting To Pc And System Setup
Chapter 3 Chapter 3 – Connecting to PC and System Setup Chapter 2 – Hardware Information... -
Page 32: Connecting To System
Connecting to System When connecting a PC or laptop to the SRG-3352 system, it is recommended to use PuTTY with Windows 10. Users can download the software from the PuTTY website. For Windows 7 or older, users must first set up their PC to recognize the system. The following instructions detail how to set up your PC to connect to the SRG-3352 system by installing the CDC Serial Driver. - Page 33 Step 3 After the driver has been successfully installed, the device USB Serial Port (COM3) should appear in Device Manager. You can now use PuTTY to access the SRG-3352 system. Chapter 3 – Drivers Installation...
-
Page 34: Login And System Setup
Login and System Setup This section details how to connect to the SRG-3352 system using PuTTY and performing initial system setup. Before you begin, make sure the system is plugged in and powered on, and connected to your PC via USB. - Page 35 Step 2: System Login Type the login name for “SRG3352 login” and press Enter. Type in the password and press Enter. If you are connecting to the system for the first time, the default initial login and password is root Successful login will display the following with the cursor on the command line.
-
Page 36: Check Mac Address
Step 3: System Logout To logout of the system, type “exit” in the command line and press Enter. You will be logged out of the system. 3.2.1 Check MAC Address In the command line root@SRT3352:~# type “ifconfig” and press enter. The MAC address of both LAN ports will be displayed. -
Page 37: Lan Settings (Lan1, Lan2)
3.2.2 LAN Settings (LAN1, LAN2) This section details how to access and change LAN Settings, including setting a static IP address or DHCP for LAN1 and LAN2. Step 1 Access the config file. This is done by typing the following in the command line: For LAN1: vim /var/lib/connman/ethernet0.config For LAN2: vim /var/lib/connman/ethernet1.config You should see the following display (this is a sample display, IP and MAC addresses... -
Page 38: Check Micro Sd Card
You will be able to check if the Micro SD Card has been mounted under /media 3.2.4 Test Status LED The SRG-3352 features four Status LEDs. These LEDs can be tested by entering the following commands: turn on: echo 1 > /sys/class/leds/srt3352:green1/brightness turn off: echo 0 >... -
Page 39: Set Rtc
3.2.5 Set RTC The SRG-3352 features a hardware clock which can be set. Use the following commands to set the hardware clock. The date and time must be entered in the format YYYYMMDD HH:MM:SS using the 24-hour clock. (The date below is an... - Page 40 echo ‘V’ > /dev/watchdog Chapter 3 – Drivers Installation...
- Page 41 3.2.8 Assign Access Point Name (APN) Use the following command to assign APN the name highlighted as follows $ vim /etc/ppp/peers/wcdma-chat-connect 3.2.9 PPP Dialing Procedure To command PPP dial up, use the following command: $ pppd call wcdma & To check ppp0, use the command $ ifconfig Chapter 3 –...
- Page 42 Alternatively, to check if PPPd is running, enter the command: $ ps axu|grep -i ppp Chapter 3 – Drivers Installation...
