LOGGING DATA

The Power Vision is a powerful logging tool to diagnose running
issues. Use the Power Vision to log all vehicle operating data
and review the data in the Power Core software. Troubleshoot an
issue with excessive knock or a throttle blade closure by keeping
the Power Vision mounted to view and record channels.
1
Press the Log button to begin logging. The Power Vision
screen will illuminate a bright red banner across the top when
logging.
2
Press the Log button again to stop logging.
3
Use the Power Core software to view log fi les.
Snapshot Log: Press and hold the Log button for two
seconds to record the previous two minutes of operating time.
DELETING DATA LOGS
This menu allows you to delete data logs.
1
Select Vehicle Tools>Delete Data Log.
2
Select a specifi c log to delete or select *Delete All Logs*.

VIEWING THE DEVICE INFORMATION

This menu allows you to view the device fi rmware version,
serial number, and stock code.
Select Device Tools>Device Information.

REFORMATTING THE DISK

This menu allows you to reformat the disk and erase all data.
Select Device Tools>Reformat Disk.
VEHICLE TOOLS
DIAGNOSTICS
DELETE DATA LOGS
RESTORE ECU
