- Page 1 INSTRUCTION MANUAL Rotary Hammer HR3200C HR3210C HR3210FCT DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model HR3200C HR3210C HR3210FCT Capacities Concrete Tungsten-carbide 32 mm tipped bit Core bit 90 mm Steel 13 mm Wood 32 mm No load speed (min 315 - 630 Blows per minute 1,650 - 3,300 Overall length 398 mm 424 mm Net weight 4.8 kg... - Page 3 12. Use personal protective equipment. Always wear eye 26. Follow instruction for lubricating and chang- protection. Protective equipment such as dust mask, non- ing accessories. skid safety shoes, hard hat, or hearing protection used for 27. Keep handles dry, clean and free from oil and appropriate conditions will reduce personal injuries.
-
Page 4: Functional Description
Lighting up the lamps CAUTION: • If the tool is operated continuously at low For Model HR3210FCT speeds for a long time, the motor will get over- loaded, resulting in tool malfunction. • The speed adjusting dial can be turned only as far as 5 and back to 1. - Page 5 Changing the quick change chuck Selecting the action mode for SDS-plus Rotation with hammering For Model HR3210FCT The quick change chuck for SDS-plus can be easily exchanged for the quick change drill chuck. Removing the quick change chuck for SDS-plus ►...
-
Page 6: Torque Limiter
For chipping, scaling or demolition operations, depress ASSEMBLY the lock button and rotate the change lever so that the pointer points to the symbol. Use a bull point, cold chisel, scaling chisel, etc. CAUTION: • Always be sure that the tool is switched off and CAUTION: unplugged before carrying out any work on the •... -
Page 7: Depth Gauge
The bit can be secured at 24 different angles. To change the bit angle, depress the lock button and rotate the change lever so that the pointer points to the symbol. Turn the bit to the desired angle. Depress the lock button and rotate the change lever so that the pointer points to the symbol. -
Page 8: Operation
Chipping/Scaling/Demolition OPERATION CAUTION: • Always use the side grip (auxiliary handle) and firmly hold the tool by both side grip and switch handle during operations. Hammer drilling operation Set the change lever to the symbol. Hold the tool firmly with both hands. Turn the tool on and apply slight pressure on the tool so that the tool will not bounce around, uncontrolled. -
Page 9: Maintenance
These accessories or attachments are recommended wise to tighten the chuck. To remove the bit, hold the for use with your Makita tool specified in this manual. ring and turn the sleeve counterclockwise. The use of any other accessories or attachments Set the change lever to the symbol. - Page 12 Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 884769C2 www.makita.com 20161003...
