IMPORTANT:
KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
INSTALLATION AND OPERATING INSTRUCTIONS
If this stove is not properly installed, a house fire may result. For your safety,
follow the installation instructions. Contact local building or fire officials
about restrictions and installation inspection requirements in your area.
240918-20
TN 10
- AUSTRALIA
SAFETY NOTICE
TN10 AUSTRALIA
SERIAL #
100001122
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for True North TN 10
Summary of Contents for True North TN 10
- Page 1 IMPORTANT: KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. TN 10 INSTALLATION AND OPERATING INSTRUCTIONS - AUSTRALIA SERIAL # SAFETY NOTICE If this stove is not properly installed, a house fire may result. For your safety, follow the installation instructions. Contact local building or fire officials about restrictions and installation inspection requirements in your area.
-
Page 2: Table Of Contents
Installation ..........................15 If this stove is not Troubleshooting ..................17 properly installed, a Replacement Parts - TN 10 ..............18 house re may result. Compliance Plate ...................19 Fo r yo u r s a f e t y, follow the installation instructions. -
Page 3: Safety And Maintenance
Periodically inspect seals and replace if necessary. Follow instructions included in the door gasket kit (TN19.DGKIT ) obtainable from your nearest True North dealer. 5. DOOR GLASS - Do not slam loading door or otherwise impact glass. When closing door, make sure that no logs protrude to impact the glass. -
Page 4: Maintenance Checks
** Replace the Baffle tubes if they show signs of cracking or breakage. Please contact your Dealer if you experience any of the damage listed above. Continuing to operate your stove with broken parts may accelerate damage to other parts and will void your warranty TN 10 AS 100001122_240918-20... -
Page 5: Creosote
fireplace and void your warranty). 4. Do not leave the air inlet wide-open for extended periods of time. 5. Keep a fire extinguisher handy. 6. Prepare a home evacuation plan with a place outside where everyone is to meet. TN 10 AS 1000011229 _240918-20... -
Page 6: If You Suspect A Chimney Fire
[610mm] Figure 1. TN10 AS Dimensions. Assembly Crate Removal Carefully remove wood top and supports. 2. Remove plastic cover. • Remove the retaining clip on the front of the baffle before lighting for the first time TN 10 AS 100001122_240918-20... -
Page 7: Clearances - Residential
300 mm on the firing side and be placed centrally to both sides of the door opening. See Figure #3. 715 mm Figure 3. TN10 AS Floor protector. Minimum Width - 720 mm Minimum Overall Depth - 1060mm TN 10 AS 1000011229 _240918-20... -
Page 8: Note: Installation
CAUTION: THIS APPLIANCE SHOULD NOT BE OPERATED WITH A CRACKED GLASS. CAUTION: THIS APPLIANCE SHOULD BE MAINTAINED AND OPERATED AT ALL TIMES IN ACCORDANCE WITH THESE INSTRUCTIONS. CAUTION: THE USE OF SOME TYPES OF PRESEVATIVE-TREATED WOOD AS A FUEL CAN BE HAZARDOUS. TN 10 AS 100001122_240918-20... -
Page 9: Chimney And Connector
4. To start installing smoke pipe (chimney connector), slip crimped edge of the pipe inside the stove collar. Use holes provided in collar to secure pipe with three screws. 5. Install the remaining lengths of pipe, one on top of the other, to the finished height of the chimney connector and secure to each other. TN 10 AS 1000011229 _240918-20... -
Page 10: Firebrick Installation
Next install 3 firebricks on the bottom of the unit. Place them to the rear of the firebox. • Finally place 3 firebricks at the back of the heater, by inserting the bricks under the rear retainer Figure 5. TN10 BRIC Exploded. TN 10 AS 100001122_240918-20... -
Page 11: Combustion Air
During extremely cold weather, and especially when burning at very slow rates, the upper parts of the exposed chimney may ice up, partially blocking the flue gases. If blockage occurs, flue gases may enter living space. TN 10 AS 1000011229 _240918-20... -
Page 12: Operation
WARNING: OPEN AIR CONTROL (AND DAMPER WHEN FITTED) BEFORE OPENING FIRING DOOR. Your TRUE NORTH heater is designed for maximum overall efficiency at a moderate firing rate. Overfiring is hazardous and a waste of fuel. Too slow a burn contributes to creosote buildup and lowers combustion efficiency. -
Page 13: Ously Installed, You May Notice That How To Test Your Wood
WARNING: Do not use grates or andirons to elevate the fuel. Burn directly on the fire bricks. Replace broken or missing bricks. Failure to do so may create a hazardous condition. TN 10 AS 1000011229 _240918-20... -
Page 14: Leaving The Re Door Open. Do Not Proper Draft
final disposal. If the ashes are disposed of by burial in soil or otherwise locally dispersed, they should be retained in a closed container until all cinders have thoroughly cooled. Other waste should not be placed in this container. TN 10 AS 100001122_240918-20... -
Page 15: Baffle Tube Removal
6. Slide the baffle board halves in with the notches overlapping (one notch facing up and one notch facing down). Then separate to ensure there are no gaps on either side, between the baffle board and the Secondary Air Chambers. Push baffle board tight against the rear of the firebox. TN 10 AS 1000011229 _240918-20... - Page 16 TN 10 AS 100001122_240918-20...
-
Page 17: If This Stove Is Not Troubleshooting
Wood Won't Burn 1. Combustion air supply blocked • Check outside air supply for obstruction 2. Draft too low • Chimney plugged or restricted, -inspect and clean • Chimney oversized or otherwise unsuitable, -consult Dealer TN 10 AS 1000011229 _240918-20... -
Page 18: Properly Installed, A Replacement Parts - Tn 10
Replacement Parts - TN 10 WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION ITEM DESCRIPTION PART NO. Baf e Board (2pcs.), TN10 .............80002159 Baf e Tube Set (4pcs.), TN10 ............80002160 Secondary Air Chamber Left, TN10 (c/w gasket/screws) ....80002162 Secondary Air Chamber Right, TN10 (c/w gasket/screws) ....80002163 Door Assembly - No Glass, TN19/20/10, Met Black ..... -
Page 19: Compliance Plate
PARTICULATE EMISSIONS FACTOR - 1.2g/kg CATALYTIC COMBUSTOR - NO Distributed by: PIVOT STOVES AND HEATING CO 234-238 MOORABOOL STREET, GEELONG, VIC 3220 pivotstove.com.au 11/09/18 100001123 Compliance plate is located at the rear of the Stove TN 10 AS 1000011229 _240918-20... - Page 20 © 2018 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. PACIFIC ENERGY FIREPLACE PRODUCTS LTD. Web site: www.paci cenergy.net 2975 Allenby Rd., Duncan, BC V9L 6V8 PRINTED IN CANADA...
