True North A Series Installation And Operating Instructions Manual

Direct vent free standing gas stove

Advertisement

Quick Links

INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could
result in serious injury, death, or property damage.
-
Do not store or use gasoline or other flamma-
ble
of this or any other
-
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier call the fire
department.
-
Installation and service must be performed by
a
or the gas supplier.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
WARNING:
If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
Visit www. truenorthstoves.com for the most recent version of this manual
180624-40
vapors and liquids in the vicinity
appliance.
qualified installer, service agency
MODEL: TN24
SERIES: A
DIRECT VENT FREE STANDING
GAS STOVE INSTALLATION
AND OPERATING INSTRUCTIONS
TN24.BODYA
SERIAL #
100000458

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A Series and is the answer not in the manual?

Questions and answers

Summary of Contents for True North A Series

  • Page 1 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. Do not store or use gasoline or other flamma- vapors and liquids in the vicinity of this or any other appliance.
  • Page 2: Table Of Contents

    Table of Contents Table of Contents Installation ..............20 Table of Contents ............2 Venting Components ..........21 Important Note for the Commonwealth of Massachu- TN24 Gas Stove rear components ......22 setts: .................3 Gas and Electrical Connection ....... 23 Caution .................4 Screen mesh removal ..........
  • Page 3: Important Note For The Commonwealth Of Massachusetts

    Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied.
  • Page 4: Caution

    Caution FOR YOUR SAFETY - Do not install or operate your True North gas stove without first reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Pacific Energy Fireplaces Warranty and may prove hazardous.
  • Page 5: Safety

    Owner Information Safety Due to high temperatures, this gas stove should be located out of traffic and away from furniture and draperies. Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition. Young children should be carefully supervised when they are in the same room as the gas stove.
  • Page 6: Manufactured (Mobile) Homes

    Owner Information Manufactured (Mobile) Homes In some jurisdictions, the TN24 gas stove may be installed in Manufactured Homes after the “first sale”. Consult local codes for approval. The gas stove must be fastened in place. Install in accordance with the current standard Mobile Homes, CAN/CSA Z240 MH (in CANADA), and the Manufacturer’s Home Construction and Safety Standard, Title 24 CFR, Part 3280 or the current Standard for Fire Safety Criteria for Manufactured Home Installations, Sites and Communities ANSI/NFPA 501A (in the USA).
  • Page 7: Remote Control Operation

    Owner Information Remote Control Operation System Description The Proflame Remote Control System consists of 4 elements: Proflame Remote Transmitter. A receiver / battery holder Proflame Integrated Fireplace Control (IFC) module. A wiring harness to connect the IFC to the gas valve and stepper motor. Transmitter (Remote Control with LCD Display) The Proflame Remote Transmitter uses a streamline design with a simple button layout and informative LCD display (Figure 1).
  • Page 8 Owner Information Temperature indication Display With the remote transmitter in the “OFF” position, press the thermostat key and the mode key at the same time. Look at the LCD screen on the remote transmitter to verify that a C or F is visible to the right of the room temperature display (Figure 3) &...
  • Page 9 Owner Information Remote Control Operation The Proflame has six (6) flame levels. With the system turned on, and the flame level at maximum in the gas stove, press the down arrow key once to reduce the flame height by one step until the flame is turned off.
  • Page 10 Owner Information Comfort Fan Speed Control If the gas stove is equipped with a hot air circulating fan, the speed of the fan can be controlled by the Proflame System. The fan speed can be adjusted through six (6) speeds. To activate this function use the Mode Key (Figure 1) to index to the fan control icon (Figure 13).
  • Page 11: Warnings And Cautions

    Owner Information Low Battery Power Detection Remote Transmitter The life span of the remote control batteries depends on various factors: quality of the batteries used, the number of ignitions of the gas stove, the number of changes to the room thermostat set point, etc. When the remote batteries are low, an icon will appear on the LCD display of the remote (Figure 19) before all battery power is lost.
  • Page 12: Maintenance

    A replacement glass door can be obtained from your nearest True North dealer. Do not substitute with any other type. To replace broken glass door, refer to Glass Door removal on page 24 and Glass Door installation on page 28.
  • Page 13: Lighting Instructions

    Owner Information Lighting Instructions button button button Figure 20: TN24 lighting instructions. 100000458 180624-40 TN24.BODYA...
  • Page 14: Tn24 Gas Stove Dimensions

    Installer Information TN24 Gas Stove Dimensions Dimensions Height 29 11/16 inches Width 25 inches Depth 19 3/16 inches Height to center of Flue Outlet 24 inches 25” 19 3/16” 29 11/16” 24” 24” 17 3/4” Figure 21: TN24 dimensions. TN24.BODYA 180624-40 100000458...
  • Page 15: Clearances To Combustibles

    Installer Information Clearances to Combustibles Minimum Clearance to Combustible Materials INTERIOR SIDE WALL 4” INTERIOR BACK WALL 4 “ INTERIOR CEILING 18” VENTING CLEARANCE 1” 18” MIN. 4” Note on corner placement Refer to minimum clearances as shown in (Figure 22) & (Figure 23). 4”...
  • Page 16: Vent Cap Minimum Clearances

    Installer Information Vent Cap Minimum Clearances Minimum clearances to the vent terminal must be maintained as shown in (Figure 24) and Roof pitch table. Measure VENT TERMINAL MINIMUM CLEARANCES clearances to the nearest edge of termination hood. TO ADJACENT STRUCTURES NOTE: Vent terminal must not be recessed 36"...
  • Page 17: Tn24 Co-Axial Venting Chart

    Otherwise, the regular terminal can be used. 2’ 1’ No venting options 1’ 2’ 3’ 4’ 5’ 6’ 7’ 8’ 9’ 10’ 11’ 12’ 13’ 14’ 15’ 16’ Figure 26: True North venting chart examples. 100000458 180624-40 TN24.BODYA...
  • Page 18: Tn24 Co-Linear Venting

    Installer Information TN24 Co-Linear Venting Simpson Duravent High-Wind (cap style) Co-Linear Kit w/Flex (46DVA-CL33) or Simpson Duravent Prairie (cap style) Co-Linear Kit w/Flex (46DVA-CL33P) are High wind cap recommended for use with this appliance. Visit http://www.duravent.com for kit details. Co-Linear Venting Notes: 1.
  • Page 19: Optional Direct Vent Termination "Snorkel

    Installer Information Optional Direct Vent Termination “Snorkel” 13” 7” 1” 4 1/4” 33 1/4” 4” 6 5/8” Front view Side view Note: For proper operation, the Snorkel must be oriented so that the vent inlet and outlet are located at the 24 1/2”...
  • Page 20: Installation

    Installer Information Installation Attachment points Attachment points and drain ports Figure 29: Fastening the snorkel. Figure 30: Caulking the snorkel. Installation: The Snorkel can be attached to an exterior wall using 4 supplied screws. Be sure to position the Snorkel correctly so that the drain ports are located at the bottom of the unit. Exterior facing or siding can butt right up to the sides of the unit and can extend up to 1”...
  • Page 21: Venting Components

    Installer Information Venting Components NOTE: Mixing venting components from different manufacturers is inadvisable. Description Metal-Fab® Security Selkirk DuraVent EXCELDirect® Sure-Seal Secure Vent™ Direct-Temp™ DirectVent Pro® Galvanize Black Galvanized Black Galvanized Black Galvanized Black Galvanized Black 6” Pipe Length 4DL6 4DL6B 4D6B SV4L6 SV4LB6...
  • Page 22: Tn24 Gas Stove Rear Components

    Installer Information This gas stove is certified for use with 4” x 6-5/8”coaxial venting components. It is permitted to only use certified venting for this gas stove. See charts on page 21 for a list of approved venting components. Figure 33: Co-axial venting components. TN24 Gas Stove rear components Right blower fan Left blower fan...
  • Page 23: Gas And Electrical Connection

    Installer Information Gas and Electrical Connection Note: Do not plug the power Note: Do not turn on the gas cord in until installation has supply until installation has been completed. been completed. Gas connection To make the required electrical and gas connections, start by positioning the gas stove.
  • Page 24: Screen Mesh Removal

    Installer Information Packaging The TN24 gas stove comes with the ceramic panels and gas burner already installed. The log set and glowing embers are packaged in protective styrofoam and secured in place by the glass door and screen. The glass door and screen must be removed before the log set and embers can be accessed.
  • Page 25 Installer Information Remove the mesh screen as described on page 24. Remove the wing bolts (Figure 40) holding the glass door retainer frame to the gas stove frame and tilt the glass door (Figure 41) so that it can be removed Remove the glass door together with the retainer frame that it is affixed to.
  • Page 26: Log Set Installation

    Installer Information Log Set Installation Installation of log set Fill burner basket (Figure 45) with embers so that the basket is filled and overflowing the burner front row (Figure 46). Reserve a small amount of embers for final placement. Place first log onto the ledge in the firebox taking care that the log is completely set against the rear wall of the firebox (Figure 47).
  • Page 27 Installer Information Inset of tab. Figure 49: 3rd log placement. 4. Position 3rd log as shown in (Figure 49) making sure that the log does not cover the holes of the back row of the burner. 3rd log has a hole in its underside which will fit onto a protruding tab on the burner (Figure 45) &...
  • Page 28: Glass Door Installation

    Installer Information (Figure 52) shows the burners back row as not being covered by the logs. At this time, the small amount of embers reserved at the beginning of log placement can be used to fill any left over spaces. NOTE: do not place embers between the back row of the burner and the back-side of the 3rd and 4th logs as this will interfere...
  • Page 29: Screen Mesh Installation

    Installer Information Screen Mesh Installation The screen mesh is positioned in front of the glass door. Its purpose is to provide protection from the heat radiating from the glass door. The screen has a front side and a rear side and must be oriented correctly for a proper fit.
  • Page 30 Installer Information The bottom edge of the screen mesh must fit firmly into the channel provided for it Door Firebox in the fire box frame (Figure 60) shows side side the location of the screen mesh channel. The screen mesh top holder (Figure 61) positions the screen mesh so that there is the correct distance between the screen mesh and the glass door.
  • Page 31: Accent Lighting Glass Plates

    Installer Information Accent Lighting Glass Plates The TN24 Gas Stove comes with an assortment of glass plates of various colours. Accent lighting is controlled via the remote control transmitter included with the TN24 Gas Stove (Figure 1 on page 7). The glass plate tray is located underneath the light tray which is underneath the stove (Figure 63).
  • Page 32: Ifc Module

    Installer Information IFC Module The Proflame 2 Integrated Fireplace Control (IFC) module is a device that allows automatic ignition and pilot flame supervision, and commands the functions of the gas stove. It’s configured to control the ON/OFF main burner operation, giving the choice of both IPI (intermittent pilot ignition), and CPI (continuous pilot ignition) modes.
  • Page 33: Damper Adjustment

    Installer Information Damper Adjustment Damper Adjustment Damper adjustment is located under the top cladding cover plate. (Factory setting is closed; slowly open and adjust as necessary to eliminate a sagging, sooting flame). Figure 69: TN24 Damper. Venturi Adjustment Venturi adjustment is accessible through an opening in the rear cover (Figure 34 on page 22).
  • Page 34: Gas Supply

    Installer Information Gas Supply Servicing of the gas stove can be performed from the rear of the unit by removing the access panel from the unit. Caution: The gas line should be installed by a qualified service person in accordance with all building codes.
  • Page 35: Gas Pressure Testing Procedure

    Installer Information Gas Pressure Testing Procedure Note: To test the gas pressure, turn off the gas supply to the gas stove before loosening test point screws. Verify gas pressures with the gas stove lit and at the highest setting. Remove rear panel and locate the valve as seen in (Figure 72). Locate the inlet and outlet test points on the valve which can be seen in (Figure 73).
  • Page 36: Propane Conversion

    Installer Information Propane Conversion Before starting the conversion make sure to shut off the gas supply to the unit and allow gas stove to cool to room temperature. To convert the gas stove from natural gas to propane the (TN24.LPKITA) kit is required. This kit comes with new pilot and burner orifices as well as a new pressure modulator for the valve.
  • Page 37: Parts Diagram

    Parts Diagram DESCRIPTION SALES CODE True North 24 unit complete ..............32010001 Optional True North LP Conversion Kit (TN24.LPKITA) ........32180001 Replacement True North Door with glass ..............80000609 True North Screen .................. 80000612 True North Control Tray Complete............80000608 True North Black Porcelain Panel Set ............
  • Page 38: Wiring Diagram

    Installer Information Wiring Diagram LAMP COMFORT Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. TN24.BODYA 180624-40 100000458...
  • Page 39: Rating Label

    Installer Information Rating Label The Rating label - as shown - is located on the rear of the gas stove. VENTED GAS FIREPLACE - NOT FOR USE WITH SOLID FUEL FOYER AU GAZ À ÉVACUATION - NE PAS UTILISER AVEC DU COMBUSTIBLE SOLIDE ANSI Z21.88-2014 / CSA 2.33-2014 Vented Gas Fireplaces This appliance is equipped for use with natural gas.
  • Page 40 © 2024 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer Web site: www. truenorthstoves.com 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
