- Page 1 C o m p a c t a n d c o m p l e t e » Q u a l i t y & r e l i a b i l i t y y o u c a n d e p e n d o n »...
- Page 2 Key features include: Omron fully understands your needs, which Ratings up to 7.5 kW • RS485 Modbus built-in • is why we put quality and reliability first. Side-by-side mounting • And we keep listening, so our products come EMC filter built-in •...
- Page 3 Energy-saving effect Inverter system Spikes in the terminal voltage are suppressed even when 10 20 30 40 50 60 70 80 90 100 the wiring distance from the inverter to the motor is long Airflow (%) Silent operation Maximise motor life...
-
Page 4: System Configuration
CX-Drive MCCB CX-One Remote Operator AC Reactor LCD 2 lines Extansion Cable Remote Operator Filter DC Reactor Choke Output Reactor Motor Ground * Only needed for 3 phase 200V or to comply C1 on 3 phase 400V models Frequency inverters... -
Page 5: Specifications
Specifications Type designation J X A B 0 0 2 - E F JX series F: Built-in EMC Filter A: Standard specs E: Europe standard Max. applicable motor output Voltage: 002: 0,2 kW B: Single-phase 200 VAC Three-phase 200 VAC... - Page 6 Constant/ reduced torque V/f Characteristics FW (forward), RV (reverse), CF1 to CF4 (multi-step speed), JG (jogging), DB (external DC injection braking), SET (2nd func- tion), 2CH (2-step acceleration/deceleration), FRS (free run), EXT (external trip), USP (USP function), SFT (soft lock), AT...
- Page 7 Three-phase A4022 400 V A4040 A4055 167.5 77.5 A4075 Rasmi footprint Filters Filter only needed by the 1-phase 200V or 3-phase 400V to comply with C1 EMC class. Dimensions Weight Rasmi model AX-FIJ1006-RE 1x200 V AX-FIJ1010-RE AX-FIJ1026-RE AX-FIJ2006-RE 3x200 V...
- Page 8 Voltage Reference AX-RC21400016-DE 1.22 AX-RC10700032-DE AX-RC06750061-DE 84 113 101 66 1.60 AX-RC03510093-DE 200V AX-RC02510138-DE 1.95 AX-RC01600223-DE 108 135 124 120 82 6.5 3.20 AX-RC01110309-DE 5.20 120 152 135 94 6.00 AX-RC00840437-DE AX-RC43000020-DE 1.22 AX-RC27000030-DE 84 113 101 66 1.60 AX-RC14000047-DE AX-RC10100069-DE 1.95...
-
Page 9: Installation
Function (signal level) Main circuit power supply input Used to connect line power to the drive. Drives with single-phase 200 V input power use only terminals R/L1 and N (T/L3), terminal R/L1, S/L2, T/N/L3 S/L2 is not available for these units... -
Page 10: Control Circuit
External power supply terminal for input signal (input) ...At sink logic Input power supply 24 VDC ±10% Internal power supply output terminal for input signal (output) ...At source logic Internal 24 VDC 24 VDC internal power supply 24 VDC ±10% 30 mA... - Page 11 Input AC Reactor AC reactor Power supply MCCB R/L1 S/L2 T/L3 3 phase 200 V class 400 V class Max. applicable Current value Inductance Max. applicable Current value Inductance Reference Reference motor output kW motor output kW 0.1 to 1.5 AX-RAI02800080-DE 0.4 to 1.5...
-
Page 12: Ordering Information
Remote Operator Filter Choke DC Reactor Motor Output reactor Ground * Only needed for 3 phase 200V or to comply C1 on 3 phase 400V models Specifications Model Voltage class Max. applicable motor output kW Rated output current (A) Standard... - Page 13 A4075 AX-RAO03600160-DE ALL DIMENSIONS SHOWN ARE IN MILLIMETERS. To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527. In the interest of product improvement, specifications are subject to change without notice. Cat. No. I110E-EN-01B...
