INSTRUCTION MANUAL
Cordless Angle Grinder
DGA405
DGA455
DGA505
015305
IMPORTANT: Read Before Using.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DGA505 and is the answer not in the manual?

Questions and answers

Related Manuals for Makita DGA505

Summary of Contents for Makita DGA505

  • Page 1 INSTRUCTION MANUAL Cordless Angle Grinder DGA405 DGA455 DGA505 015305 IMPORTANT: Read Before Using.
  • Page 2 Be sure that you understand their meaning before use. Uncertainty (K) : 3 dB (A) Read instruction manual. The noise level under working may exceed 80 dB (A). Model DGA505 Wear safety glasses. Sound pressure level (L ) : 79 dB (A)
  • Page 3 ) : 5.0 m/s h,AG The technical file in accordance with 2006/42/EC is Uncertainty (K) : 1.5 m/s available from: Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium Work mode: disc sanding Vibration emission (a ) : 2.5 m/s or less h,DS 28.4.2014...
  • Page 4 Do not abuse the cord. Never use the cord for 19. Disconnect the plug from the power source carrying, pulling or unplugging the power tool. and/or the battery pack from the power tool Keep cord away from heat, oil, sharp edges or before making any adjustments, changing moving parts.
  • Page 5 GEB059-4 fragments. The eye protection must be capable of stopping flying debris generated by various operations . CORDLESS GRINDER SAFETY The dust mask or respirator must be capable of WARNINGS filtrating particles generated by your operation. Prolonged exposure to high intensity noise may cause Safety Warnings Common for Grinding, Sanding, hearing loss.
  • Page 6 kickback or torque reaction during start-up. or binding of the wheel in the cut and the The operator can control torque reactions or possibility of kickback or wheel breakage. kickback forces, if proper precautions are taken. b) Do not position your body in line with and b) Never place your hand near the rotating behind the rotating wheel.
  • Page 7 ENC007-9 18. Be careful not to damage the spindle, the flange (especially the installing surface) or the IMPORTANT SAFETY lock nut. Damage to these parts could result INSTRUCTIONS in wheel breakage. 19. Make sure the wheel is not contacting the FOR BATTERY CARTRIDGE workpiece before the switch is turned on.
  • Page 8 FUNCTIONAL DESCRIPTION 1. Lock-off lever 2. Switch lever CAUTION: Always be sure that the tool is switched off and the • battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge 015307 1. Button To prevent the switch lever from being accidentally 2.
  • Page 9 Automatic speed change function Indicator lamps Remaining 1. Mode indicator capacity Lighted Blinking 75% to 100% 50% to 75% 25% to 50% 015142 0% to 25% Charge the battery. Mode indicator status Operation mode The battery may have High speed mode malfunctioned.
  • Page 10 Installing or removing wheel guard (For depressed center wheel, flap disc / Battery indicator Blinking abrasive cut-off wheel, diamond wheel) WARNING: Protection lock works When using depressed center grinding • 015200 wheel/flap disc, flex wheel, wire wheel brush, cut- In this situation, the tool does not start even if turning off wheel or diamond wheel, the wheel guard must the tool off and on.

  • Page 11: Inner Flange

    (optional accessory) 012772 Mount inner flange, abrasive wheel and Ezynut onto the WARNING: spindle so that Makita Logo on Ezynut faces outside. When using a depressed center wheel or flap disc, the • 1. Shaft lock wheel guard must be fitted on the tool so that the closed side of the guard always points toward the operator.

  • Page 12: Plastic Pad

    NOTE: OPERATION Ezynut can be loosened by hand as long as the • arrow points the notch. Otherwise a lock nut WARNING: wrench is required to loosen it. Insert one pin of It should never be necessary to force the tool. The •...

  • Page 13: Abrasive Cut-Off Wheel/Diamond Wheel

    Operation with abrasive cut-off / diamond wheel (optional accessory) 1. Lock nut 2. Abrasive cut-off wheel/diamond wheel 3. Inner flange 4. Wheel guard for abrasive cut-off wheel/diamond wheel 010855 Remove the battery cartridge from the tool and place it upside down allowing easy access to spindle. Mount the inner flange and abrasive cut-off / diamond wheel onto the spindle.
  • Page 14 WARNING: Operation with wire wheel brush When using an abrasive cut-off / diamond wheel, (optional accessory) • be sure to use only the special wheel guard designed for use with cut-off wheels. (In some CAUTION: European countries, when using a diamond wheel, Check operation of wire wheel brush by running •...
  • Page 15 Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Makita genuine battery and charger •...

  • Page 16: Table Of Contents

    100 mm (4") model 115 mm (4-1/2") model 125 mm (5") model Grip 36 Wheel Guard (for grinding wheel) Inner flange 42 Inner flange 42 Inner flange 30 Super flange 47 *1 Super flange 47 *1 Depressed center wheel/Flap disc Lock nut 14-45 Lock nut 14-45 Lock nut 10-30...
  • Page 20 Makita Jan-Baptist Vinkstraat 2, 3070, Belgium Makita Corporation Anjo, Aichi, Japan www.makita.com 885383D223...
