- Page 1 Installation and Owner’s Manual Smart Toilet (DV-1S0029-V1) NOTE: Drawings may not exactly define contour of the product. www.deervalleybath.com | (+1) 312-626-9466 | service@ deervalleybath.com...
- Page 2 (+1) 312-626-9466 service@deervalleybath.com...
-
Page 3: Table Of Contents
Important Safeguards Explanation of Terms and Symbols WARNING & Attention Product Installation Tools needed Parts included Parts Diagram Smart Toilet overall view Precautions before Installation Install the Smart Toilet Knob and Other Operation Battery Backup Installation Specifications... -
Page 4: Important Safeguards
Grounding pin *WARNING: Risk of electric shock. Connect the unit only to a circuit protected by a ground-fault circuit-interrupter (GFCI). AA200 NOTE: Installation of the DeerValley Smart Toilet may require specialized tools. Plumbing components are not included. (+1) 312-626-9466 www.deervalleybath.com... -
Page 5: Explanation Of Terms And Symbols
Installation and Owner’s Manual 2. Explanation of Terms and Symbols Thank you for purchasing our product. Please read this User Manual before installation and use and save it for future reference. The hazards and warnings listed herein are important to our users' safety. Significant consequences may result from failure to heed warnings. -
Page 6: Warning & Attention
Installation and Owner’s Manual WARNING This product needs to be properly grounded. Risk of electric shock. If unsure, contact an electrician. Do not place a lit cigarette along with other burning objects into the unit. Risk of fire. Do not touch, insert or pull out the power plug with a wet hand. Risk of electric shock. - Page 7 Installation and Owner’s Manual WARNING Regularly unplug the unit from power and wipe off any dust on the plug using a dry cloth. Risk of fire. Young children, the aged and the physically disabled should be given supervision by a person responsible for their safety while using the unit. Otherwise, prolonged use may cause low temperature burns.
- Page 8 Installation and Owner’s Manual WARNING Do not disassemble, repair or alter this product on your own. Call in a professional or contact service center for future advise. Risk of fire, electric shock, and/or other accident that may lead to injury. Do not use industrial or polluted water.
- Page 9 Installation and Owner’s Manual ATTENTION To avoid danger from false reset of the thermal breaker, do not supply power through an external switching device, such as a timer, or connect to a circuit that is periodically turned on and off by a general-purpose component.
- Page 10 Installation and Owner’s Manual ATTENTION When the product is not in use for an extended period, unplug the unit. Ensure to turn off the water supply and drain any remaining water inside the product for optimal storage. Risk of fire, leakage and product damage. Do not use an old hose to connect to the unit.
-
Page 11: Product Installation
Installation and Owner’s Manual 1. Product Installation (1) Tools needed Drill (with 6mm Bit) Raw Tape Utility Knife Marker 23-26mm (Adjustable Wrench) Screwdriver Tape Measure Measuring Cup (2) Parts included Connector Smart Toilet Wax Ring Floor Bolts Operating Instruction and Other Prints Please verify that all items in the package are present. -
Page 12: Parts Diagram
Installation and Owner’s Manual 2. Parts Diagram (1) Smart toilet overall view Knob Toilet Water Supply Hose Water Supply Angle Valve Knob Actual product features and appearance prevail over depictions and descriptions. NOTE: Drawings may not exactly define contour of the product. (+1) 312-626-9466 -10- www.deervalleybath.com... -
Page 13: Precautions Before Installation
Installation and Owner’s Manual (2) Precautions before Installation Water Pressure Requirements The minimum dynamic operating water pressure is 25 Psi, and the maximum static water pressure is 80 Psi. NOTE: Drawings may not exactly define contour of the product. (+1) 312-626-9466 -11- www.deervalleybath.com... -
Page 14: Install The Smart Toilet
Installation and Owner’s Manual 4. Install the Smart Toilet (1) Draw a cross marker on the drain outlet on the ground. Clean the floor and wipe off any excess dust or dirt. Failure to install on an cleaned surface will affect the quality of installation. Existing water supply angle valve Grounded waterproof and splash-... - Page 15 Installation and Owner’s Manual (4) Install the wax ring and brass floor bolts onto floor flange. Insert the 2 brass floor bolts flat head thru the appropriate slot in the floor flange. Use the provided plastic floor bolt washer to secure the floor bolts on the floor flange. Brass bolts should remain verticle FIGURE 5A.
- Page 16 Installation and Owner’s Manual (7) Connecting braided water supply hoses. With the 3/8" male connection facing to the right, apply Telflon tape and screw on adapter (supplied). FIGURE 9B FIGURE 9A Connect toilet water supply hose to male thread on adapter (apply Telflon tape to male threads). Connect braided supply tubes to valve male connections.
-
Page 17: Knob And Other Operation
Installation and Owner’s Manual Knob and other operation Seat Temperature Control Night Light To toggle the night light on/off, press and hold Power on and vacate the seat. the knob, then turn it 45° forward. Adjust seat temperature by turning the knob forward above 45°... - Page 18 Installation and Owner’s Manual Deodorization The function will operate automatically. Deodorizing fan automatically turns on after seating and turns off 3 minutes after leaving the seat. Auto Flush Human body leaves the seat sensor area after seating. When the human body leaves the seat after seating, it will automatically flush once.
-
Page 19: Battery Backup Installation
Installation and Owner’s Manual Battery Backup Installation ●Lift the toilet lid from the bottom, unscrew the battery cover with a Phillips screwdriver, insert a 9V battery, cover the battery compartment, and tighten it with a screwdriver. Place the toilet cover flat on the seat and press down to secure it. -
Page 20: Specifications
Installation and Owner’s Manual 9. Specifications (1) Product specifications Power rating 110V Frequency 60Hz Rated power input Seat temperature range 39.4 °F~104 °F Source water temperature range 39.4 °F~95 °F Water supply type DN15 (G1/2") Minimum pressure 25psi, ensuring a flow of water at least 18L/min Water Inlet Maximum pressure 80psi (still) - Page 21 Installation and Owner’s Manual (3) Regular maintenance Regular maintenance is required to ensure normal use Cut off the power and water supply before maintenance. Direct water wash to the entire product is prohibited. WARNING Do not spray water or During winter season, the water inside may freeze detergents on the toilet, after long periods of storage and non-usage.
- Page 22 Installation and Owner’s Manual (4) Problems & Solutions Problems Problems Check whether the temp of toilet seat is on the "off" position or not Problems 1.Verify if the pipeline is obstructed. Ensure the Inadequate flushing water supply pipeline is unobstructed and flowing No water flow, but flushing of the product smoothly.
- Page 23 DeerValley This warranty is void if the DeerValley is subject to alteration, product shipping/delivery charges may apply and are in or if repairs are attempted by anyone other than an autho- DeerValley sole discretion.
